SCATOLA INCASSO SCH. 1730/60 PER PULSANTIERA
EMBEDDING BOX REF. 1730/60 FOR OUTDOOR STATION
Installazione ad incasso per pulsantiera modello 1730/51
Flush-mounting installation for 1730/51 outdoor station type
Scatola incasso
Embedding box
1
Fori per passaggio cavi
Cable passage holes
2
Viti per fissare la piastra sulla scatola
Screws for fixing the framework on the box
3
Vite per fissare il frontale della pulsantiera
sulla piastra
Screws for fixing the outdoor station front
side on the framework
4
Chiave per apertura/chiusura blocco frontale
Front side opening / closing key
Piastra
Framework
Recommended
Blocco frontale
Front side
Altezza di
installazione
consigliata
installation
height
Mod.
1730
