Hardware Installation and Reference Guide
No. Ports
2 LAN Port
3 WAN/PoE Port
Figure 1-5 LED
Table 1-2 LED
Color
Off
Slow Blinking (at 0.5 Hz)
Fast Blinking (at 2 Hz)
Solid White
Description
Four 10/100/1000Base-T Ethernet ports for wired connection
One 10/100/1000Base-T Ethernet port, providing data and power transmission
through an Ethernet cable
Status
The access point is not receiving power.
The access point is operating normally but there is an alarm generated.
Possible cases:
1. Restoring the access point to factory settings.
2. Upgrading the firmware.
3. Handling alarms automatically.
4. Starting up the access point.
The access point is operating normally without alarms.
4
Product Overview
