VideoSplitter CAT5

Features and Benefits

Extends a single video source to 6 or 12 video
monitors using CAT5 twisted pair, solid core cables
(Up to 1,000 feet)
Serial and Full stereo audio (optional)
Video resolutions up to:
1600 x 1200 at 200 feet,
1280 x 1024 at 300 feet,
1024 x 768 at 1,000 feet
(Video resolution will vary depending
on the remote unit model used)
Easy to install
Rack mountable chassis
Video splitter over CAT5 cable
Splits, amplifies, and extends video from a single
video source to 6 or 12 monitors simultaneously
over CAT5 cable
Video resolutions up to 1600 x 1200
Each remote monitor can be up to 1,000 feet away
using industry standard CAT5 UTP cable
Optional Audio and Serial
The VideoSplitter™ CAT5 Advantage
The VideoSplitter CAT5 is the extender of choice for
businesses big and small that need to take a single
video source and extend it to remote monitors. The
serial/audio model takes a serial signal and full stereo
signal and distributes it to remote stations.
VideoSplitter CAT5 allows you to position 6 or 12
video monitors, speakers, and serial device (optional
serial and audio) up to 1,000 feet away from the
source using common twisted pair CAT5 cable. Each
of the modules connects to a CrystalView remote unit.
The VideoSplitter CAT5 is designed for plug-and-play
operation. First, connect the computer video (serial
and audio optional) to the local unit. Next, route the
CAT5 cable between the local and remote units.
Finally, connect the keyboard, monitor, and mouse
(serial and audio optional) to the remote unit. Now it is
ready to use.
Presentations, slide shows, schedules, and other
types of common information can be centrally
generated and displayed simultaneously on all remote
monitors. The serial and audio models can distribute
these signals to the remote stations.
Standard CAT5 connectors
W W W . R O S E . C O M
