- Page 1 User Manual Before using your scooter, please read the instructions, and keep this manual for ready reference. Original instructions...
-
Page 3: Getting Started
GETTING STARTED Thank you for choosing the INMOTION electric scooter(hereinafter referred to as the scooter)! This scooter is an intelligent high-tech entertainment product. When you use the scooter, there may be situations such as falling or collision that can cause injury and other risks. To reduce possible risks and ensure the personal and property safety of yourself and others, you have the responsibility and obligation to carefully read the user manual, fully understand all the warnings and precautions listed in this manual, and ensure that you can use it correctly. -
Page 4: Product List
PRODUCT LIST User Manual Quick Start Guide Power Cord/Adapter Headlights Mudguard Components Reflectors * 2 T-shaped Wrench M5 * 2 Reflector Stickers * 10 Combination Wrench M5×30 Hexagonal M4×8 round head M4×10 Hexagonal M8×16 Hexagon Cylindrical Head hexagon socket Cylindrical Head Socket Head Screws * 4 screw * 1... -
Page 5: Product Function Introduction
PRODUCT FUNCTION INTRODUCTION Product Diagram Dashboard Handle Assembly Throttle Twist Grip Central Control Assembly Stem Front Headlight Horn Assembly Charging Port Folding Wrench Assembly Pedal Front Motor Wheel Tail Light Disc Brake Assembly Disc Brake Assembly Front Clearance Light Rear Fender Rear Turn Signal Light Rear Motor Wheel... - Page 6 Dashboard and Buttons Left Turn Speedometer Signal Right Turn Signal Headlights Lock/Unlock Bluetooth Single/Dual Connection Motor Drive Cruise Control Trip Distance (Fault Code) Total Mileage Fault Indicater Battery Level Drive Mode Headlights Power On/Off Left Turn Signal Right Turn Signal Shift Up Shift Down cruise control [1]...
- Page 7 Product Function Introduction Icon Icon Name Lcon Description Press and hold the power button to turn on/off the scooter. It will also automatically power off if there is no activity for Power On/Off 10 minutes, which can be adjusted through the App. 0 represents the Parking mode.
-
Page 8: Error Code
ERROR CODE Front/Rear Drive Controller Malfunction Code meaning Explanation 101/201 Current sampling failure of drive controller Controller malfunction, please reboot or contact after-sales service for replacement. 102/202 Hall fault of drive motor Motor malfunction, please contact after-sales service for replacement. 109/209 Instrument did not receive data from the drive controller Communication failure, the instrument did not receive the controller data. -
Page 9: Other Faults
Other Faults Code meaning Explanation Battery communication failure Battery malfunction, please contact after-sales service for replacement. Undervoltage fault of the controller The battery voltage is too low, please charge it in time. Overvoltage fault of the controller The battery voltage is too high, please stop using it and contact after-sales service. When starting up, the brake handle is not released, please release the brake handle or Brake handle failure check the brake handle. -
Page 10: Product Specifications
PRODUCT SPECIFICATIONS Specifications Item Parameters Model Basic Specifications Overall size of the Scooter 1453 * 716 * 1320mm (default) Net Weight Approximately 58kg Max.imum Load Capacity 150kg Riding Requirements Suitable Height 150-200cm Applicable Age Ages 16-60 Normal Riding Distance Approximately 120-160km Max. -
Page 11: Product Description
RS is a high-tech entertainment product. Riding it without understanding the operating procedures may cause unpredictable injuries and property damage. The following text will provide users with detailed instructions on how to properly use RS and precautions during use. Please read carefully and use RS as required. Before using RS, make sure that all parts are intact and installed correctly. - Page 12 ASSEMBLY Screw Folding wrench Safety buckle Accessory box Open the package: Hold the handlebars and unfold the folding stem: Fasten the folding wrench: Take out the 6 connecting buckles and lift the outer Adjust the height of the stem according to the Fasten the folding wrench according to the box upwards, revealing the inner packaging and scale and lock the stem clamp.
- Page 13 2. Power on the scooter, pair your scooter with 3. Follow the App instructions to active the your account. the INMOTION App. The scooter will beep when scooter and learn how to ride safely. You can the connection is successful.
