United states stove company owner's operation and installation manual gas stove c9947n, c9947l

Advertisement

Natural Gas Model
C9947N
Owner's Operation and Installation Manual
This appliance may be installed in an aftermarket* manufactured (mobile) home,
*Aftermarket: Completion of sale, not for purpose of resale, from the manufacturer
This appliance is only for use with the type gas indicated on the rating plate. This appli-
This is an unvented gas-fired
heater. It uses air (oxygen) from
the room in which it is installed.
Provisions for adequate combus-
tion and ventilation air must be
provided. Refer to "Adequate
Combustion And Ventilation Air"
on page(s) 6 of this manual.
WARNING:
Do not use a blower insert,
heat exchanger insert or other
accessories not approved
for use with this heater.
Save this manual for
future reference.
UNITED STATES
STOVE COMPANY
227 INDUSTRIAL PARK ROAD • P.O. BOX 151 • SOUTH PITTSBURG, TN. 37380 • (423)-837-2100
where not prohibited by state or local codes.
ance is not convertible for use with other gases.
WARNING: If the information in this manual is not
followed exactly, a fire or explosion may result
causing property damage, personal injury, or loss of
life.
~Do not store or use gasoline or other flammable
vapors and liquids in the vicinity of this or any other
appliance.
~WHAT TO DO IF YOU SMELL GAS
~Installation and service must be performed by a
qualified installer, service agency, or the gas supplier.
• Do not try to light any appliance.
• Do not touch any electrical switch; do not
use any phone in your building.
• Immediately call your gas supplier from a
neighbor's phone. Follow the gas supplier's
instructions.
• If you cannot reach your gas supplier, call
the fire department.
Propane (LPG) Gas Model
C9947L
851371B 6/00

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the C9947L and is the answer not in the manual?

Questions and answers

Summary of Contents for United States Stove C9947L

  • Page 1 Follow the gas supplier's instructions. • If you cannot reach your gas supplier, call the fire department. ~Installation and service must be performed by a qualified installer, service agency, or the gas supplier. Propane (LPG) Gas Model C9947L 851371B 6/00...
  • Page 2: Table Of Contents

    TABLE OF CONTENTS SECTION IMPORTANT SAFETY INFORMATION...3-4 PRODUCT FEATURES...4 9947 SPECIFICATIONS...5 CONTENTS...5 ITEMS REQUIRED FOR INSTALLATION...6 INSTALLATION...7 MANTEL CLEARANCES...8 GAS CONNECTION...9-10 GAS PRESSURE CHECK...10 FRONT SCREEN REMOVAL...11 LOG ASSEMBLY...11 OPERATING INSTRUCTIONS...12-14 CLEANING / SERVICING...14-15 FLAME APPEARANCE...15 PARTS LIST FOR HEATER ASSEMBLY...16-17 PARTS LIST FOR BURNER AND LOG ASSEMBLY...18-19 TROUBLE SHOOTING...20-21 OPTIONAL EQUIPMENT...22...
  • Page 3: Important Safety Information

    IMPORTANT SAFETY INFORMATION INSTALLER: Please leave these instructions with the owner. OWNER: Please retain these instructions for future reference. IMPORTANT: Read these instructions carefully before installing or trying to operate this heater. WARNING: Any change to this heater or its controls can be dangerous. Improper installation or use of the heater can cause serious injury or death from fire, burns, explosion or carbon monoxide poisoning.
  • Page 4: Important Safety Information

    IMPORTANT SAFETY INFORMATION 13. Keep appliance area clear and free from combustible materials, gasoline and other flammable vapors and liquids. 15. Any safety screen or guard removed for servicing, must be replaced prior to heater operation. 16. This vent-free gas heater is intended to be smokeless. If logs appear to smoke, turn off the heater and call a qualified service person.
  • Page 5: 9947 Specifications

    9947 SPECIFICATIONS Natural Gas Manifold Pressure Setting: Gas Inlet Pressure: Maximum Minimum Model Number 9947N 9947L Controls - Main control has 4 positions: 1. OFF - All gas to the gas logs is shut off at the control 2. IGN - Piezo ignitor allows ignition of the pilot without the use of matches or batteries 3.
  • Page 6: Items Required For Installation

