INSTALLATION
& SERVICING
When replacing any part on this appliance, use only spare parts that you can be assured conform to the safety and performance
specification that we require. Do not use reconditioned or copy parts that have not been clearly authorised by Ideal Heating.
For the very latest copy of literature for specification and maintenance practices visit our website idealheating.com
where you can download the relevant information in PDF format.
August 2021
UIN 223443 A03
VOGUE MAX SYSTEM
15IE 18IE 26IE 32IE

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VOGUE MAX SYSTEM 15IE and is the answer not in the manual?

Questions and answers

Related Manuals for Ideal Heating VOGUE MAX SYSTEM 15IE

Summary of Contents for Ideal Heating VOGUE MAX SYSTEM 15IE

  • Page 1 When replacing any part on this appliance, use only spare parts that you can be assured conform to the safety and performance specification that we require. Do not use reconditioned or copy parts that have not been clearly authorised by Ideal Heating.
  • Page 2 ERP DATA MODEL SYMBOL UNITS 15 IE 18 IE 26 IE 32 IE Condensing Boiler Low Temperature Boiler B1 Boiler Cogeneration Space Heater Equipped with a Supplementary Heater Combination Heater Nominal Heat Output for Space Heating Full Load Part Load 10.5 Auxiliary Electricity Consumption Full Load...
  • Page 3 PRODUCT FICHE VOGUE MAX SYSTEM IE BOILER Ideal Heating ERP DATA SYMBOL UNITS MODEL 15 IE 18 IE 26 IE 32 IE Condensing boiler Seasonal Space heating efficiency class Rated heat output ƞ Seasonal space heating energy efficiency Annual energy consumption...
  • Page 4 Installation and Servicing...
  • Page 5 Relevant Installation changes implemented in this book from Mod Level ..A02 (Nov 20) to A03 (Aug 21) Rebrand and legislation update Page 80 - Added: WEEE Directive logo. Rebrand update throughout from Ideal Boilers to Ideal Heating. Ideal Heating reserve the right to vary specification without notice Installation and Servicing...
  • Page 6 Installation and Servicing...

  • Page 7: Table Of Contents

    CONTENTS GENERAL ..............10 SERVICING ............... 45 Introduction ..............10 Servicing Schedule ............ 45 Operation ..............10 Boiler Front Panel Removal / Replacement ....46 Safe Handling ............. 10 Lowering Controls Panel/Accessing Mains Wiring ..46 Optional Extra Kits ............. 10 Fan And Venturi Assembly Removal And Cleaning ..

  • Page 8: General

    SECTION 1 - GENERAL Table 1 - General Data 15 IE 18 IE 26 IE 32 IE Gas Supply 2H-G20-20mbar 3P-G31-37mbar Gas Supply Connection 22mm copper compression Injector Size 3.40 3.35 4.30 4.80 Flow Connection Central Heating 22mm copper compression Return Connection Central Heating 22mm copper compression...
  • Page 9 SECTION 1 - GENERAL VOGUE MAX SYSTEM IE Natural Gas only Boiler size G.C. Appliance No. (Benchmark No.) 15 IE 41-796-57 18 IE 41-796-58 26 IE 41-796-59 32 IE 41-796-60 Destination Country: GB, IE For GB, to comply with Building Regulations Part L1 (Part 6 in Scotland) the boiler should be fitted in accordance with the manufacturer’s instructions.

  • Page 10: Introduction

    Use personal protective equipment as appropriate, e.g. these Installation and Servicing Instructions or as otherwise gloves, safety footwear. recommended by Ideal Heating in writing. If in doubt please During all manoeuvres and handling actions, every attempt enquire. should be made to ensure the following unless unavoidable and/ or the weight is light.

  • Page 11: Location Of Boiler

    SECTION 1 - GENERAL 1.7 LOCATION OF BOILER 1.8 GAS SUPPLY The boiler must be installed on a flat and vertical internal wall, The local gas supplier should be consulted, at the installation planning stage, in order to establish the availability of an capable of adequately supporting the weight of the boiler and any adequate supply of gas.

