REVELL Concerta IC6T2 Brochure

IC6T2 and IW80
In-Ceiling/In-Wall Specifications
IC6T2 IW80
Driver Complement: 6-1/2" (165mm) woofer, 8" (200mm) woofer,
dual 3/4" (19mm) tweeters 1" (25mm) tweeter
Crossover: 2-Way at 2.2kHz 2-1/2-Way at 400Hz
and 2.2kHz
Bandwidth (– 6dB): 45Hz – 22kHz 40Hz – 40kHz
Sensitivity: 88dB 89dB
(2.83V @ 1m, 2π) (both channels driven)
Impedance: 6 Ohms 8 Ohms
Dimensions: 9-1/4" (235mm) 10-1/4" x 13-7/16" (259mm x 341mm)
diameter W x H
Weight: 3.5 lb (1.6kg) 5.9 lb (2.7kg)
IC6T2
6-1/2" In-Ceiling Single-Speaker Stereo Loudspeaker
High-output, dual-voice-coil woofer
Dual tweeter with unique bridge design
High-order crossover network
Boundary compensation switch
Three-position tweeter-level control
IW80
8" In-Wall Loudspeaker
High-output, low-distortion woofer
Pivoting tweeter with integral waveguide
High-order crossover network
Boundary compensation switch
Three-position tweeter-level control
The exclusive Revel "in-wall mover" allows true
comparisons of in-wall and in-ceiling loudspeakers
with their competitors. Double-blind tests prove the
sonic superiority of every Revel in-wall and in-ceiling
model before it is released for production.
