Summary of Contents for AJA RH10MD
- Page 1 RH10MD HD Downconverter and Re-clocking Distribution Amplifier (dual-rate) R-series Card Module Published: 6/30/10 Installation and Operation Guide B e c a u s e m a t t e r s .
-
Page 2: Contacting Support
Video parts or supplies, or d) to service a product that has been modified or integrated with other products when the effect of such a modification or integration increases the time or difficulty of servicing the product. - Page 3 AJA RH10MD HD Down Converter and DA User Manual Introduction The RH10MD is a 10-bit broadcast quality HD down converter and HD-SDI distribution amplifier. Provided are 4 re-clocked HD-SDI outputs, and four down-converted SD outputs. The SD outputs can be individually configured as analog or SDI—and the analog outputs can be component or composite.
-
Page 4: Block Diagram
RH10MD Rear Panel FR1 and FR2 BNC Connector Assignments, RH10MD Card Module When the RH10MD module is installed in an AJA FR1 or FR2 frame, a corresponding group of 9 BNCs on the rear panel then provide I/O for the module. -
Page 5: User Controls
AJA RH10MD HD Down Converter and DA User Manual User Controls The user interface for configuring the RH10MD and selecting output formats is a dipswitch at the front LEDs of the card and some jumpers at the back of the card. -
Page 6: Control Functions
3 and 4 BNCs. Jumpers to Select Output Format Control Functions In addition to selecting output format, the 8-position dipswitch also controls many other configuration settings of the RH10MD card. These are described in the following table. Switch Number Description Details Analog Format... -
Page 7: Installation
AJA RH10MD HD Down Converter and DA User Manual Jumper J2 Settings Jumper J2 is located at the bottom of the card (shown in the photo below). The meaning of the jumper settings is detailled in the illustration: Jumper Between Pins 1 and 2: ON = RP215 is used to synchronize 3:2 pulldown sequence OFF = RP188 is used. -
Page 8: Specifications
Specifications Item Specification Input Formats: 1035i/1080i/1080psf/1080p/720p SMPTE 292/296, or 525/625i SMPTE 259M 23.98/24/25/50/59.94/60 Hz Frame Rates 23.98 -> 525/59.94 (3:2 pulldown) 24 -> 525/59.94 (3:2 pulldown) (drop frame) 25 -> 625/50 50 -> 625/50 59.94 -> 525/59.94 60 -> 525/59.94 (drop frame) Delay: 1 frame, audio and video Outputs:... -
Page 9: Canadian Ices Statement
AJA RH10MD HD Down Converter and DA User Manual Appendix A: Safety & Compliance Federal Communications Commission (FCC) Compliance Notices Class A This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15, Subpart B of the FCC Rules. -
Page 10: Korea Kcc Compliance Statement
Declaration of Marking by this symbol indicates compliance with the Essential Requirements of the EMC Directive of the European Union 2004/108/EC. Conformity This equipment meets the following conformance standards: Safety: CB- IEC 60065:2001 + A1:2005 NRTL - UL 60065:2003 R11.06, CSA C22.2 NO. 60065:2003 + A1:06 GS - EN 60065:2002 + A1 Additional licenses issued for specific countries available on request. -
Page 11: Taiwan Compliance Statement
AJA RH10MD HD Down Converter and DA User Manual Taiwan Compliance Statement This is a Class A product based on the standard of the Bureau of Standards, Metrology and Inspection (BSMI) CNS 13438, Class A. Japanese Compliance Statement 1. Class A ITE −... - Page 12 Warning! Do not use this device near water and clean only with a dry cloth. Avertissement! N'utilisez pas cet appareil près de l'eau et nettoyez-le seulement avec un tissu sec.. Warnung! Das Gerät nicht in der Nähe von Wasser verwenden und nur mit einem trockenen Tuch säubern.
- Page 13 AJA RH10MD HD Down Converter and DA User Manual Avertissement ! Référez-vous au personnel de service qualifié pour tout entretien. L'entretien est exigé quand l'appareil a été endommagé de quelque manière que ce soit, par exemple lorsque le cordon d'alimentation ou la prise sont endommagés, que du liquide a été versé ou des objets sont tombés dans l'appareil, que l'appareil a été...
- Page 14 ¡Advertencia! Cuando mueva la unidad desenchufe de la red eléctrica el/los cable(s) de la fuente de alimentación CA tipo brick. Advertência! Remova os cabos CA de alimentação brick da rede elétrica ao mover a unidade. Avvertenza! Scollegare il cavo dell’alimentatore quando si sposta l’unità. Warning! Ensure Mains Power is disconnected before installing the FR1 or FR2 frame R- series modules into the frame, or installing and removing options.
- Page 15 AJA RH10MD HD Down Converter and DA User Manual Caution! The FR1/FR2 front fan door is heavy and is not hinged. Remove with Caution. Attention ! La porte frontale du ventilateur de FR1/FR2 est lourde et ne repose pas sur des charnières. Retirer avec précaution.