  • Page 12: Terminal

    SECTION 1 - GENERAL 4. Where the lowest part of the terminal is fitted less than 2m 1.10 TERMINAL (6’6”) above a balcony, above ground or above a flat roof The terminal assembly can be adapted to accommodate various to which people have access then the terminal MUST be wall thicknesses.

  • Page 13: Boiler Dimensions, Services & Clearances

    SECTION 1 - GENERAL all dimensions in mm 1.16 BOILER DIMENSIONS, SERVICES & CLEARANCES The boiler connections are made on the boiler connection tails. Refer to Section 2.15. into which the boiler is going to be installed is less than the length of flue required the flue must be fitted from the The following minimum clearances must be maintained for operation and servicing.

  • Page 14: System Requirements

    SECTION 1 - GENERAL 1.17 SYSTEM REQUIREMENTS Central Heating Notes Pressure relief valve setting bar a. The method of filling, refilling, topping up or flushing sealed primary hot water circuits from the mains via a temporary hose connection Vessel charge pressure 0.5 to 0.75 is only allowed if acceptable to the local water authority.

  • Page 15: System Balancing

    Benchmark Guidance Notes on Water Treatment in Central Scalemaster Water Treatment Products Heating Systems. Emerald Way, Stone, Staffordshire ST15 0SR If water treatment is used Ideal Heating recommend only the Tel: +44 (0) 1785 811636 use of SCALEMASTER SM-1 PRO, FERNOX, MBI, ADEY MC1 Calmag Ltd.

  • Page 16: Installation

    SECTION 2 - INSTALLATION 2.1 BOILER ASSEMBLY - Exploded View Note that item numbers are linked to the spares list 104 CH Return Valve 127 Pressure Gauge 214 Siphon trap 318 Control Box Lid 105 CH Flow Valve 131 CH Water Pressure Sensor 217 Gas Cock 319 Programmer Blank Insert 108 Pump Head...

  • Page 17: Unpacking

    SECTION 2 - INSTALLATION 2.2 UNPACKING The boiler is supplied fully assembled in Pack A. A telescopic or non-telescopic flue assembly for rear or side flue outlet, in Pack B is supplied as a separate order. Unpack and check the contents. Pack A Contents Boiler Hardware Pack Box...

  • Page 18: Front Panel Removal

    SECTION 2 - INSTALLATION UNPACKING CONT’D Note. This flue system incorporates a removable flue outlet nose that utilises a push fit location system. This enables the installation of deflector, high level or balcony outlet flue kits without the removal of the whole ‘B’ pack terminal. The appliance must not be operated without the desired outlet nose correctly fitted in place.

  • Page 19: Wall Mounting Template

    SECTION 2 - INSTALLATION 2.4 WALL MOUNTING TEMPLATE Extended centre line The wall mounting template is located on the internal protective 131(or 176) packaging. The template shows the position of the fixing and rear flue centre holes for a standard installation V - See Diagram Below Care MUST be taken to ensure the correct holes are drilled.

  • Page 20: Determining The Flue Length & Flue Packs Req'd

    SECTION 2 - INSTALLATION 2.8 DETERMINING THE FLUE LENGTH AND FLUE PACKS REQUIRED IMPORTANT. The boiler must be installed in a vertical position in accordance to the installation instructions. FLUE KITS Telescopic Flue‘B’ Pack - contains: Flue turret, telescopic flue incorporating a terminal, rubber wall seal and instructions Horizontal Flue Terminal (600mm long) ‘B’...
  • Page 21 SECTION 2 - INSTALLATION DETERMINING THE FLUE LENGTH AND FLUE PACKS REQUIRED, CONT’D Edge of turret Edge of turret Edge of turret FIGURE 1 to outside face of wall plus to outside face of wall plus to outside face of wall plus 44mm = ue length 44mm = ue length 44mm = ue length...

  • Page 22: Cutting & Setting The Flue Length

    SECTION 2 - INSTALLATION 2.9 CUTTING & SETTING THE FLUE LENGTH TELESCOPIC FLUES TELESCOPIC FLUE B PACK SHOULD ONLY BE ADJUSTED FOR USE WITHIN ITS SPECIFIED RANGE AND MUST NOT BE CUT HORIZONTAL FLUE TERMINAL (1000MM LONG) B PACK (TELESCOPIC) MUST ONLY BE CUT IF REQUIRED FLUE LENGTHS ARE BETWEEN 602 &...

