KNOW THE LCD SCREEN (Fig. A2)
Refer to the section "MOWER STATUS
REFERENCE & FAULT CODE" for more information
about the icons and indicators on the LCD screen.
1. Reverse Icon
2. CCS Icon
3. Safety Key Icon
4. LED Lights Icon
5. Auto-Parking Icon
6. USB Icon
7. Blade Speed Indicator
8. Safety Device Status Indicator
9. Hour Meter
10.Vacant Battery Compartment Icon
11.Temperature Icon
12.Occupied Battery Compartment Icon
13.Driving Mode
14.Fault Code Indicator
15.Overload Indicator
16.Low Power Indicator
17.Fuel Gauge
18.Load Indicator
19.Driving Speed Indicator
UNPACKING
NOTICE: Save the packing materials until you
have carefully inspected and satisfactorily
operated the product. If any parts in packing list
assembled on the machine please instantly
contact EGO service.
NOTICE:: Except the tools in below packing list, all
other tools mentioned in the manuals are just
recommended but not provided.
NOTICE:: Do not remove the foam block under
the steering wheel before the steering wheel is
properly installed. Vibration during moving may
cause the damage to the steering wheel.
PACKING LIST
(Fig. B)
Zero Turn Ride-On
B-1
Mower
B-3 Mulching Plug
B-5 Allen Key
B-7 Open-End Wrench B-8
Wash-Port Quick
B-9
Coupler
ASSEMBLY
INSTALLING THE SEAT (Fig. C1 – C4)
WARNING: The safety interlock system must not
be disconnected or bypassed. Doing so could cause
the mower to operate unexpectedly, resulting in
personal injury.
NOTICE: For your safety, the mower may stop
driving as the seat switch got disconnect during
driving. In this case, please refer to the section
"TROUBLESHOOTING" for more information.
C1-1 Socket
C1-3 Cable
C2-2 Suspension Base C2-3 Allen Key
Socket-Head
C2-4
Screws
C3-1 Steel Rails
Socket-Head
C3-3
Screws
INSTALLING THE STEERING
WHEEL (Fig. C5 – C6)
C5-1 Locking Bolt
C6-1 Locating Block
C6-3 Steering Wheel Protector
ZERO TURN RIDE-ON MOWER — ZT4200E-S
B-2 Seat
Socket-Head
Screws (2 for
B-4
backup)
B-6 Socket Wrench
Safety Keys
B-10 Operator's Manual
C1-2 Plug
C2-1 Seat Arm
Seat Position
C2-5
Adjustment Lever
C3-2 Allen Key
C4-1 Hook
C5-2 Bar
C6-2 Slot
