- Page 1 '× ' Metal Patio Gazebo ASSEMBLY MANUAL MODEL#:LGMF1588 Missing part? Damaged? Contact us via email at domiservice01@outlook.com © Copyright 2022-2024 domi LLC. I All Rights Reserved.
- Page 2 U s e b o l t s t o s e c u r e t h e f r a me t o t h e g r o u n d t o a g a i n s t t h e s t r o n g w i n d . ！...
- Page 5 Beam Pole Corner Roof Bar Beam Roof Bar Corner Roof Bar Connector Solidfying Bar Finishing Bar Finishing Bar Finishing Bar Roof Panel Finishing Ba Roof Panel Roof Panel Roof Panel Roof Panel...
- Page 6 Roof Panel Roof Panel Roof Panel Roof Panel Roof Panel Roof Panel Net Frame Roof Panel Base Joint Cover Joint Cover Union Bar Corner Corner Inside Roof Outside Roof Solidifying Bar Solidifying Bar Connector Connector J-Hook Bracket Bracket Bracket Spacer Bracket Hook Joint Cover...
- Page 7 Bracket Corner Cover Finishing End Finishing End Solid Sidewall Plastic Bracket Plastic Bracket Mosquito Sidewall Plastic Bracket...
- Page 8 (1) Attach 2 Part #B1 to Part #A with 4 Bolts #8. (2) Attach 2 Part #B2 to Part #A with 4 Bolts #6. (3) Attach Part #B to Part #A with 3 Bolts #8. (4) Repeat the above procedures to assemble the other 3 Part #A.
- Page 9 (2) Insert the other side of (1) Insert Part #C2 into Part #C1 Part #C2 into Part #C and and secure with 3 Bolts #8. secure with 3 Bolts #8. (4) Insert Part #X into the beam. (3) Connect Part #C1 and Part #C through Part #C2.
- Page 10 (1) Connect Part #C/C1 to Part #A with 8 Bolts #4.(From Outside) (2) Repeat the above procedures to assemble the other 3 corners. ！ Please don't tighten all bolts.
- Page 11 (1) Connect Part #C/C1 to Part #A with 4 Bolts #8.(From Inside) (2) Repeat the above procedures to assemble the other 3 corners. ！ Please don't tighten all bolts.
- Page 12 (1)Affix Part #R and Part #R1 to the frame with 8 Bolts #8 (2) Repeat the above procedures to assemble the other 3 corners. Please don't tighten all bolts. ！...
- Page 13 (1) Cover the corner with Part #X1. (2) Secure with 2 Self-tapping Screws #3. (from top to bottom) (3) Secure with 2 Self-tapping Screws #3. (from bottom to top) (4) Repeat the above procedures to assemble the other 3 corners. Tighten all bolts.
- Page 14 Assemble the 4 Corner Roof Bars: (1) Connect Part #E1 and Part #E with 2 Bolts #8 . (2) Attach Part #U to Part #E with Bolt #8 . (3) Repeat the above procedures to assemble the other 3 corner roof bars.
- Page 15 Please have a freestanding ladder ready at the center of the gazebo. (1) Place 4 Part #E1 on the 4 corners of Part #S. Secure with 8 Bolts #8 (from bottom to top) ATTENTION: You can also finish this step on the ground and then lift 4 corner roof bars and inside roof connector to the top together.
- Page 16 (1) Attach Part #U1 to Part #E2 with Bolt #7 . (2) Repeat the above procedures to assemble the other 3 roof bars.
- Page 17 Outside View (1) Place Part #E2 on part #S. Secure with Bolt #8 (from bottom to top). Inside View (2) Connect Part #E2 and the Assembled Beam(C&C1) with part #U1. Secure with 2 Bolts #8 . (3) Repeat the above procedures to assemble the other 3 sides.
- Page 18 Secure Part #T to Part #S and Part #S1. Outside View ATTENTION: The holes of Part #S and Part #S1 need to be aligned, on the same vertical line.
- Page 19 (1) Insert Part #U3 into 2 Part #F. (2) Attach Part #F to the Part #E2 with 1 Bolt #7 and 2 Blots #8. Inside View (3) Repeat the above procedures to assemble the other 3 sides.
- Page 20 Inside View (1) Insert Part #U2 into 2 Part #F . (2) Secure with 2 Bolts #8. (3) Secure them to Part #E with Bolt #8. (4) Repeat the above procedures to assemble the other 3 sides.
