Hardware Installation and Reference Guide
1 Product Overview
The RG-S6980-64QC is a next-generation core switch, providing 400GE access, low latency, and comprehensive data
center features. It has 64 x 400GE ports. The RG-S6980-64QC can be used with access and aggregation switches to build
a high-performance and reliable data center network.
The RG-S6980-64QC has one model.
400GE QSFPDD
Model
RG-S6980-64QC
The QSFPDD port supports the 400GE/100GE mode.
1.1 RG-S6980-64QC
Specifications
Model
RG-S6980-64QC
CPU
Intel Xeon D-1627: 4-core 8-thread processor with a clock speed of
BootROM
16 MB
SSD
240 GB
SDRAM
DDR4 8 GB (compatibility with 16 GB)
Expansion
Not supported
Module Slots
8 (7+1 redundancy)
Fan Module Slots
At least seven fan modules are required.
Fan Module
M2EFAN II-F
Power
Module
4 (2+2 redundancy)
Slot
Power Module
RG-PA1200I-F
AC input:
Rated voltage range: 100 V AC to 127 V AC
Frequency: 50 Hz to 60 Hz
Power Input
Maximum input current: 12 A
Rated voltage range: 200 V AC to 240 V AC
Frequency: 50 Hz to 60 Hz
Maximum input current: 8 A
Power
Maximum: 2524 W
Consumption
Typical: 1760 W
See Appendix B.
SFP Module
SFP28 Port
Not supported
100GE QSFP28
Ports
Ports
64
N/A
The module types may update without prior notification. Contact Ruijie Networks for details.
10GE SFP+
Ports
Module Slots
N/A
HVDC input:
Rated voltage: 240 V DC
Rated current: 6.5 A
- 1 -
Product Overview
Expansion
Redundan
t Fans
N/A
7+1
2.9 GHz
RPS
2+2
