H E A T I N G
USER GUIDE
VOGUE MAX SYSTEM
15IE 18IE 26IE 32IE
When replacing any part on this appliance, use only spare parts that you can be assured conform to the safety and
performance specification that we require. Do not use reconditioned or copy parts that have not been clearly authorised
by Ideal Heating.
For the very latest copy of literature for specification and maintenance practices visit our website idealheating.com
where you can download the relevant information in PDF format.
August 2021
UIN 223446 A02
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Ideal Heating VOGUE MAX SYSTEM 26IE
Summary of Contents for Ideal Heating VOGUE MAX SYSTEM 26IE
- Page 1 When replacing any part on this appliance, use only spare parts that you can be assured conform to the safety and performance specification that we require. Do not use reconditioned or copy parts that have not been clearly authorised by Ideal Heating. For the very latest copy of literature for specification and maintenance practices visit our website idealheating.com where you can download the relevant information in PDF format.
- Page 3 VOGUE MAX SYSTEM IE Natural Gas only 15 IE G.C. Appliance No. 41-796-57 18 IE G.C. Appliance No. 41-796-58 26 IE G.C. Appliance No. 41-796-59 32 IE G.C. Appliance No. 41-796-60 All Gas Safe Register installers carry a Gas Safe Register ID card, and have a registration number. Both should be recorded in the Benchmark Commissioning Checklist.
- Page 4 FOR ANY QUERIES PLEASE RING THE IDEAL CONSUMER HELPLINE : 00353 (0)1 961 7700 NOTE. BOILER RESTART PROCEDURE - To restart the boiler, press “RESTART” hot key located below the colour screen. The appliance will now repeat the ignition sequence if a heat demand is present. INTRODUCTION The Vogue Max System IE is a wall mounted, room sealed, condensing system boiler, featuring full sequence automatic spark ignition and fan assisted combustion.
-
Page 5: Important Notes
IMPORTANT NOTES • This appliance must not be operated without the casing correctly fitted and forming an adequate seal. • If the boiler is installed in a compartment then the compartment MUST NOT be used for storage purposes. • If it is known or suspected that a fault exists on the boiler then it MUST NOT BE USED until the fault has been corrected by a Gas Safe Registered Engineer or in IE a Registered Gas Installer (RGII). -
Page 6: Boiler Controls
BOILER CONTROLS Legend A. Boiler Status C. Hot Keys E. On / Off Control G. Hot Key Identification Text B. Burner On indication D. Central Heating Temp. Control F. Pressure Gauge H. Central Heating Status READY 39°C TIMER OR ROOM THERMOSTAT OFF C TO CYLINDER MENU... -
Page 7: Ignition Lockout
TO LIGHT THE BOILER. (REFER TO BOILER OPERATION CONTROLS) Central Heating Switch ON electricity to the boiler and check that all With the external heating controls calling for heat, the “off/on” external controls, e.g. programmer and room thermostat, control (E) set to ‘on’ and the Central Heating Temperature are ON. -
Page 8: Overheat Lockout
WEATHER COMPENSATION TO SHUT DOWN THE BOILER Set the off/on switch (E) to “off”. When the Weather Compensation option is fitted to the system then the Central Heating Temperature Control (D) becomes TO RESTART THE BOILER a method of controlling room temperature. Turn the Central Repeat the procedure detailed in ‘To light the boiler’... -
Page 9: Loss Of System Water Pressure
LOSS OF SYSTEM WATER PRESSURE The gauge (F) indicates the central heating system pressure. If the pressure is seen to fall below the original installation pressure of 1.0 & 1.5 bar and the above screen is displayed then conduct the re-pressurising procedure as follows: Re-pressurise via the filling loop to between 1.0 &... -
Page 10: Condensate Drain
CONDENSATE DRAIN To unblock a frozen condensate pipe; This appliance is fitted with a siphonic condensate trap system that reduces the risk of the appliance condensate 1. Follow the routing of the plastic pipe from its exit point on from freezing. However should the condensate pipe to this the appliance, through its route to its termination point. -
Page 11: Escape Of Gas
ESCAPE OF GAS MAINTENANCE Should a gas leak or fault be suspected contact the National The appliance should be serviced at least once a year by Gas Emergency Service without delay. Tel. 1850 20 50 50 a Gas Safe Registered Engineer or in IE a Registered Gas Installer (RGII). -
Page 12: Points For The Boiler User
POINTS FOR THE BOILER USER Note. In line with our current warranty policy we would ask that you check through the following guide to identify any problems external to the boiler prior to requesting a service engineer’s visit. Should the problem be found to be other than with the appliance we reserve the right to levy a charge for the visit, or for any pre-arranged visit where access is not gained by the engineer. -
Page 13: Fault Finding
FAULT FINDING If a fault occurs then a fault description and suggested potential corrective actions will be displayed. In addition the following information may be useful. Hot water works OK but no Ensure that the timer and Room Stat are switched on. Check batteries in central heating programmable room stats. - Page 14 DISPLAY FUNCTIONS (WITHOUT OUTSIDE SENOR) Indicates that the Boiler is Switched Off. Indicates that the boiler is either heating the radiators or Move off/on switch to the “on” position to switch the boiler on. the hot water cylinder. MENU MENU Indicates that either the timer is off or the room stat and cylinder stats are satisfied.
- Page 15 DISPLAY MESSAGES (WITH OUTSIDE SENSOR) Indicates that the boiler is switched off. Move off/on switch (E) Indicates that boiler Boiler is providing to the “on” position to switch the boiler on. is heating the hot central heating and water cylinder to 60ºC radiator temp is 60ºC.
- Page 16 DISPLAY MESSAGES (GENERAL) Indicates that the temperature at the boiler is less than 5ºC and the boiler is running to protect itself from frost damage. BOILER FROST PROTECTION ACTIVE SWITCH OFF TEMPERATURE 19 MENU Indicates that a service is due. To reset the service time, refer to page 19.
- Page 17 CHANGE SETTINGS (BASIC) To change the maximum boiler temperature, rotate the boiler To disable Central Heating frost protection turn the On/Off temperature control (D). This screen will be shown: switch (E) to the Off position. This screen will be shown: SELECT MAXIMUM BOILER TEMPERATURE EXIT MENU...
-
Page 18: Menu Operation
MENU OPERATION Efficiency Level Press select and a screen similar to the following To view the efficiency level of the boiler press MENU will be displayed; and the following screen will be displayed; MENU EFFICIENCY LEVEL SHOW EFFICIENCY LEVEL SERVICE COMPANY NAME SERVICE COMPANY PHONE NUMBER EXIT SELECT... - Page 19 Reset Service Time If the boiler has not been serviced within the last 12 months, a Press SELECT and the following screen is displayed; message will be displayed indicating this. To reset the timing of this message, following a boiler service press MENU and the following screen will be displayed;...
- Page 20 WEEE DIRECTIVE 2012/19/EU Waste Electrical and Electronic Equipment Directive • At the end of the product life, dispose of the packaging and product in a corresponding recycle centre. • Do not dispose of the unit with the usual domestic refuse. FM 59915 •...