    ITEMS REQUIRED FOR INSTALLATION ITEMS REQUIRED FOR INSTALLATION Ensure that the following items are available before proceeding with installation: • External regulator (for propane/LPG only) • Piping which complies with local codes • Pipe sealant approved for use with propane / LPG (resistant to sulfur compounds) CODES Adhere to all local codes or in their absence, the latest edition of THE NATIONAL FUEL GAS CODE ANSIZ223.1 or NFPA54 which can be obtained from:...
  • Page 7: Installation

    INSTALLATION The following formula can be used to determine the maximum heater rating per the definition of unconfined space: BTU/HR = (L1+L2) Ft x (W) Ft x (H) Ft x 1000 Consider two connecting rooms with an open area between, with the following dimensions:( See Fig.
  • Page 8: Mantel Clearances

    MANTEL CLEARANCES If placing a custom mantel above the heater, you must meet minimum clearances between mantel shelf and the top of the heater. If your installation does not meet the below minimum clearances, you must: • Raise the mantel to an acceptable height, OR •...
  • Page 9: Gas Connection

    GAS CONNECTION A qualified gas appliance installer must connect the fireplace to the gas supply. Consult all local codes. Use new black iron or steel pipe only. Internally tinned copper tubing can be used in some areas when permitted by local codes. Only use pipe of 1/2" or greater diameter to allow full gas volume to heater.
  • Page 10: Gas Connection

    GAS CONNECTION The gas inlet connection is 3/8" NPT, made at the rear of the unit in the bottom left-hand corner. Test all gas joints from the gas meter to the heater for leaks using soap and water solution after completing connection. DO NOT USE AN OPEN FLAME.
  • Page 11: Front Screen Removal

    REMOVING FRONT SCREEN REMOVING FRONT SCREEN: the screen toward you slightly and lift the screen up out of the screen retainer (Fig. 8B). NOTE: To reinstall the front screen, reverse steps 1 & 2. FIG. 8A LOG ASSEMBLY LOG POSITIONING Do not handle these logs with your bare hands! Always wear gloves to prevent skin irritation from ceramic fibers.
  • Page 12: Operating Instructions

    OPERATING INSTRUCTIONS Avoid any drafts that alter the burner flame patterns. Do not allow fans to blow directly into the heater. Do not place a blower inside burn area of firebox. Ceiling fans may create drafts that alter burner flame patterns. Sooting and improper burning will occur. This vent-free gas heater is intended to be smokeless.
  • Page 13 OPERATING INSTRUCTIONS STOP! Read the safety information on the previous page. Set the thermostat to lowest setting. Turn off all electrical power and open the access door. Push in gas control (B) slightly and turn clock wise to "OFF". Push "ON / OFF" switch to "OFF" position. NOTE: Knob cannot be turned from "PILOT"...
  • Page 14: Cleaning / Servicing

    OPERATING INSTRUCTIONS Wait 30 seconds before readjusting the heater when the control has been turned down to a lower setting. MATCH LIGHTING INSTRUCTIONS If the pilot will not light using the piezo ignitor, you can light the pilot with a match. First, locate the pilot. The pilot is located between the two burner tubes on the right end (facing the unit), inside the firebox.
  • Page 15: Flame Appearance

    CLEANING / SERVICING Periodic Cleaning • Do not use cleaning fluid to clean logs or any part of heater. • Logs - Brush with soft bristle brush or vacuum with brush attachment. • Vacuum loose particles and dust from the front and rear burner, control, and piezo. •...
  • Page 16: Parts List For Heater Assembly

    HEATER ASSEMBLY...
  • Page 17 PART NO. 24775 Pedestal 24776 Pedestal Trim 24878 Pedestal Brace 69243 Firebox Bottom 24779 Firebox 69248 Firebox Inner Top 24782 Firebox Outer Top 24780 Front 24783 Blower Box 24784 Cabinet Back 24785 Right Side, Cabinet Door 24786 Left Side, Cabinet 24787 Control Cover Box 24879...
  • Page 18: Parts List For Burner And Log Assembly

