- Page 1 '× ' Metal Gazebo ASSEMBLY MANUAL MODEL#: LGMF1559 Missing part? Damaged? Contact us via email at service@domioutdoorliving.com www.domioutdoorliving.com © Copyright 2022-2024 domi LLC. I All Rights Reserved.
- Page 5 Pole Pole Beam Beam Beam Beam Beam Corner Roof Support Tube Corner Roof Support Tube Middle Roof Support Tube Roof Solidifying Bar Middle Roof Support Tube Roof Solidifying Bar Roof Solidifying Bar Middle Roof Tube Middle Roof Tube...
- Page 6 Middle Roof Tube Roof Support Tube Roof Support Tube Solidifying Tube Solidifying Tube Solidifying Tube Solidifying Tube Finishing Bar Finishing Bar Finishing Bar Finishing Bar Finishing Bar Finishing Bar Roof Panel Roof Panel Roof Panel...
- Page 7 Corner Corner Middle Middle Solidifying Bar Solidifying Bar Solidifying Bar Solidifying Bar Middle Beam Middle Beam Joint Bracket Base Base Joint Bracket Beam Union Middle Roof Middle Beam Bracket Connector Tube Connector Union Connector Corner Roof Joint Cover Corner Cover Plastic Cover Tube Connector Bracket...
- Page 8 Plastic Spacer Bracket...
- Page 9 (1) Attach part #B2 to part #A with 6 bolts #1. (2) Attach part #B1 to part #A with 4 bolts #1. (3) Attach part #B to part #A with 3 bolts #3. (4) Repeat the above procedures to assemble the other 3 poles #A.
- Page 10 (1) Attach part #B1 to part #A1 with 4 bolts #1. (2) Attach part #B3 to part #A1 with 4 bolts #3. (3) Repeat the above procedures to assemble another pole #A1.
- Page 11 (1) Insert one side of part #Q into part #C1 and secure with 2 bolts #3. (2) Insert the other side of part #Q into part #C and secure with 2 bolts #3. (3) Place part #R to the assembled beam, secure with 4 bolts #8. Back View Front View (4) Repeat the above procedures to assemble another part #C...
- Page 12 (1) Insert one side of part #Q into part #C3 and secure with 4 bolts #3. (2) Insert the other side of part #Q into part #C2 and secure with 4 bolts #3. Back View Back View (3) Insert one side of part #Q into part #C3 and secure with 4 bolts #3. (4) Insert the other side of part #Q into part #C4 and secure with 4 bolts #3.
- Page 13 (1) Place 2 part #R to the assembled beam, secure with 8 bolts #8. (2) Use 8 bolts #3 to secure 4 part #T1 to the assembled beam as shown. Back View (3) Repeat the above procedures to assemble another part #C2, #C3 and #C4.
- Page 14 (1) Connect part #C4 & #C /(#C1 & #C2) with 8 bolts #7. (From Outside) (2) Repeat the above procedures to assemble the other 3 corners. Please don't fully tighten the bolts.
- Page 15 (1) Secure part #C4 & #C /(#C1 & #C2) to part #A with 4 bolts #3 (From Inside) (2) Repeat the above procedures to assemble the other 3 corners. Please don't fully tighten the bolts.
- Page 16 (1) Insert part #N /#N1 to the bracket on the pole #A, secure with 2 bolts #3. (2) Align the holes and secure part #N to the beam #C with 2 bolts #3. (3) Align the holes and secure part #N1 to the beam #C4 with 2 bolts #3.
- Page 17 (1) Put the corner cover #R1 on the corner and secure with 8 bolts #8. (2) Repeat the above procedures to assemble the other 3 corner covers.
- Page 18 (1) Insert part #N2 /#N3 to the bracket on the middle pole #A1, secure with 2 bolts #3. (2) Align the holes and secure part #N2 /#N3 to the beam #C3 with 2 bolts #3. (3) Repeat the above procedures to assemble the opposite side.
- Page 19 (1) Use 2 bolts #3 to secure part #S1 to corner roof support tube #D, use bolts #3 to secure part #T to corner support roof support tube #D as shown. (2) Use 2 bolts #3 to secure part #S2 to corner roof support tube #D1, use bolts #3 to secure part #T to corner roof support tube #D1 as shown.
- Page 20 (1) Insert part #S to part #D and #D1, secure with 6 bolts #3. (2) Repeat the above procedures to assemble the opposite side.
- Page 21 (1) Place the assembled corner roof support tube #D & #D1 on the beam, align the holes as shown. (2) Use 2 bolts #3 to secure part #S2 to pole #A. (3) Use 1 bolts #3 to secure part #S2 to beam #C. Please don't fully tighten the bolts.
