Summary of Contents for InMotion AIR Pro
- Page 1 ORIGINAL INSTRUCTIONS E-SCOOTER USER MANUAL...
-
Page 3: Table Of Contents
Contents Safety Instructions Packing List Product Function Diagram Control Panel/Dashboard Assembling Your KickScooter First Ride Charging Learning to Ride Security Tips Folding and Carrying Specifications Maintenance Before Your Ride Safety Alerts & Error Messages Trademarks and Legal Notices Certifications Contact... -
Page 4: Safety Instructions
Please obey local traffic laws and regulations if situation is different. In places without laws comply with the safety guidelines outlined in this manual. INMOTION will not be responsible for any property damage, personal injury/death, accidents, or legal disputes caused by violations of the safety instructions. - Page 5 Do not attempt to charge your scooter if it, the charger, or the power outlet is wet. Only use the INMOTION supplied charger. Use only with FY-4202000 supply unit. Do not use a charger from any other different product models.
- Page 6 of the scooter, could result in serious injury and/or damage, and could void the limited warranty. Children should not use scooter or play with scooter parts. Cleaning and maintenance shall not be done by children without supervision. The vehicle vibration will cause the driver's body vibration while riding. Please park on flat pavement, such as on a slope, the scooter kickstand must be facing downhill to prevent capsizing.
-
Page 7: Packing List
2. Packing List User Materials User Manual Quick Start Guide Assembled E-Scooter Accessories 1*Power cable 1*Power adapter 1*Handlebars 1*M5 Wrench 1*M6 Wrench 1*Inner tube Please carefully check whether the items in the packing box are complete and intact. If there is any part missing or damaged, please contact your point of purchase or email to manufacturer. -
Page 8: Product Function Diagram
3. Product Function Diagram Dashboard Power button Throttle Head unit clip Bell Brake lever Handlebar Headlight Charging port Stem Head unit mount Taillight Plate Bracket Rear wheel Rear reflector Folding mechanism Footrest Front fork Kickstand Front mudguard Front reflector Front wheel Air valve... -
Page 9: Control Panel/Dashboard
4. Control Panel/Dashboard For drive mode For sports mode Power button: Long press for more than 2s to power on/off Speedometer Speed unit On power-on state, click once to turn on/off the headlight Battery level Light icon Double click to switch the riding mode Bluetooth icon Pedestrian mode Cruise mode... -
Page 10: Assembling Your Kickscooter
5. Assembling Your E-Scooter To avoid personal injury, please follow the instructions shown in the diagram for assembly operation and inspection. Children are not allowed to involve in assembly operations. 1. Open the package, take out the inner tray and scooter. 2. -
Page 11: First Ride
There are safety risks when learning to ride the scooter. For your safety, your new scooter is not activated and will beep occasionally after Power ON. Until activated, the scooter maintains a riding speed at 5km/h and is not allowed to switch the ride modes. Please download INMOTION App to activate your scooter to enjoy all features. INMOTION APP 1. -
Page 12: Charging
7. Charging Charger indicator light: (charging) Green (charged) Charging port 1. Open the rubber cap. 2. Insert the battery 3. Remove the battery charger plug. charger and close the rubber cap when Charging finished. • Do not charge if the charge port or power cord is wet. •... -
Page 13: Learning To Ride
8. Learning to Ride Wear an approved helmet, elbow pads, 1. Check the power level indicator after 2. Stand on the footrest with one knee pads and other protective gear to powering on. Charge the scooter if the foot and push off with another foot minimize any possible injury. -
Page 14: Security Tips
9. Security Tips Failure to follow these instructions could lead to serious injury. Do not ride the scooter in Do not ride at high speed Do not press the throttle Avoid contacting the rain. when you get over speed when walking with the obstacles and watch bumps, thresholds etc., scooter. - Page 15 Do not ride on motorways, Do not rotate the handle Do not touch the motor, it Do not take your hands public roads, or highways. violently while driving at high may overheat after running. off the handlebar while speed. riding. Do not ride through puddles, The scooter is for one rider Do not ride up and down stairs or...
-
Page 16: Folding And Carrying
10. Folding and Carrying Folding Press the locking button Press down the folding ring Wrench Stem Power off the scooter, hold the stem, press the locking button Hold the stem and pull the folding ring, attach the hook to the and pull the lever, bend the handlebar stem towards the footrest. -
Page 17: Specifications
11. Specifications Index Items Value Model C1 Pro Unfold dimensions (L x W x H) 44.3″×17.5″×20.5″ (1125×445×1200mm) Basic specs Folded dimensions (L x W x H) 44.3″×17.5″×47.2″ (1125×445×520mm) Net weight Approx. 39.0lbs (17.7kg) Max. payload 264.6lbs (120kg) Rider Recommended age 14-60 Max. - Page 18 Rating voltage 36.5V Max. Voltage Ambient temperature 0℃ - +40℃ Battery Nominal capacity 438Wh Battery management system Overheat / short circuit / overcurrent / overcharge protection Motor Rating power 400W Input voltage AC100-240V 50/60HZ Charger Output voltage DC42V Output current Front 10 inch, Air-filled low rolling resistance tire Tyre...
-
Page 19: Maintenance
12. Maintenance Cleaning Wipe the body of the electric scooter with a damp cloth. If stains persist, apply some toothpaste, brush with a toothbrush, then wipe with a damp cloth. Note When cleaning the electric scooter, make sure that it is turned off, that the charging cable is disconnected, and the rubber cap is closed, as a water leak may cause a damage to electronic components. -
Page 20: Before Your Ride
• Do not touch the battery contacts. Do not dismantle or puncture the outer casing. Avoid contact between metal objects and battery terminals to prevent short circuits, physical harm or death. • Do not throw the battery into a fire as this could damage it, cause overheating or even a fire. •... -
Page 21: Safety Alerts & Error Messages
14. Safety Alerts & Error Messages When your scooter encounters any failure, the dashboard will display the relevant fault code as shown. If the following solutions still fail to solve the problem, please ask the after-sales service for help. Error Error Solution Components... -
Page 22: Trademarks And Legal Notices
15. Trademarks and Legal Notices INMOTION is a registered trademark of INMOTION TECHNOLOGIES CO., LTD; Android, Google Play are trademarks of Google Inc., App Store is a service mark of Apple Inc., The respective owners reserve the rights of their trademarks referred to in this manual. -
Page 23: Contact
Restriction of Hazardous Substances (RoHS) Directive INMOTION TECHNOLOGIES CO., LTD. product, with included parts (cables, cords, and so on) meets the requirements of Directive 2011/65/EU on the restriction of the use of certain hazardous substances in electrical and electronic equipment ("RoHS recast" or "RoHS 2"). - Page 24 Join our Facebook group www.inmotionworld.com Version: V1.0 The manufacturer reserves the right to make changes to the product, release firmware updates, and update this manual at any time. Visit www.inmotionworld.com or check the App to download the latest user materials. You must install the App, activate your E-Scooter, and obtain the latest updates and safety instructions.
