OWNER'S MANUAL & OPERATING INSTRUCTIONS
2000 Max Watts / 1700 Rated Watts
2000 Max Watts / 1700 Rated Watts
PORTABLE INVERTER GENERATOR
uS Patent # D656897
Other Patents Pending
SAVE ThESE INSTRuCTIONS
Important Safety Instructions
are included in this manual.
MODEL NUMBER
73537i
MADE IN CHINA
REV 73537i-20130219
10006 Santa Fe Springs Road
Santa Fe Springs CA 90670
USA / 1-877-338-0999
www.championpowerequipment.com
Advertisement
Table of Contents
Related Manuals for Champion 73537i
Summary of Contents for Champion 73537i
- Page 1 MODEL NUMBER 73537i uS Patent # D656897 Other Patents Pending 10006 Santa Fe Springs Road SAVE ThESE INSTRuCTIONS Santa Fe Springs CA 90670 Important Safety Instructions USA / 1-877-338-0999 MADE IN CHINA are included in this manual. REV 73537i-20130219 www.championpowerequipment.com...
- Page 2 FCC Statement 1. This device complies with Part 15 of the FCC Rules. accordance with the instructions, may cause harmful Operation is subject to the following two conditions: interference to radio communications. However, there (1) This device may not cause harmful interference. is no guarantee that interference will not occur in a (2) This device must accept any interference particular installation.
-
Page 3: Table Of Contents
73537i 2000 Max Watts / 1700 Rated Watts PORTABLE INVERTER GENERATOR TABLE OF CONTENTS Introduction ...... -
Page 4: Introduction
ENGLISH INTRODuCTION Introduction Accessories Congratulations on your purchase of a Champion Power Champion Power Equipment manufactures and sells Equipment inverter generator. CPE designs and builds accessories designed to help you get the most from your generators to strict specifications. With proper use and purchase. -
Page 5: Manual Conventions
Please call our help line at 1-877-338-0999 situation which, if not avoided, could result in death or serious injury. CAuTION CAUTION indicates a potentially hazardous situation which, if not avoided, may result in minor or moderate injury. REV 73537i-20130219... -
Page 6: Safety Rules
Inform your electricity provider immediately if you or anyone in your household depends on electrical euipment to live. Inform your electrical provider immediately if a loss of power would cause you or anyone in your household to experience a medical emergency. REV 73537i-20130219... - Page 7 – Equipment vibrates excessively Operation of this equipment may create sparks that can start fires around dry vegetation. A spark arrestor may be required. The operator should contact local fire agencies for laws or regulations relating to fire prevention requirements. REV 73537i-20130219...
-
Page 8: Controls And Features
Fuel Lever Vent – Turn this valve to the “On” Maintenance Cover – Oil filler, Air filter, and position to supply air to the tank. Carburetor access. Fuel Cap – Remove to add fuel. Muffler Recoil Starter – Used to start the engine. REV 73537i-20130219... -
Page 9: Power Panel
73500i cable kit (optional equipment) is required for parallel operation. Parts Included Your 73537i Gasoline Powered Generator ships with the following parts: – 12V DC Battery Charging Cable .... -
Page 10: Assembly
The recommended oil type is 10W-30 automotive 2. Loosen the cover screw and remove the maintenance oil. cover. NOTE Check oil often during the break-in period. Refer to the Maintenance section for recommended service intervals. 3. Remove oil fill cap/dipstick to add oil. REV 73537i-20130219... -
Page 11: Add Fuel
WARNING Pouring fuel too fast through the fuel screen may result in blow back of fuel at the operator while filling. REV 73537i-20130219... -
Page 12: Operation
During operation the muffler and exhaust fumes produced will become hot. If adequate cooling and breathing space are not supplied, or if the generator is blocked or contained, temperatures can become extremely heated and may lead to fire. REV 73537i-20130219... -
Page 13: Connecting Electrical Loads
If the engine starts but does not run make certain that the generator is on a flat, level surface. The engine is equipped with a low oil sensor that will prevent the engine from running when the oil level falls below a critical threshold. REV 73537i-20130219... -
Page 14: 12V Dc Outlet
2. Plug the battery charging cable into the DC receptacle of the generator. 3. Connect the red (+) battery charger lead to the red (+) battery terminal. 4. Connect the black (–) battery charger lead to the black (–) battery terminal. 5. Start the generator. REV 73537i-20130219... -
Page 15: Do Not Overload Generator
ENGLISH OPERATION Do Not Overload Generator Parallel Operation Two Category 5 model 73537i generators can be Capacity operated in parallel to increase the total available Follow these simple steps to calculate the running and electrical power to 3000 watts. A Champion model starting watts necessary for your purposes. -
Page 16: Maintenance And Storage
8. Use the spark plug tool to fi rmly install the plug. cover screws. 9. Attach the spark plug cap to the plug. 6. Dispose of used oil at an approved waste 10. Reinstall the spark plug access cap, and management facility. maintenance cover. REV 73537i-20130219... -
Page 17: Air Filter
Use a damp cloth to clean exterior surfaces of the engine. Failure to clean the spark arrester will result in Use a soft bristle brush to remove dirt and oil. degraded engine performance. Use an air compressor (25 PSI) to clear dirt and debris from the engine. REV 73537i-20130219... -
Page 18: Adjustments
Contact our help line at 1-877-338-0999 to locate the Use a damp cloth to clean exterior surfaces of the generator. nearest Champion Power Equipment certified service Use a soft bristle brush to remove dirt and oil. dealer for your generator or engine maintenance needs. - Page 19 – When storing the generator for short or extended periods of time make sure that the Engine Switch and the Fuel Valve are set in the OFF position. REV 73537i-20130219...