  • Page 23: Installing The Flue

    SECTION 2 - INSTALLATION 2.10 INSTALLING THE FLUE FITTING FLUE THROUGH THE WALL 1. Measure wall thickness and add 14mm. 2. Measure from the outer terminal lip towards outer flue, place a small location mark at the dimension acquired at point 1. 3.

  • Page 24: Condensate Drain

    SECTION 2 - INSTALLATION 2.11 CONDENSATE DRAIN Condensate Pump Condensate Drain Where gravity discharge to an internal termination is not physically possible or where very long internal pipe runs would be required Condensate Drain to reach a suitable discharge point, a condensate pump of a specification recommended by the boiler or pump manufacturer should be used terminating into a suitable internal foul water discharge point such as an internal soil and vent stack or internal...
  • Page 25 SECTION 2 - INSTALLATION CONDENSATE DRAIN - CONT’D Figure 3 - Connection of a Condensate Pump Typical Figure 4 - Connection of condensate Drainage Pipe to Method (see manufacturer’s detailed instructions) External Soil & Vent Stack Boiler Water/weather Visible air break with 75mm proof insulation Boiler...

  • Page 26: Fitting The Optional Roof Flue Kit (Flat Or Pitched)

    SECTION 2 - INSTALLATION 2.12 FITTING THE OPTIONAL ROOF FLUE KIT (Flat or Pitched) Note. A flat or pitched roof flashing plate (not supplied) is required before proceeding with the installation of this kit. This kit is suitable for both flat and pitched roof terminations, using a concentric flue to run vertically from the top of the boiler and terminating above roof level.

  • Page 27: Flue Terminal Position

    SECTION 2 - INSTALLATION 2.13 FLUE TERMINAL POSITION The terminal should be positioned so that products of combustion can safely disperse at all times. Pluming may occur at the termination so, where possible, terminal positions where this could cause a nuisance 3 0 0 m m should be avoided.

  • Page 28: Assembling The Roof Flue Kit

    SECTION 2 - INSTALLATION 2.14 ASSEMBLING THE ROOF FLUE KIT Determine the correct height that the flue should terminate above the roof. If after calculating or measuring the overall flue height from the top of the boiler, it is necessary to cut both pipes of assembly A, then ensure they are cut equally leaving the inner flue tube longer than the outer air tube as supplied.

  • Page 29: Connections & Filling

    SECTION 2 - INSTALLATION 2.15 CONNECTIONS & FILLING NOTES. Ensure all boss blanking plugs are removed before connecting hardware. Each valve must be fitted to the correct boss as shown in the picture. Ensure each union is fitted with fibre seals provided. Do not subject any of the isolating valves to heat as the seals may be damaged.

  • Page 30: Electrical Connections

    SECTION 2 - INSTALLATION 2.16 ELECTRICAL CONNECTIONS Wiring should be 3 core PVC insulated cable, not less than WARNING. This appliance MUST be earthed. 0.75mm (24 x 0.2mm), and to BS 6500 Table 16. For IE A mains supply of 230Vac ~ 50 Hz is required. reference should be made to the current ETCI rules for electrical installations.

  • Page 31: Optional System Controls Kits

    SECTION 2 - INSTALLATION 2.18 OPTIONAL SYSTEM CONTROLS KITS Ideal offers the following kit:- (see kit for installation instructions) Weather Compensation Kit: allows outside temperature sensing. 2.19 INTERNAL WIRING - EXTERNAL CONTROLS The Vogue Max System IE boiler comes pre-fitted with a red link wire between the SL1 connections and a violet link wire between the OpenTherm connections of the installer wiring connections.

  • Page 32: System Control Wiring

    SECTION 2 - INSTALLATION 2.20 SYSTEM CONTROL WIRING SYSTEM BOILER WITH Y PLAN SYSTEM Y PLAN FUSED VALVE SPUR BOILER SL 2 SL 1 MAINS IN CH ON TIMER HW ON HW OFF SYSTEM BOILER WITH S PLAN SYSTEM S PLAN VALVE S PLAN FUSED...