- Page 14 ADJUST THE GEARS For a better riding experience, there are four adjustable gears on the scooter, and the chassis height can be adjusted according to road conditions or personal habits. Instructions: Use two T-shaped hex wrenches to fix the screws at both ends of the connecting shaft. Rotate one screw counterclockwise to loosen it, remove the other screw from the connecting shaft, install the connecting shaft into the hole corresponding to the target gear according to your needs, and then tighten the previously loosened screw with the wrench.
- Page 15 Dimensions in folded/unfolded state 1320mm 266mm 1453mm 716mm 661mm 1453mm...
- Page 16 CHARGING • The original charger is 84V 5A. The blue LED indicates power, the green LED indicates a full charge, and the red LED indicates that the scooter is currently charging. When two chargers are used simultaneously, the charging time will be reduced by 50%. Warning: •...
- Page 17 INFLATING For a better cycling experience, please be sure to check the tire pressure before each ride. If the tire pressure is low, please pump it up in a timely manner. The ideal tire pressure range is between 2.5 to 3.5 bar. 1.
-
Page 18: Learning To Ride
LEARNING TO RIDE 1. Wear Approved helmets, elbow pads, knee 2. Check the battery indicator light after 3. Stand with one foot on the pedal and push pads, and other protective gear to minimize turning on the power. If the battery level is off with the other foot to start gliding. - Page 19 SAFE DRIVING GUIDE Do not ride the scooter in the Do not ride at high speed when Do not press the throttle when Avoid contacting obstacles and rain. you get over speedbumps, walking with the scooter. watch out for the road conditions. thresholds etc.,please ride at low speed on rough roads.
- Page 20 Do not ride on motorways, Do not rotate the handle violently Do not touch the motor, it may Do not take your handsoff the public roads, or highways. while driving at high speed. overheat after running. handlebar while riding. Do not carry any passengers Do not ride through puddles, Do not ride up and down stairs Do not use mobile phone or...
-
Page 21: Safety Notice
Appear. If any damage is caused due to insufficient rider experience or failure to use this product according to this manual, Shenzhen INMOTION Technology Co., Ltd. will not assume any responsibility. 4. Following the tips and warnings in this manual can reduce risks but cannot eliminate all risks. Please remember that when using the scooter, there may be a risk of injury or death due to loss of control, collision, and falling. -
Page 22: Riding Instructions
RIDING INSTRUCTIONS 1. When riding this product, please abide by local laws, regulations and policies. It is forbidden to use in areas prohibited by local laws and regulations and relevant management units. 2. When riding, please respect the right of way of pedestrians. Pass on the left side of pedestrians whenever possible. When facing a pedestrian, stay to the right and reduce speed. - Page 23 8. Warning! Like any mechanical component, the scooter will experience high stress and wear. Other 1. Only use original or Approved parts and accessories from INMOTION. Do not modify your scooter. Modifying your scooter may affect its operation, leading to serious damage and invalidating the warranty.
-
Page 24: Battery Maintenance
MAINTENANCE Cleaning Use a soft damp cloth to wipe the scooter frame clean. If there are stubborn stains, Apply toothpaste and brush repeatedly with a toothbrush, then clean with a soft damp cloth. Storage When not in use, please Park the scooter indoors or inside a scooter to avoid damage caused by water ingress during rainy or snowy weather. The scooter should be stored in a cool, dry place. - Page 25 • Do not ride this scooter in an environment where the ambient temperature exceeds the operating temperature of the product (see "Specifications"), as both low/high temperatures will limit the maximum power output and may cause slipping or falling, resulting in personal injury or property damage. •...
-
Page 26: Trademark And Legal Statement
4. If you provide any personal information, it is deemed that you fully agree that INMOTION can use and disclose it to affiliated companies. The use of INMOTION and affiliated companies includes but is not limited to internal employees, consultants, agents, suppliers, and partners. -
Page 27: Intellectual Property
4. This legal statement constitutes an inseparable legal part of INMOTION's products (please also forward it when reselling the product). 5. You can choose to fully accept all the terms of this legal statement to use INMOTION's products. If you use INMOTION's products, it is deemed that you agree to accept all the terms of this legal statement and bear any possible risks and responsibilities. - Page 28 INMOTION App Facebook group Website www.inmotionworld.com...
