52" 65 Watt ABS Ceiling Fan
MANUAL
Remote Control Compatible
65W
AC
MOTOR
Energy
Brushless
Quick Connect
Efficient
Quiet
www.martecaustralia.com.au | 02 8778 7500 | sales@martecltd.com.au
MBF1343WS
MBF1343TS
52"
Lightweight
Easy Switch
ABS Blades
Blade System
System
2
12º
Blade
Tropical
Pitch
Rated
Advertisement
Table of Contents
Related Manuals for Martec Beret Series
Summary of Contents for Martec Beret Series
- Page 1 BERET SERIES 52" 65 Watt ABS Ceiling Fan INSTALLATION/ASSEMBLY/ WIRING MANUAL For No Light and Including Light Kit Models MBF134WS MBF1343WS MBF1343TS MBF134TS Remote Control Compatible NOTE: REMOTE CONTROLLER IS NOT INCLUDED WITH THIS MODEL BUT CAN BE PURCHASED FROM YOUR RETAILER Model No:(MPAPP) Prince Smart Remote Controller Kit 12º...
- Page 2 GENERAL INFORMATION AND WARNINGS Congratulations on choosing to buy a Quality Martec product. All products brought to you by MARTEC ® are manufactured to the highest standards of performance and safety, Your purchase is backed by our comprehensive 2 Year In-Home Warranty.
- Page 3 BERET ASSEMBLY INSTRUCTIONS HOW TO INSTALL THE LIGHT KIT PLATE (Version with LED LIGHT ) The screw on the connecting disk is aligned with the keyhole of the lamp plate connector . After rotating clockwise to the bottom, tighten the screw with the screwdriver to ensure that the screw does not move ( see diagram below) FIG 1 www.martecaustralia.com.au | 02 8778 7500 | sales@martecltd.com.au...
- Page 4 HOW TO INSTALL THE MARTEC ANTI-NOISE SURE HANG KIT PLATE The screw on the connecting disk is aligned with the keyhole of the lamp disk. After rotating clockwise to the bottom, tighten the screw with the screwdriver to ensure that the screw is firmly in place.
-
Page 5: Mechanical Noise
INFORMATION FOR LICENSED ELECTRICIAN AND FAN OWNERS Please read fault finder before calling for warranty. FAN WILL NOT START • Check that mains circuit breakers are in the ON position. • Check that isolation wall switch is in the ON position. •... -
Page 6: Important Facts
IMPORTANT FACTS All electric motors, including fan motors make some noise and may feel hot to touch - this is not a fault. Ceiling fans tend to move during operation as they are not generally rigid-mounted. Rigid mounted ceiling fans generate excessive vibration and stress on their mountings. Movement of a couple of centimeters is quite normal and does not suggest the fan will fall down. - Page 7 Other uses may cause personal injury or fire hazard. • Use of wall/remote controller other than those approved by Martec will void this warranty. • Make sure electricity is turned off at the main power box before commencing work. Turn off the power by removing fuse or turning off circuit breaker before installing the wall/ remote controller.
-
Page 8: Assembly Instruction
ASSEMBLY INSTRUCTION HOW TO INSTALL BLADES The blade hole position is aligned with the turntable hole position. Tighten with the blade screw of the screw bag. (See Fig.6) HOW TO INSTALL THE FACE PLATE (Version without light) The raised clamping position on the cover is aligned with the slot in the cover and then rotate the cover clockwise until it is tightened Fig.8 www.martecaustralia.com.au | 02 8778 7500 | sales@martecltd.com.au... - Page 9 ASSEMBLY INSTRUCTION With Light Version , install frosted Lens Cover Please make sure the switch is off before changing the color temperature. Simply switch the slide switch on the LED plate (See Fig.9.) to select the desired color temperature (WW3000K, NW4000K or CW 5000K). ( See image below) Fig.9 Changing Colour Temperature Slide Switch 3000k, 4000k 5000k www.martecaustralia.com.au | 02 8778 7500 | sales@martecltd.com.au...
-
Page 10: Wiring Diagram
WIRING DIAGRAM WIRING DIAGRAM FOR FAN CONTROLLED WITH WALL CONTROLLER WALL CONTROLLER Important : Ensure all cables are SAFETY SYMBOLS electrically isolated before wiring. Protective Earth • Wire the incoming power cables to the terminal block Warning / Caution mounted on the hanging bracket. Wire Active, Neutral and Earth to corresponding L, N terminals respectively. - Page 11 Fan Size and Dimensions Features • Complete with 4 precision ABS easy molded blades. • Quiet and Powerful 65 Watt pre- assembled motor. • Reversible switchable airflow option for summer -winter. • Quick Connect wiring and fittings for easy installation. •...
-
Page 12: Specifications
Specifications Input Voltage : 230V- AC - 50Hz Motor : 65 Watt AC LED : 24 W Tri- Colour ( For Light Models ) Total Power Consumption Fan Only : 65Watt ( If fitted with optional extra LED light Kit add 24W) Compliance AS/NZS CISPR 14.1;... -
Page 13: Blade Attachment
Assembly • Unlike most ceiling fans, the Martec ® your ceiling fan requires you to attach the blades this model. • If installing more than one ceiling fan , ensure that the blades do not get mixed up between units as each set is dynamically balanced. -
Page 14: Product Maintenance
Warning If unusual oscillating movement is observed , immediately stop using the ceiling fan and contact Martec , or suitable qualified persons. Normal Wear and Tear Threaded components working slightly loose or blade carriers even slightly bent due to vigorous cleaning or bumping can cause extra wobble and noise. -
Page 15: Troubleshooting
Trouble Shooting Caution: Before any adjustment are made , please ensure fan is OFF and has stopped spinning. Any non electrical troubleshooting must be performed by persons with adequate skills. If uncertain , please contact supplier. Always ensure the fan is turned off before cleaning or blade adjustments are made. -
Page 16: Warranty Statement
2. The 2 year “In Home” warranty does not extend to the Martec Product accessories such as remote controller kits and/or light fittings (including glass light shades) that have been fitted during or after the original Martec Product installation. - Page 17 11. This warranty does not cover electrical humming noises, wobbling or any other external influences. 12. Martec Pty Ltd reserves the right to change or amend any or all parts of this warranty statement at any time and without notice.
- Page 18 NOTE: Stainless steel requires regular cleaning; “Tea Staining” is a common occurrence with all types of stainless steel. This is not considered a fault of the product and is not covered under warranty. Martec’s Precision 316, while made from Marine Grade 316 stainless steel, should only be used in a covered or enclosed outdoor environment as the fan is not hermetically sealed and will eventually rust internally.
- Page 19 I, the Customer, acknowledge that I will be liable for this charge should the authorised Martec Service Agent determine this to be the case. Failure to pay warranty recovery charges issued by Martec Pty Ltd will result in the termination of any remaining warranty, in addition to possible debt collection procedures.