  • Page 33: External Electrical Controls

    SECTION 2 - INSTALLATION 2.21 EXTERNAL ELECTRICAL CONTROLS Wiring External to the Boiler EXAMPLE - Connection to Honeywell Evohome The fuse rating should be 3A. Wiring external to the boiler MUST be in accordance with the current I.E.E. (BS 7671) Wiring Regulations and any local regulations.

  • Page 34: Wiring Diagram

    SECTION 2 - INSTALLATION 2.22 WIRING DIAGRAM Installation and Servicing...

  • Page 35: Commissioning And Testing

    SECTION 2 - INSTALLATION 2.23 COMMISSIONING AND TESTING A. Electrical Installation B. Gas Installation 1. Checks to ensure electrical safety should be carried out by a 1. The whole of the gas installation, including the meter, competent person. should be inspected and tested for tightness and purged in accordance with the recommendations of BS 6891.

  • Page 36: Initial Lighting

    SECTION 2 - INSTALLATION 2.24 INITIAL LIGHTING Legend A. Boiler Status B. Burner on Indication C. Hot Keys D. CH Temperature Control READY 39°C E. Boiler On / Off Switch TIMER OR ROOM THERMOSTAT OFF F. Pressure Gauge C TO CYLINDER 15°C G.

  • Page 37: Check Ch & Hw Cylinder Operation

    SECTION 2 - INSTALLATION 2.25 CHECK CH & HW CYLINDER OPERATION OPERATION WITHOUT OUTSIDE SENSOR OPERATION WITH OUTSIDE SENSOR When the burner is established the following screen will With all the system controls calling for heat, when the be displayed. burner is established the following screen will be displayed.

  • Page 38: Display Functions In Normal Operation

    SECTION 2 - INSTALLATION 2.26 DISPLAY FUNCTIONS IN NORMAL OPERATION OUTSIDE SENSOR NOT CONNECTED OUTSIDE SENSOR CONNECTED Boiler Frost Protection: occurs if Flow Boiler Switched Off: On/Off Switch is Off Temperature less than 5°C Boiler Switched Off: (On/Off Switch is Off) BOILER FROST PROTECTION ACTIVE SWITCH OFF TEMPERATURE 19...

  • Page 39: Menu Operation

    SECTION 2 - INSTALLATION 2.28 MENU OPERATION EFFICIENCY LEVEL INSTALLERS DETAILS RESET SERVICE INTERVAL To view the efficiency level of the boiler The service required message which If the boiler has not been serviced within is displayed after 12 months can be press MENU and the following screen will the last 12 months then a message will customised to show the installer’s...
  • Page 40 SECTION 2 - INSTALLATION MENU OPERATION - CONT’D FAULT HISTORY FAULT HELP VENT SYSTEM To view the Fault History of the boiler This feature provides a list of potential The Vent System feature aids removal of press MENU and the following screen corrective actions at an installer level air from the heat exchanger.
  • Page 41 SECTION 2 - INSTALLATION MENU OPERATION - CONT’D PUMP / FAN / VALVES SENSOR READINGS MAXIMUM FLOW TEMPERATURE It is possible to limit the maximum flow To view the current Water Pressure, To view the current status of the Pump, Switched Live Status, DHW Flow Rate, Diverter Valve, Fan and Gas Valve press temperature that can be set from the...
  • Page 42 SECTION 2 - INSTALLATION MENU OPERATION - CONT’D SERVICE MODE MINIMUM RATE SERVICE MODE MAXIMUM RATE PUMP MODULATION This feature will run the burner at This feature will run the burner at The boiler is factory set for pump minimum rate. Note that a CH demand maximum rate.
  • Page 43 SECTION 2 - INSTALLATION MENU OPERATION - CONT’D OUTSIDE SENSOR SLOPE PLOT GRAPHS This feature is only accessible if an To plot graphs of Water Pressure, Outside Sensor has been fitted to the Switch Live, DHW Flow Rate, DHW boiler. Boiler performance can be Temperature, Flow/Return Temperature, adjusted relative to the insulation level of Flame Status, Outside Temperature or...

