System Components - Fluke Datapaq Furnace Tracker User Manual

The dedicated User Manual supplied with your data logger should be read in
conjunction with this manual. It provides information on operating the logger,
including:
• Installing Insight and establishing communication between logger and PC.
• Resetting the logger with new data-collection parameters.
• Downloading the collected data to the PC.
• Use of hardwired telemetry.
• Troubleshooting logger problems.
For full details on use of the Insight software, refer to the online Help system
available when the software is installed.

System Components

A typical Furnace Tracker system comprises:
• Data logger, with communications lead and charger; logger with radio-
telemetry option includes internal transmitter.
• Receiver (radio-telemetry option only).
• Thermal barrier – to protect the logger during its time in the furnace.
• Thermocouple probes.
• Insight Furnace Tracker software.
• User documentation:
○ Datapaq Furnace Tracker User Manual.
○ Data logger User Manual (specific to the logger model).
○ TM21 Radio-telemetry System User Manual (radio-telemetry option only).
Additional hardware, software and documentation are supplied with Furnace
Surveying, CAB Surveyor and other systems, as appropriate.
This manual, and other Datapaq user documentation, in various languages, is
available on the Insight installation DVD or USB key included with Datapaq systems.
During the software installation, you may select documents to be copied to your PC
8
Introduction
for rapid on-demand viewing through Insight.
