Page 1
H13SAE-MF ENGLISH QUICK REFERENCE GUIDE Revision 1.0...
Page 2
Should you have questions or experience difficulty, contact Supermicro's Technical Support Department for assistance. Only certified technicians should attempt to install or configure components. Read this section in its entirety before installing or configuring components in the Supermicro chassis. WARNING: This product can expose you to chemicals including lead, known to the State of California to cause cancer and birth defects or other reproductive harm.
Page 4
UPERMICR H13SAE-MF . 1.0 uick efeRence uide Motherboard Layout and Features I/O BACK PANEL UID_LED UID SW JUBUD1 COM1 BMC_LAN LAN2 LAN1 LEDM1 PCIe 4.0x4 USB6(3.1) USB7(3.2) USB2(3.1) USB3(3.1) JPW2 USB4(3.1) USB5(3.1) LEDM22 M.2-C1 H13SAE-MF REV:1.00 DESIGNED IN USA M.2-C2...
Page 5
• One Supermicro Motherboard • Four SATA Cables • One I/O Shield • One Quick Reference Guide Jumpers and Connectors Jumpers Jumper Description Default JBT1 Clear CMOS (Onboard) Short Pads to Clear CMOS UID SW Unit ID Switch (Push-Button Toggle Switch ON/OFF)
Page 6
• Drivers & Utilities: https://www.supermicro.com/wdl/ • Safety: http://www.supermicro.com/about/policies/safety_information.cfm CPU & Memory Support The H13SAE-MF motherboard supports up to 128 GB of ECC/Non ECC UDIMM DDR5 5200 MT/s speed, populated in four DIMM slots. Refer to the table below for additional memory information. Notes: •...
Page 7
otes • Graphics shown in this quick reference guide are for illustration purposes only. Your compo- nents may or may not look exactly the same as the drawings shown in this guide. • Refer to Chapter 2 of the User Manual for detailed information on jumpers, connectors, LED indicators, memory support and CPU/motherboard installation instructions.