  • Page 44: General Checks

    SECTION 2 - INSTALLATION 2.29 GENERAL CHECKS WATER CIRCULATION SYSTEM 6. Balance the system. Refer to Section 1.18. 1. With the system COLD, check that the initial pressure 7. Check the condensate drain for leaks and check that it is is correct to the system design requirements.

  • Page 45: Servicing

    SECTION 3 - SERVICING 3.1 SERVICING SCHEDULE For the very latest copy of literature for specification & maintenance practices, visit our website idealheating.com, where you will be able to download the relevant information. WARNING. Always turn OFF the gas supply at the gas service cock, and switch OFF and disconnect the electricity supply to the appliance before servicing.

  • Page 46: Boiler Front Panel Removal / Replacement

    SECTION 3 - SERVICING 3.2 BOILER FRONT PANEL REMOVAL / REPLACEMENT REMOVAL 1. Loosen the 2 screws retaining the front panel at the underside of the boiler. 2. Release catches at underside of the front panel by pulling downwards. 3a. Pull the underside of the front panel forward then lift upwards to remove.

  • Page 47: Fan And Venturi Assembly Removal And Cleaning

    SECTION 3 - SERVICING 3.4 FAN AND VENTURI ASSEMBLY REMOVAL AND CLEANING 1. Refer to Sections 3.2 & 3.3. 2. Remove the ignition, detection and earth leads. 3. Remove the 2 clips securing the gas inlet pipe and remove the pipe. 4.

  • Page 48: Burner Removal And Cleaning

    SECTION 3 - SERVICING 3.6 BURNER REMOVAL AND CLEANING 1. Refer to Sections 3.2 & 3.3 2. To remove Fan, Burner and Venturi Assembly refer to Section 3.4. 3. Remove the assembly from the heat exchanger. 4. Brush off any deposits with a SOFT brush. 5a.

  • Page 49: Cleaning The Heat Exchanger

    SECTION 3 - SERVICING 3.8 CLEANING THE HEAT EXCHANGER Refer to Sections 3.2 & 3.3. Remove Fan, Burner and Venturi Assembly. Refer to Section 3.4. Once the front of the heat exchanger is open, the heat exchanger may be cleaned with a hand brush and vacuum cleaner to remove any debris.

  • Page 50: Replacement Of Components

    SECTION 3 - SERVICING 3.10 REPLACEMENT OF COMPONENTS When replacing ANY component: IMPORTANT. Ensure all gas valve connections are gas tight with a gas 1. Isolate the electrical supply soundness check up to the gas control valve. When work is complete, the front panel must be correctly 2.

  • Page 51: Burner Injector Replacement

    SECTION 3 - SERVICING 3.12 BURNER INJECTOR REPLACEMENT 1. Refer to Sections 3.2 to 3.4 2. Remove the 2 clips securing the gas inlet pipe and remove the pipe. 3. Carefully ease the injector out of the gas valve. 4. Replace injector ‘O’ ring. 5.

  • Page 52: Ignition Electrode Replacement

    SECTION 3 - SERVICING 3.15 IGNITION ELECTRODE REPLACEMENT 3& 6 1. Refer to Sections 3.2 & 3.3. 4.5±0.5 2. Disconnect the ignition lead and the earth connection 3. Release the 2 securing screws and carefully withdraw the probe. 4. Check the gap on the replacement ignition electrode is 4.5 ±...

  • Page 53: Spark Generator Replacement

    SECTION 3 - SERVICING 3.17 SPARK GENERATOR REPLACEMENT Refer to Sections 3.2 & 3.3. Disconnect the leads from the spark generator. Remove spark generator by pulling forwards to release the retaining clip, then push back to release the second retaining clip. Fit the new spark generator and re-assemble in reverse order ensuring that the the earth lead is replaced.

  • Page 54: Pcb Replacement

    SECTION 3 - SERVICING 3.20 PCB REPLACEMENT Note. Fit the earth strap provided with the PCB to your wrist and secure to a suitable earth on the boiler chassis. 1. Refer to Sections 3.2 & 3.3. Remove the 2 screws securing the controls housing lid. 3.

