If the Geberit sanitary flush in concealed cistern
is linked to the building service management
EN
system via the RS485 or digital I/O interfaces, it
is not necessary to program the flushing
parameters. The sanitary flush in concealed
cistern will be fully controlled by the building
service management system.
Display of operating state
The control unit of the Geberit sanitary flush in
concealed cistern displays the following operating
states:
Table 1:
Element
Green LED
Red LED
1)
Buzzer
Operating states
Status
Short flash
pulse
Long flash
pulse
On
Off
On
Flashing
Off
2)
On
Off
Meaning
Normal operation,
operating voltage on
Normal operation,
Bluetooth® interface
active
Solenoid valve open
Operating voltage off
Malfunction, diagnose
with Geberit SetApp
Warning, diagnose
with Geberit SetApp
Normal operation
Malfunction, diagnose
with Geberit SetApp
Normal operation or
buzzer deactivated