- Page 22 (1) Use 2 bolts #3 to secure part #E2 /#E /#E1 to the corner roof support tube. Inside View Please don't fully tighten the bolts. Inside View Outside View (2) Use 2 bolts #3 to secure part #E2 /#E /#E1 to the beam. (3) Repeat the above procedures to assemble the opposite side.
- Page 23 (1) Insert one side of part #Q2 into part #P and secure with 2 bolts #3. (2) Insert the other side of part #Q2 into part #P1 and secure with 2 bolts #3. (3) Use 2 bolts #6 and nuts #9 to secure 2 part #B4 to part #P.
- Page 24 (1) Insert part #S to part #D2 and #D3, secure with 6 bolts #3. (2) Use 2 bolts #3 to secure part #E2 /#E /#E1 to the middle roof support tube as shown. Please don't fully tighten the bolts. (3) Use bolt #3 to secure 4 part #T3 to the middle roof support tube as shown.
- Page 25 (1) Use 2 bolts #11 and nuts #9 to secure part #D2 to part #S3( fixed on #P) as shown. (2) Use 2 bolts #3 to secure part #E2 /#E /#E1 to the middle beam as shown. (3) Use 2 bolts #11 and nuts #9 to secure part #D3 to part #S3(fixed on #P1).
- Page 26 (1) Place the assembled middle roof frame to the 2 middle pole #A1 as shown. (2) Secure with 4 bolts #3, then secure the opposite side. (3) Tighten all the bolts and press the small plastic cover #R2 to the hole on beam #C3.
- Page 27 (1) Insert one side of part #Q1 into part #F and secure with 4 bolts #3. (2) Insert the other side of part #Q1 into part #F1 and secure with 4 bolts #3. (3) Secure bolts #3 to part #F /#F1 to reinforce the middle roof tube. (From bottom to top) (4) Repeat the above procedures to connect par #F1 &...
- Page 28 (1) Use bolt #3 to secure 4 part #U to the middle roof tube. (From bottom to top)
- Page 29 (1) Place the assembled middle roof tube on the roof support tube, and secure with 3 bolts #3.
- Page 30 (1) Insert part #H to the bracket #U and secure with bolts #3 as shown. (2) Use bolt #2 to connect part #H with bracket #T1 as shown.
- Page 31 (1) Screw 4 hooks #W to part #G. (2) Use bolts #3 to secure part #G to roof support tube #H.
- Page 32 (1) Use bolts #3 to secure 8 bracket #T2 to roof support tube #H. Inside View (2) Place part #J2 on bracket #T2 and secure with bolt #3.
- Page 33 (1) Use bolts #3 to secure 8 bracket #T2 to roof support tube #H. (on both sides) Inside View (2) Place part #J1 on bracket #T2 and secure with bolt #3.
- Page 34 (1) Place part #J /#J3 on bracket #T2 and secure with bolt #3. Inside View (2) Use bolts #3 to secure part #J /#J3 to bracket #T.
- Page 35 (1) Cover plastic bracket #Z to roof panels as shown. Please wear gloves and be careful when handing components.
- Page 36 Spacer #Y should be inserted between roof panels and solidifying bar or beams, then secure with bolts and nuts( step b).
- Page 37 Overall roof assembly. Connect roof as below.
- Page 38 (1) Insert spacer #Y between (2) Insert spacer #Y between roof panels and beams, then roof panels and support secure with bolts #5 and nuts #9. tube #H, then secure with bolts #4.
- Page 39 (1) Insert spacer #Y between roof panels #M2 /#M1 and solidifying tube #J3 /#J, cover with finishing bar #K1 /#K. (2) Secure with bolts #6 and nuts #9.
- Page 40 (1) Place spacer #Y under the roof panel, and insert with finishing bar #L /#L1 /#L2 /#L3. (2)Secure with bolts #5 and nuts #9. You may need 2 people to finish this step.
- Page 41 (1) Insert spacer #Y between roof panels and roof support tube. (2) Affix the gap between each finishing bar with fixing bracket #V2. (3) Align the holes and secure with bolt #6 and nut #9. Please wear gloves and be careful when handing components.
- Page 42 (1) Insert spacer #Y as shown, then cover with fixing bracket #V1, align the holes and secure with bolt #5 and nut #9. (2) Repeat the above procedure to assemble the other 3 corners. Please wear gloves and be careful when handing components.
- Page 43 (1) Place the fixing bracket #V as shown and secure with 1 bolt #3 and 2 self-tapping bolts #8. (2) Repeat the above procedure to assemble the opposite side.
- Page 44 Thanks for your purchase. At domi outdoor living, we believe in our products. That’s why we provide a 12-month warranty and friendly, casy-to-reach after-sales service. So if you have any questions about our product and assembly- ,please feel free to contact us.
