Installation Instructions; Remote Control - Create WIND CALM User Manual

FIX I NG THE MOUNT I NG B R ACKE T
The outlet box and joist must be securely mounted and capable of reliably supporting at
least the weight of the fan.
1. Light
2. Light intensity control
3. Fan intensity control
4. Timer
5. Batteries (2 x AAA)
6. Colour temperature control
7. ON / OFF button
8. Reverse function
• Turn on the fan by pressing the ON / OFF button
• Change air flow direction (winter/summer function) by pressing Reverse button with the fan
on. It does not work when the fan is off. The blades will stop spinning to start again in the
opposite direction just pressing the button once.
• Turn the light on and off pressing Light button.
• Pess Power levels button to increase the speed of the fan once it is on.

INSTALLATION INSTRUCTIONS

Wood
ceiling

REMOTE CONTROL

1
2
3
4
5
WIND CALM
WITH LED LIGHT
Concrete
ceiling
6
7
8
E NGLI SH
9
