REVELL Concerta IC65 Owner's Manual
In-wall/in-ceiling loudspeakers
Hide thumbs
Also See for Concerta IC65:
- User manual (1 page) ,
- Owner's manual (17 pages) ,
- Brochure (2 pages)
Related Manuals for REVELL Concerta IC65
Summary of Contents for REVELL Concerta IC65
- Page 1 Revel ® IW65/IW80 In-Wall Loudspeakers IC65/IC80/IC6T2 In-Ceiling Loudspeakers Owner’s Manual...
-
Page 2: Documentation Conventions
DOCUMENTATION CONVENTIONS This document contains general safety, installation and operation instructions for the Revel ® Concerta ™ IW65/IW80 in-wall loudspeakers and the IC65/IC80/IC6T2 in-ceiling loudspeakers. It is important to read this document before attempting to use these products. Pay particular attention to safety instructions. -
Page 3: Product Registration
™ IW65/IW80 IN-WALL AND IC65/IC80/IC6T2 IN-CEILING LOUDSPEAKERS Since 1996, the Revel name has stood for the best in loudspeaker design and performance. Backed by Harman International’s extensive research and design facilities, Revel loudspeakers benefit from cutting-edge development tools such as: •... -
Page 4: Installation Considerations
But not all listening spaces can accommodate the ideal conditions for these two factors. Therefore, careful attention to the placement of your Revel in-wall and in-ceiling loudspeakers will have the most significant impact on the general performance of the loudspeakers. -
Page 5: Loudspeaker Placement
• When installing in the wall, position each speaker so that the tweeter is as close to ear level as possible. Note:... - Page 6 • Place the left and right loudspeakers roughly the same distance from the primary listener locations. • To avoid “hot spots, ” plan to use more loudspeakers, each set to a lower volume. Revel Concerta IW65/IW80 & IC65/IC80/IC6T2 Owner’s Manual...
-
Page 7: Mounting Instructions
SPEAKER WIRES Using high-quality speaker wire will maintain the best sound quality from your Revel in-wall or in-ceiling speakers. For distances of 100 feet or less, use at least #16-gauge speaker wire with polarity coding. For distances of greater than 100 feet, use at least #12-gauge wire or heavier. -
Page 8: Installation
Always allow at least a 1/2" between the wall stud and the speaker cutout or the locking tabs will not have the space to swivel into place. 3. Ensure that the drywall, plywood or other appropriate wallboard is at least a 1/2" thick and capable of withstanding the weight of the speaker being installed. - Page 9 Hand-tighten with a nonpowered, straight-handle Phillips-head screwdriver only. Ensure that the speaker is securely held in place and that all four locking tabs are firmly resting against the wall panel. Note: Do not use a socket wrench, powered screwdriver, drill or any other powered tool.
- Page 10 Hand-tighten with a nonpowered, straight-handle Phillips-head screwdriver only. Ensure that the speaker is securely held in place and that all four locking tabs are firmly resting against the ceiling material.
-
Page 11: Obtaining Service
80Hz or above. Some A/V receivers or processors are set by identifying the loudspeakers as “small. ” OBTAINING SERVICE To obtain warranty or nonwarranty service, contact an authorized Revel dealer. Refer to the included Revel warranty card for warranty information. -
Page 12: Specifications
4-1/8" (104mm) 88 liters Infinite Baffle (full stud bay) 5.9 lb (2.7kg) 3.5 lb (1.6kg) Revel Concerta IW65/IW80 & IC65/IC80/IC6T2 IC80 IC6T2 45Hz to 40kHz, ±3dB 55 Hz to 22 kHz, ±3dB 10 – 135 Watts 10 – 125 Watts... -
Page 13: Limited Warranty
(5) years (parts and labor) from any failure as a result of original manufacturing defects, so long as: 1. The Revel products were purchased within the 50 United States, its territories or Canada. 2. The dealer from whom the Revel products were purchased was authorized to sell such products at the time of the original purchase. - Page 14 Revel, the Revel logo and Concerta are trademarks of Harman International Industries, Incorporated, in the United States and/or other countries. Features, specifications and appearance are subject to change without notice. For customer service and product shipment information, go to www.revelspeakers.com.
