1MRS758456 H
4.4
4.5
ARG600 Single SIM Variant
User Manual
If the functional mode of the Ethernet port is set to "WAN" or "VLAN", the
following details must be noted. Before changing the Ethernet port mode to
"WAN", the firewall configuration needs to allow Web UI and SSH access from
WAN (Firewall/General and enable both Allow WebUI access from WAN and
Allow SSH access from WAN). The VLAN functional mode of the Ethernet port
requires an external VLAN switch.
Configuring mobile WAN
Install the SIM card before configuring the mobile WAN.
1.
In the left pane, under Network, click Mobile WAN.
2.
Enter the preferred configuration in the configuration fields.
3.
Click Submit to save the settings.
Configuring the default route
1.
In the left pane, under Network, click WAN Failover.
2.
Set WAN Default Route to Yes.
This setting enables the use of the Ethernet WAN or the Mobile WAN as the
default route interface.
3.
If configuring Ethernet WAN as the default gateway, in the left pane under
Network, click Ethernet Port and set Port function to WAN.
If configuring Mobile WAN as the default gateway, skip this step.
4.
Set the default route.
•
To select Ethernet WAN as the default gateway, under Primary WAN,
set Interface to Ethernet WAN.
•
To select Mobile WAN as the default gateway, under Primary WAN,
set Interface to Mobile WAN.
5.
If both Ethernet WAN and Mobile WAN are configured, under Backup
WAN, set Interface to Mobile WAN or Ethernet WAN, whichever is not
selected as the default gateway.
If the primary WAN interface comes down, the device automatically switches
the default route to the backup WAN interface.
6.
Click Submit to save the settings.
7.
Restart the device.
Section 4
Getting started
23
