This manual is intended to be used as part of an employee training program as required by OSHA. When used and
maintained in accordance with the manufacturer's instructions, this product helps provide a method of emergency
escape when working at height, referenced by OSHA and industry guidelines including API RP 54 6.10.1.
DESCRIPTION:
The Rollgliss™ Low Speed 115 Foot and 200 Foot Emergency Descent Devices with Auto-Retract are comprised of a Wire Rope
Lifeline housed in a cast aluminum enclosure. A brake controls vertical and sloped descent speed of a single user attached to a
Snap Hook or Guide Cable Sleeve at the end of the lifeline.
Figure 1 - 115 and 200 Ft Emergency Descent Device Models
Vertical Descent - 115 ft (35m)
Lifeline
Galvanized
3303000
Stainless
3303002
Sloped Descent - 115 ft (35m)
Lifeline
Galvanized
3303001
Stainless
3303003
Form: 5903738 Rev: E
Rollgliss
115 and 200 Ft Emergency Descent Device
Low Speed with Auto-Retract
User Instruction Manual
Vertical Descent - 200 ft (61m)
Lifeline
Galvanized
3303017
Stainless
3303018
Sloped Descent - 200 ft (61m)
Lifeline
Galvanized
3303021
Stainless
3303019
®
© 3M 2019

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DBI SALA Rollgliss 115 Ft and is the answer not in the manual?

Questions and answers

Related Manuals for 3M DBI SALA Rollgliss 115 Ft

Summary of Contents for 3M DBI SALA Rollgliss 115 Ft

  • Page 1 Vertical Descent - 200 ft (61m) Lifeline Lifeline Galvanized 3303000 Galvanized 3303017 Stainless 3303002 Stainless 3303018 Sloped Descent - 115 ft (35m) Sloped Descent - 200 ft (61m) Lifeline Lifeline Galvanized 3303001 Galvanized 3303021 Stainless 3303003 Stainless 3303019 Form: 5903738 Rev: E © 3M 2019...

  • Page 2: Safety Information

    Avoid surfaces and objects that can damage the user or equipment. Ensure there is adequate fall clearance when working at height. Never modify or alter your fall protection equipment. Only 3M or parties authorized in writing by 3M may make repairs to the equipment.

  • Page 3: System Requirements

    Emergency Descent Device. 2.0 SYSTEM REQUIREMENTS COMPATIBILITY OF COMPONENTS: 3M Fall Protection equipment is designed for use with 3M Fall Protection approved components and subsystems only. Substitutions or replacements made with non-approved components or subsystems may jeopardize compatibility of equipment and may effect the safety and reliability of the complete system.
  • Page 4 GUIDE CABLE: Applications with a sloped descent require a Guide Cable (see Figure 2, item D). Systems requiring a Guide Cable must be designed by a qualified person. Descent speed is affected by the angle at which the Guide Cable is secured and the amount of sag in the Guide Cable.

  • Page 5: Installation And Use

    TEST THE SYSTEM: 3M Fall Protection recommends performing a test descent using a 120 lb (55 kg) test weight. The descent speed should be uniform and allow the user to reach the landing area safely. The descent speed should be approximately as stated in Section 1.2.B.
  • Page 6 Figure 5 - Connect the Emergency Descent Device to a Guide Cable (Sloped Application Only) A Remove four 1/4-20 x 1-1/4 Bolts B Position Suspension Bar C Install four 1/4-20 x 1-1/2 Bolts, torque to 60 in lbs. D Capture Guide Cable in Suspension Bars with 3/8-16 x 1-3/4 bolts and 3/8-16 nylok nuts. Torque to 60 in lbs. E Capture Descender Swivel and Guide Cable in Guide Cable Sleeve.
  • Page 7 If you are a first-time user, contact a Customer Service representative in the US at 800- 328-1667. If you have already registered, go to www.3M.com. Follow the instructions provided with the handheld RFID reader or on the web RFID portal to transfer your data to the web log.

  • Page 8: Specifications

    7.0 SPECIFICATIONS MATERIALS Housing: Cast Aluminum Anchorage Handle: Stainless Steel Fasteners: Stainless Steel Main Shaft: Stainless Steel Connecting Hook: Stainless Steel Cable Bumper: Urethane Lifeline (Stainless Steel): 3/16” (4.8 mm) dia. 7x19 Aircraft Wire Rope, 3,600 lbs (16 kN) minimum tensile strength Finish Paint: Polyester Baked Finish PERFORMANCE SPECIFICATIONS...

  • Page 9: Inspection And Maintenance Log

    9.0 INSPECTION AND MAINTENANCE LOG SERIAL NUMBER: MODEL NUMBER: DATE PURCHASED: DATE OF FIRST USE: INSPECTION DATE INSPECTION ITEMS CORRECTIVE ACTION MAINTENANCE NOTED PERFORMED Approved By: Approved By: Approved By: Approved By: Approved By: Approved By: Approved By: Approved By: Approved By: Approved By: Approved By:...
  • Page 10 INSPECTION DATE INSPECTION ITEMS CORRECTIVE ACTION MAINTENANCE NOTED PERFORMED Approved By: Approved By: Approved By: Approved By: Approved By: Approved By: Approved By: Approved By: Approved By: Approved By: Approved By: Approved By: Approved By: Approved By: Approved By: Approved By: Approved By: Approved By: Approved By:...
  • Page 12 LIMITED REMEDY: Upon written notice to 3M, 3M will repair or replace any product determined by 3M to have a factory defect in workmanship or materials. 3M reserves the right to require product be returned to its facility for evaluation of warranty claims. This warranty does not cover product damage due to wear, abuse, misuse, damage in transit, failure to maintain the product or other damage beyond 3M’s control.
