Sundara
Tide Double Basin
®
Hand Washing System
All goods sold hereunder are warranted to be free from defects in material and factory workmanship for a period of three years from the
date of purchase. Decorative finishes warranted for one year. We will replace at no costs goods that prove defective provided we are
notified in writing of such defect and the goods are returned to us prepaid at Atlanta, GA, with evidence that they have been properly
maintained and used in accordance with instructions. We shall not be responsible for any labor charges or any loss, injury or damages
whatsoever, including incidental or consequential damages. The sole and exclusive remedy shall be limited to the replacement of the
defective goods. Before installation and use, the purchaser shall determine the suitability of the product for his intended use and the
purchaser assumes all risk and liability whatever in connection therewith. Where permitted by law, the implied warranty of merchantabi-
lity is expressly excluded. If the products sold hereunder are "consumer products," the implied warranty of merchantability is limited to
a period of three years and shall be limited solely to the replacement of the defective goods. All weights stated in our catalogs and lists
are approximate and are not guaranteed.
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov
ADVERTENCIA: Cáncer y daño reproductivo - www.P65Warnings.ca.gov
AVERTISSEMENT: Cancer et effets néfastes sur la reproduction - www.P65Warnings.ca.gov
NOTE: The information in this manual is subject to change at any time without notice. Installations may
be performed at different times of construction by different individuals. For this reason, these instructions
should be left on-site with the facility or maintenance manager.
NOTE: READ ENTIRE MANUAL PRIOR TO INSTALLING PRODUCT.
ZURN INDUSTRIES, LLC 5900 Elwin Buchanan Drive, Sanford, NC U.S.A. 27330, Ph. 1-800-997-3876, Fax 919-775-3541
In Canada: ZURN INDUSTRIES LIMITED 7900 Goreway Drive, Unit 10, Brampton, Ontario L6T 5W6, Ph. 905-405-8272, Fax 905-405-1292
Rev. A
Date: 7/31/2018
C.N. No. SAN008319
Z5006.02
Sundara
Hand Washing System
Installation, Maintenance,
and Parts Manual
PATENT(S) PENDING
LIMITED WARRANTY
Prod. | Dwg. No. FV657
Tide Triple Basin
®
Advertisement
Table of Contents
Related Manuals for ZURN Sundara Z5006.02
Summary of Contents for ZURN Sundara Z5006.02
- Page 1 NOTE: READ ENTIRE MANUAL PRIOR TO INSTALLING PRODUCT. ZURN INDUSTRIES, LLC 5900 Elwin Buchanan Drive, Sanford, NC U.S.A. 27330, Ph. 1-800-997-3876, Fax 919-775-3541 In Canada: ZURN INDUSTRIES LIMITED 7900 Goreway Drive, Unit 10, Brampton, Ontario L6T 5W6, Ph. 905-405-8272, Fax 905-405-1292 Rev. A Date: 7/31/2018 C.N.
-
Page 2: Specifications
Specifications: Sundara Tide double basin lavatory system manufactured by Zurn Industries. Lavatory shall be mounted at standard height ® to conform with ANSI, UFAS, TAS and ADA Accessibility Standards. Counter and integral basin to be constructed of Sundara ®... - Page 3 Z5006.02 Parts List Item Name Basin Optional Shroud Shroud Wall Bracket Mounting (L) Bracket "Wall Hanger Bracket (Available only for Retrofit)" Solid Top Open Grid Drain Water Supply Items P Trap Assembly Sensor Faucet 10 Soap Dispenser (If Ordered) 11 "5/16-18 Screw for Mounting L Bracket to Basin"...
- Page 4 FV657 Rev. A 7/31/2018 Page 4...
-
Page 5: Required Tools
L Brackets Installation Required Tools: Allen Wrench: Torx Wrench: T10 & T25 For ease of installion, lay basin on its top surface on a cushioned surface. Use socket wrench to torque the screws (approximately 4-5 complete turns bottom out approximately 5 ft-lbs of torque). Socket Wrench: Warning: Do not overtighten the screws. - Page 6 Soap Dispenser Installation For ease of installion, lay basin on its back. Install the soap spout on right or left soap hole as applicable. Refer to soap dispenser installation guide for details. Grid Drain Installation For ease of installion, lay basin on its back. Place grid drain into drainage opening Fasten washer and nut from underside of basin FV657 Rev.
-
Page 7: Installing Mounting Bracket
Retrofitting Hanger Bracket Wall Stud Installation Plywood Wall Stud Bolt supplied by Drywall Hanger Bracket installer to attach the plywood to wall studs 1/2” Thick Hanger Bracket Plywood Recommended for retrofit: • Measure the rough in dimensions on the wall. Top edge of the cutout marked must be 2”... - Page 8 Installing with Carrier Option Z1240-EZR Carrier System Optional Waste Line Sleeve (-WL) Warning: Must be handled by at least 2 people Avertissement : s’y prendre à deux minimum. Refer to Carrier Rough-in & Installation guide for details. Soap Dispenser Bracket and Bottle Installation Refer to soap dispenser installation guide for details.
-
Page 9: Shroud Installation
P Trap Installation & Water Supply Connection to Faucet Connect the tail piece to Grid Drain (threaded connection) Then attach P-Trap to tailpiece Adjust the tail piece base on drain outlet on the wall. Shroud Installation: Step 1 Step 2 •... - Page 10 Shroud Installation: Step 3 Step 4 • Place shroud on hanger hooks of wall bracket as shown. Then, insert each clevis pin through the 2 pivot points. (Note: the shroud will likely need to be rotated upward slightly in • Re-install wall bracket with coarse screws in previous lo- order to install each pivot.
-
Page 11: Maintenance Instructions
Repair Instructions: • Zurn recommends that damages should be repaired by certified solid surface fabricator or repair agents. • Blemishes to the basin surface (such as scratches, burnmarks, and minor chipping) can be repaired by sanding with super-fine(800 or 1000 grit) sand paper and/or maroon Scotch-Brite™...
