Rose electronics RE2-1R2X16U Specifications

UltraMatrix Remote

Features and Benefits

Connect to remote computers locally or over IP
Video resolution up to 1280 x 1024
Security system with login, computer access control and
data encryption. Two choices of encryption are available,
128 bit Blowfish or 64 bit triple DES
Powerful and expandable to 1,000 computers.
BIOS-level access control, local or remote
Scaling, scrolling, auto-size, and quad screen features
Pull-down menus allow you to easily switch to servers by
location and name
Single mouse cursor system allows easy switching
between your local workstation and the remote computer
Serial VT220 terminal emulation for access to UNIX hosts,
routers, and other supported serial devices (Multi-
Platform models)
Multi-lingual menu (English, French, German, Spanish,
Italian, and Portuguese)
Status screen shows current connections, computer
power, plus additional information
Supports PS/2, PS/2 wheel, USB, and Sun
Supports HV sync, composite sync, and sync-on-green
video
Serial access for computer switching, unit configuration,
flash memory upgrades and
reset to factory defaults
Up to 4 local user and 4 remote user
Free firmware upgrades for product
enhancements and new software
features available at www.rose.com
Rack mount kits available in 19", 23", and
24" sizes
Made in USA
Matrix KVM switch with integrated
remote access over IP
System-wide connectivity locally or over IP from any
location worldwide
Connects 1,000 computers to Multiple user stations
High quality video up to 1280 x 1024
Secure encrypted operation with login and computer
access control
PC only and Multi-Platform models available
Multi-Platform design makes it compatible with PCs,
Sun, UNIX, Linux, USB, and serial devices
View 4 connections real time in the Quad screen
mode
The UltraMatrix™ Remote Advantage
The UltraMatrix Remote represents the next generation
in KVM switches. It not only provides a comprehensive
solution for remote server console access with Bios-level
access control, this access can be local or from any
workstation on your network over IP worldwide.
The powerful, advanced on-screen menu can be used to
configure the unit, name the computers, and much more.
When accessing a computer over your network, the
Viewer application receives and displays the video and
sends back keyboard and mouse data. This process
allows you to access the remote computers from
anywhere, locally, across your network, or around the
world.
The UltraMatrix Remote can easily be expanded to other
KVM switches to make a seamless and truly scalable
KVM matrix switch. Network communication technology
is used to reduce cost, eliminate single points of failure,
and increase reliability.
The Viewer program is designed to simplify access to the
remote computers. Once connected you will see a crisp,
clear, high-quality image of the remote computer. Your
keyboard and mouse now control the remote computer.
The UltraMatrix Remote uses flash memory
technology. Upgrades and product
enhancements are easily done by obtaining
unit specific firmware from our web site at
www.rose.com.
Quad screen view
