Network Turret Camera
Quick Start Guide
0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Hilook T6 Series and is the answer not in the manual?

Questions and answers

Related Manuals for HIKVISION Hilook T6 Series

Summary of Contents for HIKVISION Hilook T6 Series

  • Page 1 Network Turret Camera Quick Start Guide...
  • Page 2 Any and all information, including, among others, wordings, pictures, graphs are the properties of Hangzhou Hikvision Digital Technology Co., Ltd. or its subsidiaries (hereinafter referred to be “Hikvision”). This user manual (hereinafter referred to be “the Manual”) cannot be reproduced, changed, translated, or distributed, partially or wholly, by any means, without the prior written permission of Hikvision.
  • Page 3 LOSS OF BUSINESS PROFITS, BUSINESS INTERRUPTION, OR LOSS OF DATA OR DOCUMENTATION, IN CONNECTION WITH THE USE OF THIS PRODUCT, EVEN IF HIKVISION HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. REGARDING TO THE PRODUCT WITH INTERNET ACCESS, THE USE OF PRODUCT SHALL BE WHOLLY AT YOUR OWN RISKS.

  • Page 4: Regulatory Information

    Network Turret Camera·Quick Start Guide IN THE EVENT OF ANY CONFLICTS BETWEEN THIS MANUAL AND THE APPLICABLE LAW, THE LATER PREVAILS. Regulatory Information FCC Information Please take attention that changes or modification not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.

  • Page 5: Safety Instruction

    Network Turret Camera·Quick Start Guide This product and - if applicable - the supplied accessories too are marked with "CE" and comply therefore with the applicable harmonized European standards listed under the EMC Directive 2014/30/EU, the RoHS Directive 2011/65/EU. 2012/19/EU (WEEE directive): Products marked with this symbol cannot be disposed of as unsorted municipal waste in the European Union.
  • Page 6 Network Turret Camera·Quick Start Guide The precaution measure is divided into “Warnings” and “Cautions” Warnings: Serious injury or death may occur if any of the warnings are neglected. Cautions: Injury or equipment damage may occur if any of the cautions are neglected. Warnings Follow these Cautions Follow these safeguards to prevent...
  • Page 7 Network Turret Camera·Quick Start Guide ● Do not connect several devices to one power adapter as adapter overload may cause over-heating or a fire hazard. ● Please make sure that the plug is firmly connected to the power socket. When the product is mounted on wall or ceiling, the device shall be firmly fixed.
  • Page 8 Network Turret Camera·Quick Start Guide ● Do not place the camera in extremely hot, cold (the operating temperature shall be -30 °C to 60 °C), dusty or damp locations, and do not expose it to high electromagnetic radiation. ● To avoid heat accumulation, good ventilation is required for operating environment.

  • Page 9: Table Of Contents

    Network Turret Camera·Quick Start Guide Table of Contents 1 Appearance Description ..............9 2 Installation ..................11 (Optional) Install the Memory Card ....... 11 Ceiling Mounting ............12 Wall Mounting .............. 16 Mounting with Junction Box.......... 18 Mounting with Inclined Base ......... 21 2.6 (Optional) Network Cable Waterproof Jacket Installation23 3 Set the Network Camera over the LAN .........

  • Page 10: Appearance Description

    Network Turret Camera·Quick Start Guide 1 Appearance Description The overview of the camera is shown as the figure below. Type I Camera Overview Type II Camera Overview Description Camera Body Enclosure Mounting Base Lock Button...
  • Page 11 Network Turret Camera·Quick Start Guide Description Network Cable Power Cord Notes: Only certain models support memory card installation and  reset function. Power on the camera when pressing the RESET button, and  press button for another 10 seconds to restore the default settings, including the user name, password, IP address, port No., etc.

  • Page 12: Installation

    Network Turret Camera·Quick Start Guide 2 Installation Before you start: ● Make sure the device in the package is in good condition and all the assembly parts are included. ● The standard power supply is 12 VDC, please make sure your power supply matches with your camera.