    BURNER AND LOG ASSEMBLY...
  • Page 19 KEY PART NO. 24777 BURNER PLATE 89920 BURNER 89921 "O.P. AMERICA" NAT. PILOT • 89922 "O.P. AMERICA" L.P. PILOT 83172 #10A x 1/2 SCREW 89842 COMPRESSION SLEEVE 89841 COMPRESSION NUT 81201 PILOT TUBE 24788 CONTROL BRACKET 81198 CONTROL VALVE (NATURAL) •...
  • Page 20: Trouble Shooting

    TROUBLE SHOOTING Turn off and let cool before servicing. Only a qualified service person should service and repair heater. NOTE: All troubleshooting items are listed in order of operation. OBSERVED PROBLEM When ignitor button is pressed, there is no spark at ODS/Pilot. Appliance produces unwanted odors.
  • Page 21: Trouble Shooting

    TROUBLE SHOOTING OBSERVED PROBLEM ODS/Pilot lights, but flame goes out When control knob is released. (continued from page 20) One or both burner do not light after ODS/pilot is lit. Burner backfires during combustion. Slight smoke or odor during initial operation. Logs appear to smoke after initial operation.
  • Page 22: Optional Equipment

    OPTIONAL EQUIPMENT INDICATOR SKYTECH 1001 MODEL: RCK60 REMOTE CONTROL KIT MODEL: WSK60 WALL SWITCH KIT MODEL: WTK60 WALL THERMOSTAT KIT 32 c 50 60 70 80 90 32 c 50 60 70 80 90...
  • Page 23: Wiring Diagrams

    WIRING DIAGRAM FOR BLOWER ASSEMBLY BLOWER 1/4"FEMALE INS. RHEOSTAT WIRING DIAGRAM FOR GENERATOR ASSEMBLY 1/4"FEMALE INS. 1/4" MALE INS. 1/4"FEMALE INS. 1/4" MALE INS. 1/4" MALE INS. 1/4" FEMALE INS. 1/4"FEMALE INS. THERMODISC THERMOPILE CONTROL WIRING TERMINALS WHITE (NEUTRAL) BLACK (HOT) GREEN (GROUND)
  • Page 24 WIRING GUIDE FOR 9947 The following Wiring Guide is to help assist in the wiring of any combination of the Optional Kit listed below: RCK60 - REMOTE CONTROL KIT WSK60 - WALL SWITCH KIT WTK60 - WALL THERMOSTAT KIT IMPORTANT: Before ordering or installing any to the available kits, remember the following... 1) Not all Optional Kits will work together.
  • Page 25 Optional kits at once, one will always override the other. WALL SWITCH For further information, contact our Customer Service Department at United States Stove Company, 227 Industrial Park Road, P.O. Box 151, South Pittsburg, Tn. 37380. (423)837-2100 THE RCK60 - REMOTE CONTROL KIT:...
  • Page 26: Notes

    NOTES...
  • Page 27: Limited Warranty Policy

    TIES, EXPRESS OR IMPLIED, INCLUDING THE WARRANTY OF MERCHANTABILITY OF FITNESS FOR PURPOSE AND OF ALL OTHER OBLIGATIONS OR LIABILITIES, UNITED STATES STOVE COMPANY DOES NOT ASSUME FOR IT, ANY OTHER OBLIGA- TION OR LIABILITY IN CONNECTION WITH THE SALE OR USE OF THIS HEATER.
  • Page 28 3. The MODEL NUMBER: 9947N / 9947L 4. The SERIAL NUMBER BEFORE INSTALLING YOUR HEATER, FILL IN THE SERIAL NUMBER IN THE SPACE PROVIDED ABOVE FOR YOUR RECORDS. UNITED STATES STOVE COMPANY 227 Industrial Park Rd., P.O. Box 151 South Pittsburg, TN 37380 (423) 837-2100...
  • Page 29: Log Assembly

    REMOVING FRONT SCREEN 1) Lift the front screen slightly up (Fig. 2A) and then tilt the bottom of the screen inward and downward (Fig. 2B). 2) Lean the top of the screen toward you slightly (Fig. 2B) and then proceed to carefully bring the screen straight back (Fig.
  • Page 30: Operating Instructions

