Troubleshootin - Ego Power+ ZERO TURN Z6 Instructions Manual

NOTE: If a fault code appears on LCD screen, remove all battery packs and re-insert them a few minutes
later. If this doesn't solve the problem, follow the fault code troubleshooting below.
LCD
Description
Display
Seat sensor icon shows on
the LCD
PTO Switch icon blinks
Energy regeneration icon
blinks occasionally.
CCS icon blinks
Fault
Mower
Beeper
Cod
Status
e on
Indicator
LCD
n/a OFF No
n/a OFF No
n/a OFF No
n/a OFF No
ZERO TURN RIDE-ON MOWER — ZT4200E-S
Cause Solution
If with the operator is
seated on the seat
and the icon is on,
The operator
stop operating the
leaves the seat
mower immediately
or the seat safety
and check the seat
interlock system
connection. If the seat
is disconnected.
connection with the
mower is confirmed
correct, please contact
a qualified service
technician for repairs.
Before restarting the
The blade motor mower, push the
was interrupted in
PTO switch down
operation and the
to turn off the blade
PTO switch is not motors. Please see
set to off position.

"TROUBLESHOOTIN

G"
section in this manual
for reference.
The kinetic
energy generated
This is normal
during braking or
operation. No action is
driving downhill is
needed.
converted into
electricity to
charge the battery
packs.
The CCS function could
The CCS
not be set when the
(cruise control
mower is driving at very
system)
low speed or is driving
function has
in reverse.
failed.