  • Page 13: Ceiling Mounting

    Network Turret Camera·Quick Start Guide Expose the Memory Card Slot 2. Loosen the screws to remove the memory card slot cover. 3. Insert the memory card into the slot, and push to get it mounted. Memory Card Reset Button Memory Card Slot Install the Memory Card 4.
  • Page 14 Network Turret Camera·Quick Start Guide Type I and Type II camera both support the ceiling mounting and the steps are similar. Here takes type II as an example to describe the steps. Steps: 1. Disassemble the camera by pressing the button on the camera. Press Disassemble the Camera 2.
  • Page 15 Network Turret Camera·Quick Start Guide 54.3 3-Φ4.5 Φ125 14.5 Figure 2-4 The Drill Template 3. Drill the screw holes or the cable hole in the ceiling according to the drill template. Note: Drill the cable hole if adopting ceiling outlet to route the cable.
  • Page 16 Network Turret Camera·Quick Start Guide Note: In the supplied screw package, both self-tapping screws, and  expansion bolts are contained. If the ceiling is cement, expansion bolts are required to fix the  camera. If the ceiling is wooden, self-tapping screws are required.

  • Page 17: Wall Mounting

    Network Turret Camera·Quick Start Guide 8. Power on the camera, and set the network configuration. For details, refer to 3 Set the Network Camera over the LAN and 4 Access via Web Browser. 9. Adjust the surveillance angle. Adjust Surveillance Angle 1).
  • Page 18 Network Turret Camera·Quick Start Guide Steps: 1. Disassemble the camera by pressing the button on the camera. Press Disassemble the Camera 2. Drill screw holes in the wall according to the holes of the bracket and install the bracket to the wall with screws. Install the Bracket 3.

  • Page 19: Mounting With Junction Box

    Network Turret Camera·Quick Start Guide Install the Mounting Base to the Bracket 4. Repeat steps 5 to 9 of 2.2 Ceiling Mounting to complete the installation. Mounting with Junction Box Before you start: ● Type I and Type II both support mounting with junction box and the steps are similar.
  • Page 20 Network Turret Camera·Quick Start Guide Press Disassemble the Camera 2. Paste the supplied drill template to the desired mounting position. Drill Template 3. Drill the screw holes according to the drill template. 4. (Optional) If you want to route the cables inside the wall, drill a cable hole in the wall according to the adapter plate.
  • Page 21 Network Turret Camera·Quick Start Guide Fix Mounting Base on the junction box’s Cover 6. Secure the junction box’s body on the wall with screws. Secure the Junction Box’s Body on the Wall 7. Combine the junction box’s cover with its body with supplied screws.

  • Page 22: Mounting With Inclined Base

    Network Turret Camera·Quick Start Guide Combine the Junction Box’s Cover with its body 8. Repeat steps 5 to 9 of 2.2 Ceiling Mounting to complete the installation. Mounting with Inclined Base Before you start: ● Type I and Type II both support mounting with inclined base and the steps are similar.
  • Page 23 Network Turret Camera·Quick Start Guide 2. Paste the inclined base’s drill template to the wall. 3. Drill screw holes and the cable hole (optional) on the wall according to the supplied drill template. Note: Drill the cable hole, when adopting ceiling outlet to route the cable Drill Template 4.

  • Page 24: Optional) Network Cable Waterproof Jacket Installation23

    Network Turret Camera·Quick Start Guide Fix the Inclined Base’s boy on Ceiling/Wall 6. Combine inclined base’s cover with its body with screws. Combine the Cover with the Body 7. Repeat steps 5 to 9 of 2.2 Ceiling Mounting to complete the installation.
  • Page 25 Network Turret Camera·Quick Start Guide Figure 2-21 Waterproof Accessory Components Table 2-1 Components Components Camera’s Network Interface Socket O-Type Gasket Network Plug Waterproof Endcap Waterproof Rubber Gasket Lock Nut Network Cable from Router/Switch Steps: Feed the plugless network cable ⑦ through the lock nut ⑥, waterproof the rubber gasket ⑤...
  • Page 26 Network Turret Camera·Quick Start Guide Crimp an RJ-45 network plug ③onto the end of the cable, taking care to insert the twisted pairs of wires in correct order. Place the O-type gasket ② onto the end of the camera’s network interface socket ①. Insert the network plug ③...
  • Page 27 Network Turret Camera·Quick Start Guide Align the snap and notch. i. Insert into ⑤ ④ ii. Secure with ⑥ ④ Camera Switch/Router Waterproof Accessory Installation...

  • Page 28: Set The Network Camera Over The Lan

    Network Turret Camera·Quick Start Guide 3 Set the Network Camera over the Note: You shall acknowledge that the use of the product with Internet access might be under network security risks. For avoidance of any network attacks and information leakage, please strengthen your own protection.