  • Page 55: User Pcb Replacement

    SECTION 3 - SERVICING 3.21 USER PCB REPLACEMENT Set both the user temperature selector knobs to the 12 o’clock position. Refer to Sections 3.2 & 3.3. Remove the two screws securing the controls housing lid. Refer to Section 3.20. Remove the electrical cover at the clips indicated. Refer to Section 3.20.

  • Page 56: Safety Pressure Relief Valve Renewal

    SECTION 3 - SERVICING 3.24 SAFETY PRESSURE RELIEF VALVE RENEWAL Refer to Sections 3.2 & 3.3. 2. Close the isolating service valves and drain the (CH) boiler. Refer to Section 3.22. 3. Remove the burner & Fan assembly, if required for access. Refer to Section 3.4.

  • Page 57: Pump Head Replacement

    SECTION 3 - SERVICING 3.26 PUMP HEAD REPLACEMENT Refer to Sections 3.2 & 3.3. 2. Close the isolating service valves and drain the (CH) boiler. Refer to Section 3.22. 3. Disconnect both electrical leads to the pump. 4. Remove the 4 Allen screws securing the pump head and remove.

  • Page 58: Heat Exchanger Replacement

    SECTION 3 - SERVICING 3.29 HEAT EXCHANGER REPLACEMENT Refer to Sections 3.2 & 3.3. Close the isolating service valves and drain the (CH) boiler. Refer to Section 3.22. Remove the condensate trap. Refer to Section 3.19. Remove the Burner & Fan assembly. Refer to Section 3.4. Remove the securing clips to disconnect the flow and return pipes below the heat exchanger.

  • Page 59: Expansion Vessel Recharging And Replacement

    SECTION 3 - SERVICING 3.30 EXPANSION VESSEL RECHARGING AND REPLACEMENT Recharging: A. Refer to Sections 3.2 & 3.3. B. Remove the charge point dust cover. C. Recharge the tank pressure to 0.75bar D. Refit in reverse order E. Check the operation of the boiler. Refer to Sections 2.24 - 2.27. Replacement: 1.

  • Page 60: External System Filter Cleaning Guide

    SECTION 3 - SERVICING 3.32 EXTERNAL SYSTEM FILTER CLEANING GUIDE Switch off the boiler (isolate electrical supply). Close the inlet/outlet valves. Remove Close magnet and vent. Vent Remove drain valve cap, open drain valve Vent and vent. Open Open inlet valve slowly and flush out filter Close Open until water runs clear.

  • Page 61: Fault Finding

    SECTION 4 - FAULT FINDING 4.1 FAULT FINDING CHART MAIN MENU Go to Section 4.13 No Connection to OVERHEAT LOCKOUT Go to Section 4.2 NO CONNECTION TO PRIMARY PCB Primary PCB Overheat Lockout Check other gas appliances work If pre-payment meter check credit IGNITION LOCKOUT If not, contact gas supplier Go to Section 4.3...
  • Page 62 SECTION 4 - FAULT FINDING 4.2 OVERHEAT LOCKOUT Are the boiler and CH/cylinder system filled with water Fill and vent the system and open all and are all isolation valves, system filter and radiator isolation valves, then restart the boiler valves open? Is the flow/return differential across the boiler in Check the flow and return thermistors...

  • Page 63: Flame Loss

    SECTION 4 - FAULT FINDING 4.4 FLAME LOSS If the boiler is restarted, does the boiler ignite for a Check the detection electrode and associated harness short time and then extinguish? for continuity, visual condition and position. Check if the condensate pipe is blocked.

  • Page 64: Flow Thermistor Fault

    SECTION 4 - FAULT FINDING 4.6 FLAME ON BEFORE GAS VALVE ON Check integrity of wiring from primary PCB to Flame Restart the boiler, does boiler work OK? Sense electrode, replace if deteriorated. Check condition of Flame Sense Electrode and replace if deteriorated Disconnect the electrical connection to the Flame Replace Flame Detection Electrode Sense Electrode.

  • Page 65: Fan Fault

    SECTION 4 - FAULT FINDING 4.9 RETURN THERMISTOR FAULT Disconnect the electrical connection to the Fit a new thermistor Return Thermistor and check the resistance using a suitable multimeter connected across the thermistor’s terminal pins. At 25°C expect 9,700 - 10,300 Ω At 60°C expect 2,400 - 2,600 Ω...

