Using the UA-1X

Listening to Sound from Your Computer

As shown in the diagram, you can connect headphones or monitor speakers,
and monitor the playback sound from your application or the sound from the
instrument or audio device to which the UA-1X is connected.
fig.07-01
Computer
USB
connector
Set the desired sampling frequency for recording in the application being used for recording,
then proceed with recording. Available sampling frequencies vary depending on the operating
system used.
fig.table
OS
Mac OS 9/X
Windows 98 SE/
Windows Me/
Windows 2000/XP
10
Stereo set,
Monitor speakers, etc.
External Input jacks
(LINE IN, AUX IN)
Signal flow
Frequency
32 kHz 44.1kHz
✕
✕
❍ ❍
Signal flow
Audio Cable
48 kHz
❍
❍
OUTPUT
Stereo
Headphones