  • Page 29: Activate The Camera

    Network Turret Camera·Quick Start Guide Activate the Camera You are required to activate the camera first by setting a strong password for it before you can use the camera. Activation via web browser, activation via SADP, and activation via client software are all supported. We will take activation via SADP software and activation via web browser as examples to introduce the camera activation.
  • Page 30 Network Turret Camera·Quick Start Guide Activation Interface (Web) 3. Create a password and input the password into the password field. STRONG PASSWORD RECOMMENDED– We highly recommend you create a strong password of your own choosing (using a minimum of 8 characters, including upper case letters, lower case letters, numbers, and special characters) in order to increase the security of your product.

  • Page 31: Activation Via Sadp Software

    Network Turret Camera·Quick Start Guide 5. Click OK to save the password and enter the live view interface. Activation via SADP Software SADP software is used for detecting the online device, activating the camera, and resetting the password. Get the SADP software from the supplied disk or the official website, and install the SADP according to the prompts.

  • Page 32: Modify The Ip Address

    Network Turret Camera·Quick Start Guide 3. Create and input the new password in the password field, and confirm the password. STRONG PASSWORD RECOMMENDED– We highly recommend you create a strong password of your own choosing (using a minimum of 8 characters, including upper case letters, lower case letters, numbers, and special characters) in order to increase the security of your product.
  • Page 33 Network Turret Camera·Quick Start Guide For IP address modification via client software, refer to the user manual of client software. Steps: 1. Run the SADP software. 2. Select an active device. 3. Change the device IP address to the same subnet with your computer by either modifying the IP address manually or checking the checkbox of Enable DHCP.
  • Page 34 Network Turret Camera·Quick Start Guide Note: You can enable the Hik-Connect service for the device during activation. Refer to Chapter 5.1 for detailed information. 4. Input the admin password and click Modify to activate your IP address modification. The batch IP address modification is supported by the SADP. Refer to the user manual of SADP for details.

  • Page 35: Access Via Web Browser

    Network Turret Camera·Quick Start Guide 4 Access via Web Browser System Requirement: Operating System: Microsoft Windows XP SP1 and above version CPU: 2.0 GHz or higher RAM: 1G or higher Display: 1024×768 resolution or higher Web Browser: Internet Explorer 8.0 and above version, Apple Safari 5.0.2 and above version, Mozilla Firefox 5.0 and above version and Google Chrome 18 and above version Steps:...
  • Page 36 Network Turret Camera·Quick Start Guide 4. Click Login. Login Interface 5. Install the plug-in before viewing the live video and managing the camera. Follow the installation prompts to install the plug-in. Note: You may have to close the web browser to finish the installation of the plug-in.

  • Page 37: Operate Via Hik-Connect App

    Network Turret Camera·Quick Start Guide 5 Operate via Hik-Connect App Purpose: Hik-Connect is an application for mobile devices. With the App, you can view live image of the camera, receive alarm notification and so Note: Hik-Connect service is not supported by certain camera models. Enable Hik-Connect Service on Camera Purpose: Hik-Connect service should be enabled on your camera before using...

  • Page 38: Enable Hik-Connect Service Via Web Browser

    Network Turret Camera·Quick Start Guide Verification Code Setting (SADP) Note: The verification code is required when you add the camera to Hik-Connect app. 3. Click and read "Terms of Service" and "Privacy Policy". 4. Confirm the settings. Enable Hik-Connect Service via Web Browser Before you start: You need to activate the camera before enabling the service.
  • Page 39 Network Turret Camera·Quick Start Guide Steps: 1. Access the camera via web browser. Refer to Chapter 4. 2. Enter platform access configuration interface: Configuration > Network > Advanced Settings > Platform Access. Platform Access Configuration (Web) 3. Select Platform Access Mode as Hik-Connect. 4.

  • Page 40: Hik-Connect Setup

    Network Turret Camera·Quick Start Guide 7. Save the settings. Hik-Connect Setup Steps: 1. Download and install the Hik-Connect app by searching “Hik-Connect” in App Store or Google Play 2. Launch the app and register for a Hik-Connect user account. 3. Log in Hik-Connect app after registration. Add Camera to Hik-Connect Before you start: You need to enable the Hik-Connect service on camera before...
  • Page 41 Network Turret Camera·Quick Start Guide 2. In the Hik-Connect app, tap “+” on the upper-right corner and then scan the QR code of the camera to add the camera. You can find the QR code on the camera or on the cover of the Quick Start Guide of the camera in the package.

  • Page 42: Initialize The Memory Card

    Network Turret Camera·Quick Start Guide Initialize the Memory Card Steps: Check the memory card status by tapping on the Storage Status in the Device Settings interface. If the memory card status displays as Uninitialized, tap to initialize it. The status will then change to Normal. You can then start recording any event triggered video in the camera such as motion detection.
  • Page 43 UD10150B...