- Page 21 (1) Connect Part #J and Part #Q with 2 Bolts #7 and 2 Nuts #5. (2) Place the Assembled Part #J & #Q on Part #E2, securing with 1 Bolt #8. (3) Repeat the above procedures to assemble the other 3 sides.
- Page 22 (1) Place 2 Part #J on Part #E, put on Part #X3 and secure with Self-tapping Screw #2. Inside View （2) Repeat the above procedures to assemble the other 3 corners.
- Page 23 Cover Part #Z, #Z1 & #Z2 to Roof Panels. Section View...
- Page 24 ATTENTION: The bigger roof panel need to cover the smaller one. (1) Insert Part #L1 and Part #L2 into the fame. (2) Insert Part #L3 and Part #L4 into the fame. (3) Attach Part #H to Part #E2, securing with Bolt #8. (4) Repeat the above procedures to assemble the other 3 sides.
- Page 25 (1) Place 2 Part #H on Part #E1, put on Part #X3 and secure with Self-tapping Screw #2. Outside View (2) Repeat the above procedures to assemble the other 3 corners.
- Page 26 Cover Part #Z to Roof Panels Section View...
- Page 28 ATTENTION: The bigger roof panel need to cover the smaller one. (1) Insert Part #M1 and Part #M2 into the frame. (2) Insert Part #M8 and Part #M7 into the frame. (3) Place 6 Part #W between roof panels and beams. Then secure with 6 Bolts #10 and 6 Nuts #5.
- Page 29 ATTENTION: The bigger roof panel need to cover the smaller one. (3) Place 4 Part #W between roof panels and solidifying bars. Then secure with 4 Bolts #12 and 4 Nuts #5. (1) Insert Part #M3 into the frame. (2) Insert Part #M6 into the frame.
- Page 30 ATTENTION: The bigger roof panel need to cover the smaller one. (1) Insert Part #M4 into the frame. (3) Place 4 Part #W between roof panels and solidifying bars. Then secure with 4 Bolts #12 and 4 Nuts #5; Place 1 Part #W between roof panels and Part #E2.
- Page 31 ATTENTION: The bigger roof panel need to cover the smaller one. (1) Insert Part #M1 and Part #M2 into the frame. (2) Insert Part #M8 and Part #M7 into the frame. (3) Place 6 Part #W between roof panels and beams. Then secure with 6 Bolts #10 and 6 Nuts #5.
- Page 32 ATTENTION: The bigger roof panel need to cover the smaller one. (1) Insert Part #M3 into the frame. (3) Place 4 Part #W between roof panels and solidifying bars. Then secure with 4 Bolts #12 and 4 Nuts #5. (2) Insert Part #M6 into the frame.
- Page 33 ATTENTION: The bigger roof panel need to cover the smaller one. (1) Insert Part #M4 into the frame. (3) Place 4 Part #W between roof panels and solidifying bars. Then secure with 4 Bolts #12 and 4 Nuts #5; Place 1 Part #W between roof panels and Part #E2.
- Page 34 (1) Place Part #W between roof panels and Part #E2. Then secure with Bolt #11 and Nut #5. (2) Repeat the above procedures to assemble the other 3 sides.
- Page 35 (1) Place Part #K and Part #K1 on Part #E2; Put on Part #X2 and secure with Bolt #8. (2) Repeat the above procedures to assemble the other 3 sides.
- Page 36 (1) Place Part #K1 and Part #K on Part #E; Put on Part #X3 and secure with Self-tapping Screw #2. (2) Repeat the above procedures to assemble the other 3 corners.
- Page 37 (1) Attach roof panels to f inishing bars with 2 Self-tapping Screws #3. (2) Repeat the above procedures to assemble the other 3 sides.
- Page 38 How to Put the 112 Hooks into the Double-track Double-track 7 Hooks × 2 Rows 7 Hooks × 2 Rows 7 Hooks × 2 Rows 7 Hooks × 2 Rows 7 Hooks × 2 Rows 7 Hooks × 2 Rows 7 Hooks ×...
- Page 39 (1) Place 7 hooks on each slot of the Sidewall Track(C1&C). (2) Install Part #T1 at the joint of Part C&C1 with Bolt #8. Double-track (3) Repeat the above procedures to assemble other 3 sides.
- Page 40 Hang up Mosquito Sidewalls to Inside Track...
- Page 41 Hang up Solid Sidewalls to Outside Track...
- Page 42 R E S O P T C O M F O R T I N Y O N R O W N B A C K Y A R D A t d o m i o u t d o o r l i v i n g , w e b e l i e v e i n o u r p r o d u c t s . T h a t ’...
