RSA Lighting QCT2075 Specification

DESCRIPTION
4" round recessed trimless adjustable truncated cone fixture. For use
with 12V MR16 lamp 71W max. or CMHMR16 20W or 39W.
For use in downlighting / accent applications.
SPECIFICATION FEATURES
A ...Trimless Fixture
Round adjustable truncated cone
trimless fixture. Includes bullet plunger
retainers for smooth snap-in action
during installation and removal of trim for
relamping. Helps guard against plaster
cracking.
B ...Lamp
For use with 12V MR16 lamp 71W max.
or CMH MR16 20W or 39W. Lamp not
included. 12V MR16 fixture includes clear
protective glass lens and can accept up
to three (3) optical accessories total.
C ...Socket
Posi-Grip bi-pin socket for 12V MR16.
GX10 for metal halide lamps. (Included
with Quiet Ceiling Housing sold
separately)
D ...Reflector
Etched aluminum reflector is cut at a 35˚
angle.
E ...Finish
Trim face is powder coated in white,
black, industrial silver, stainless
steel or primer finish for painting in
existing ceiling color. All other internal
components are flat black.
F....Safety
Steel safety cable provided. Attaches
to tab inside housing to prevent falling
during maintenance or as a result of
accidental dislodging of the trim.
ORDERING INFORMATION
QCT2075
Fixture Finish
QCT2075 =
WH
4" Round Trimless
BK
Adjustable Truncated Cone
S
Fixture for 12V MR16 or CMH
SS
MR16
PM
www.cooperlighting.com
D
A
4.00"
DIA.
White
=
Black
=
Industrial Silver
=
Stainless Steel (painted)
=
Primer
=
Specifications and Dimensions subject to change without notice.
RSA Lighting • 7945 Orion Ave. • Van Nuys, CA 91406 • 818-349-3030 • FAX 818-349- 3031
Catalog #
Project
Comments
Prepared by
Ceiling mudding compound is applied
right to the edge of the fixture.
• 12V MR16 71W max.
• CMH MR16 20W or 39W
C
B
+/- 15º
QUIET CEILING
4" Round Trimless
F
Recessed Truncated
QCT904RM / QCT904RMMH
QCT906SP / QCT906SPMH
3.00"
DIA.
Type
Date
TRIMLESS
QCT2075
Cone Fixture
FOR 12V MR16 71W max.
CMH MR16 20W or 39W
Compatible Housings:
QCT900 / QCT900MH
QCT902IC / QCT902ICMH
rev 030108
