3 Straighten the cables at the top of the shaft, and slowly pull the propeller drive motor away from the shaft
base until you can see the power and data cables
4 Holding the cables only, slowly pull them through the shaft, taking care that the connectors do not get caught
on the top of the shaft.
When removing the propeller drive motor from the shaft, you must pull the cables themselves, and not the
motor. Pulling on the propeller drive motor may damage the cable connections inside the motor. The motor
should not be supported by the cables alone. Supporting the motor only with the cables may damage the motor.
The power cables and transducer cable (if present) should pull through the shaft completely.
Removing the Cable Grommets
1 Using the tool included in the kit, remove the recessed grommet nuts
2 Push out the grommets
NOTICE
from the inside of the downshaft adapter.
connected to the propeller drive motor.
from both sides.