-
Page 20: Specifications
......120 V Your Champion Power Equipment product is designed – Phase ...... -
Page 21: Wiring Diagram
73537i ENGLISH SPECIFICATIONS Wiring Diagram REV 73537i-20130219... -
Page 22: Parts Diagram
73537i ENGLISH SPECIFICATIONS Parts Diagram REV 73537i-20130219... -
Page 23: Parts List
Connect Port Mounting Rubber, End 81.200602.00 Bolt And Washer Cover 1.9074.4.0210.3 Assembly M2×10 81.200603.00 Mounting Rubber, Engine Bolt And Washer 1.9074.4.0414.3 2.05.050 Wire ClipΦ100Φ Assembly M4×14 122.190600.00 Rectifier 5.1130.001 Receptacle 1.5783.0520 Bolt M5×20 81.210200.00 Toroid Coil, complete 1.97.1.04.3 WasherΦ4 REV 73537i-20130219... -
Page 24: Engine Parts Diagram
73537i ENGLISH SPECIFICATIONS Engine Parts Diagram REV 73537i-20130219... -
Page 25: Engine Parts List
81.081300.00 81.130008.00 Connecter, Choke Valve Axis Right 81.130006.00 Brace, Support Plate Muffler Protector Assembly 81.081200.00 Middle 81.090005.00 Clamp Board, Air Filter Tube 1.6175.06.3 Nut M6 81.091000.00 Air Cleaner Assembly 81.101100.00 Muffler Assembly 81.101000.00 Muffler Assembly 81.100001.00 Gasket, Exhaust REV 73537i-20130219... -
Page 26: Troubleshooting
Review load and adjust. See “Power Management” Faulty cords or device Check for damaged, bare or frayed wires. Replace defective device For further technical support: Technical Service Mon – Fri 8:30 AM – 5:00 PM (PST/PDT) Toll Free: 1-877-338-0999 tech@championpowerequipment.com REV 73537i-20130219... -
Page 27: Warranty
Warranty Qualifications Other Exclusions Champion Power Equipment (CPE) will register this This warranty excludes: warranty upon receipt of your Warranty Registration Card – Cosmetic defects such as paint, decals, etc. - Page 28 The United States Environment Protection Agency (U.S. EPA.) and the California Air Resources Board (CARB) Emission Control System Warranty Your Champion Power Equipment (CPE) engine complies with both the U.S. EPA and state of California Air Resources Board (CARB) emission regulations.
- Page 29 EMISSION CONTROL SYSTEM WARRANTY The following are specific provisions relative to your Emission Control System (ECS) Warranty Coverage. 1. APPLICABILITY: This warranty shall apply to 1995 and later model year California small off-road engines (for other states, 1997 and later model year engines). The ECS Warranty Period shall begin on the date the new engine or equipment is delivered to its original, end-use purchaser, and shall continue for 24 consecutive months thereafter.
- Page 30 You must take your CPE engine or the product on which it is installed, along with your warranty registration card or other proof of original purchase date, at your expense, to any Champion Power Equipment dealer who is authorized by Champion Power Equipment, Inc. to sell and service that CPE product during his normal business hours.
