Summary of Contents for Supermicro H13SAE-MF
- Page 1 H13SAE-MF ENGLISH QUICK REFERENCE GUIDE Revision 1.0...
-
Page 2: Battery Handling
Supermicro's Technical Support Department for assistance. Only certified technicians should attempt to install or configure components. Read this section in its entirety before installing or configuring components in the Supermicro chassis. WARNING: This product can expose you to chemicals including lead, known to the State of California to cause cancer and birth defects or other reproductive harm. - Page 3 H13SAE-MF QUICK REFERENCE GUIDE 限用物質含有情況標示聲明書 限 限 用 用 物 物 質 質 含 含 有 有 情 情 況 況 標 標 示 示 聲 聲 明 明 書 書 Declaration of the Presence Condition of the Restricted Substances Marking 設備名稱：主機板...
-
Page 4: Cpu Installation
H13SAE-MF QUICK REFERENCE GUIDE CPU Installation CPU Installation Installing the Processor Note: Do not remove the plastic cover covering the outside of the socket. This cover will pop out during installation of the processor. Use a finger to push down the lever, then... -
Page 5: Heat Sink Installation
H13SAE-MF QUICK REFERENCE GUIDE Heatsink Installation Heatsink Installation After the processor is secured, now you must install the heatsink to the socket frame. Lower the heatsink down until the four screws on the heatsink align with the four screw holes on the socket frame. - Page 6 M.2 Device Installation H13SAE-MF QUICK REFERENCE GUIDE M.2 Device Installation This motherboard has four M.2 M-key sockets that support the 2280 and 22110 M.2 devices. One standoff and a screw are pre-installed into the position of each 22110 mounting hole.
- Page 7 M.2 Device Installation H13SAE-MF QUICK REFERENCE GUIDE 2280 M.2 Device Installation Locate the pre-installed standoff and screw. Remove the screw and set it aside. Using a hex socket screwdriver, re- move and then re-install the standoff to the position of the 2280 mounting hole.
- Page 8 M.2 Device Installation H13SAE-MF QUICK REFERENCE GUIDE 22110 M.2 Device Installation Locate the pre-installed screw. Re- move the screw and set it aside. Insert the M.2 device into the M.2 socket at a 30-degree angle and press it down. Tighten the screw to secure the M.2 device into place.
- Page 9 H13SAE-MF QUICK REFERENCE GUIDE NOTES...
- Page 10 UPERMICR H13SAE-MF . 1.0 uick efeRence uide Motherboard Layout and Features I/O BACK PANEL UID SW LEDM1 UID_LED LAN1 LAN2 BMC LAN USB 3.2 DP/HDMI VGA/COM1 HD AUDIO USB 3.2 USB 3.2 JUBUD1 USB 3.2 USB 3.2 USB 3.2 PCIe 5.0x16 J4901 PCIe 5.0x8...
-
Page 11: Jumpers And Connectors
• One Supermicro Motherboard • Four SATA Cables • One I/O Shield • One Quick Reference Guide Jumpers and Connectors Jumpers Jumper Description Default JBT1 Clear CMOS (Onboard) Short Pads to Clear CMOS UID SW Unit ID Switch (Push-Button Toggle Switch ON/OFF) -
Page 12: Memory Support
• Drivers & Utilities: https://www.supermicro.com/wdl/ • Safety: http://www.supermicro.com/about/policies/safety_information.cfm Memory Support The H13SAE-MF motherboard supports up to 192 GB of ECC/Non ECC UDIMM DDR5 5200/4800/3600 MT/s speed, populated in four DIMM slots. Refer to the table below for additional memory information. -
Page 13: Back Panel I/O Connectors
otes • Graphics shown in this quick reference guide are for illustration purposes only. Your compo- nents may or may not look exactly the same as the drawings shown in this guide. • Refer to Chapter 2 of the User Manual for detailed information on jumpers, connectors, LED indicators, memory support and CPU/motherboard installation instructions.