    Avoid any drafts that alter the burner flame patterns. Do not allow fans to blow directly into the heater. Do not place a blower inside burn area of firebox. Ceiling fans may create drafts that alter burner flame patterns. Sooting and improper burning will occur.
  • Page 31 OPERATING INSTRUCTIONS 1. STOP! Read the safety information on the previous page. 2. Turn off all electrical power and open the access door. 3. Turn off the rear burner and set the front burner to low. 4. Push in gas control (knob 1) slightly and turn clockwise to "OFF".
  • Page 32: Cleaning / Servicing

    Wait 30 seconds before readjusting the heater when the control has been turned down to a lower setting. MATCH LIGHTING INSTRUCTIONS If the pilot will not light using the piezo ignitor, you can light the pilot with a match. First, locate the pilot. The pilot is located between the two burner tubes on the right end (facing the unit), inside the firebox.
  • Page 33 CLEANING / SERVICING Periodic Cleaning • Do not use cleaning fluid to clean logs or any part of heater. • Logs - Brush with soft bristle brush or vacuum with brush attachment. • Vacuum loose particles and dust from the front and rear burner, control, and piezo. •...
  • Page 34 HEATER ASSEMBLY REPLACEMENT PARTS...
  • Page 35: Parts List For Heater Assembly

    PARTS LIST FOR HEATER ASSEMBLY PART # 69113 69134 69065 69102 69070 24469 69084 24455 24457 89899 83323 24536 89825 89824 83172 N/S = NOT SHOWN IMPORTANT NOTICE: WHEN ORDERING CABINET PARTS, PLACE THE APPROPRIATE CODE AFTER THE PART NUMBER THAT CORRESPONDS TO THE COLOR OF YOUR UNIT. ALMOND = A CHARCOAL GRAY = C GREEN = G...
  • Page 36 BURNER & LOG ASSEMBLY...
  • Page 37 PARTS LIST FOR GAS LOG ASSEMBLY PART # 24610 24611 81189 81190 83251 83244 83343 89831 89834 89838 89839 89840 24612 89872 89873 83437 89841 89842 89829 89836 89830 89836 24613 89826 89826-1 89826-2 89826-3 89826-4 89856 86318 89855 N/S = NOT SHOWN DESCRIPTION BURNER PLATE CONTROL BRACKET...
  • Page 38: Troubleshooting

    Turn off and let cool before servicing. Only a qualified service person should service and repair heater. NOTE: All troubleshooting items are listed in order of operation. OBSERVED PROBLEM When ignitor button is pressed, there is no spark at ODS/Pilot. Appliance produces unwanted odors.
  • Page 39 TROUBLESHOOTING, CONTINUED... OBSERVED PROBLEM ODS/Pilot lights, but flame goes out When control knob is released. (continued from page 17) One or both burner do not light after ODS/pilot is lit. Burner backfires during combustion. Slight smoke or odor during initial operation. Logs appear to smoke after initial operation.
  • Page 40 OPTIONAL F40 BLOWER KIT THIS OPTIONAL F40 BLOWER KIT IS AVAILABLE WHERE YOU PURCHASED THIS HEATER OR YOU CAN ORDER DIRECT FROM THE FACTORY BY CONTACTING THE PARTS DEPARTMENT AT THE NUMBER AND ADDRESS ON THE BACK PAGE OF THIS MANUAL. BACK VIEW OF 9740...
  • Page 41 NOTES...
  • Page 42 TIES, EXPRESS OR IMPLIED, INCLUDING THE WARRANTY OF MERCHANTABILITY OF FITNESS FOR PURPOSE AND OF ALL OTHER OBLIGATIONS OR LIABILITIES, UNITED STATES STOVE COMPANY DOES NOT ASSUME FOR IT, ANY OTHER OBLIGA- TION OR LIABILITY IN CONNECTION WITH THE SALE OR USE OF THIS HEATER.
  • Page 43 3. The MODEL NUMBER: 9740N / 9740L 4. The SERIAL NUMBER BEFORE INSTALLING YOUR HEATER, FILL IN THE SERIAL NUMBER IN THE SPACE PROVIDED ABOVE FOR YOUR RECORDS. UNITED STATES STOVE COMPANY 227 Industrial Park Rd., P.O. Box 151 South Pittsburg, TN 37380 (423) 837-2100...