  • Page 66: No Ch But Cylinder Temperature Ok

    SECTION 4 - FAULT FINDING 4.13 NO CONNECTION TO PRIMARY PCB Check the wiring from the Primary PCB to the User interface PCB is securely connected at both ends Replace the wiring from the Primary Turn power Off and On, does the fault disappear PCB to the User Interface PCB 4.14 NO CH BUT CYLINDER TEMPERATURE OK Ensure that the Timer and Room...

  • Page 67: No Hw But Ch Ok

    SECTION 4 - FAULT FINDING 4.15 NO HW BUT CH OK Are the Timer and Cylinder Stat calling for heat? Ensure the Timer and Cylinder stat are calling for heat Open the Radiator Valves Are the Radiator Valves open? Check zone Valve and Zone Valve Wiring Consult Electronic Programmable Room Stat Fault Finding Instructions Does the Zone Valve move to the appropriate position?

  • Page 68: Spare Parts

    SECTION 5 - SPARE PARTS When replacing any part on this appliance use only spare parts that you can be assured conform to the safety and performance specification that we require. Do not use reconditioned or copy parts that have not been clearly authorised by Ideal. Failure to do so could affect safety or performance of this appliance.
  • Page 69 SHORT LIST OF PARTS Installation and Servicing...
  • Page 70 Benchmark Commissioning & Warranty Validation Service Record It is a requirement that the boiler is installed and commissioned to the manufacturers’ instructions and the data fields on the commissioning checklist completed in full. To instigate the boiler warranty the boiler needs to be registered with the manufacturer within one month of the installation.
  • Page 71 GAS BOILER SYSTEM COMMISSIONING CHECKLIST & WARRANTY VALIDATION RECORD Address: Boiler make and model: Boiler serial number: Commissioned by (PRINT NAME): Gas Safe registration number: Company name: Telephone number: Company email: Company address: Commissioning date: Heating and hot water system complies with the appropriate Building Regulations? Optional: Building Regulations Notification Number (if applicable): Time, temperature control and boiler interlock provided for central heating and hot water Boiler Plus requirements (tick the appropriate box(s))
  • Page 72 SERVICE & INTERIM BOILER WORK RECORD It is recommended that your boiler and heating system are regularly serviced and maintained, in line with manufacturers’ instructions, and that the appropriate service / interim work record is completed. Service provider When completing a service record (as below), please ensure you have carried out the service as described in the manufacturers’ instructions. Always use the manufacturers’...
  • Page 73 SERVICE & INTERIM BOILER WORK RECORD It is recommended that your boiler and heating system are regularly serviced and maintained, in line with manufacturers’ instructions, and that the appropriate service / interim work record is completed. Service provider When completing a service record (as below), please ensure you have carried out the service as described in the manufacturers’ instructions. Always use the manufacturers specified spare parts.
  • Page 74 FLOWCHART FOR CO LEVEL AND COMBUSTION RATIO CHECK ON COMMISSIONING A CONDENSING BOILER Important Preliminary Information on Checks The air gas ratio valve is factory-set and must not be adjusted DURING COMMISSIONING. If the boiler requires conversion to operate with a different gas family (e.g. conversion from natural gas to LPG) sepa- rate guidance is provided with the conversion kit supplied and this must be followed.
  • Page 75 Start Set Boiler to Maximum Gas Rate Carry Out Flue Integrity Check Using Analyser In accordance with boiler instructions, Insert analyser probe into air inlet test point (where available) and allow set boiler to operate at maximum rate readings to stabilise. (full load condition).
  • Page 76 NOTES Installation and Servicing...
  • Page 77 NOTES Installation and Servicing...
  • Page 78 NOTES Installation and Servicing...
  • Page 79 NOTES Installation and Servicing...
  • Page 80 & servicing of central heating systems At Ideal Heating we take our environmental impact seriously, therefore when installing any Ideal Heating product please make sure to dispose of any previous appliance in an environmentally conscious manner. Households can contact their local authority to find out how.

This manual is also suitable for:

Vogue max system 18ieVogue max system 26ieVogue max system 32ie
