REVELL Concerta IC65 Brochure

Specifications
IW65
Frequency Response
(2 π anechoic) 50 Hz to 40 kHz ± 3 dB
Recommended Amplifier
Power Range 10 - 125 Watts
Sensitivity
(2.83 V 2 π anechoic) 89 dB
Nominal Impedance 8 Ohms
Crossover Frequency 3,000 Hz; 24 dB/Octave
Low-Frequency Driver 6-1/2" (165 mm) Micro
Ceramic Composite
(MCC) Cone
High-Frequency Driver 1" (25 mm) Micro
Ceramic Composite
(MCC) Dome
External Dimensions (W x H) 8-1/2" x 11"
(216 mm x 280 mm)
Mounting Cut-out Size (WxH) 7" x 9-1/2"
(178 mm x 242 mm)
Mounting Depth 3-1/2" (89 mm)
Weight Net 3.5 lb. (1.6 kg)
Specifications are subject to change without notice.
Revel ® and the Revel logo are registered trademarks of
Harman International Industries, Incorporated.
Not responsible for typographic errors.
Part # 072-20435 Rev. 0 6/07
IC65 IC80
50 Hz to 40 kHz ± 3 dB 45 Hz to 40 kHz ± 3 dB
10 - 125 Watts 10 - 135 Watts
89 dB 89 dB
8 Ohms 8 Ohms
2,500 Hz; 18 dB/Octave 2,500 Hz; 18 dB/Octave
6-1/2" (165 mm) Micro 8" (200 mm) Micro
Ceramic Composite Ceramic Composite
(MCC) Cone (MCC) Cone
1" (25 mm) Micro 1" (25 mm) Micro Ceramic
Ceramic Composite Composite (MCC) Dome
(MCC) Dome
Diameter: 9-1/4" Diameter: 10-7/8"
(235 mm) (275 mm)
Diameter: 7-7/8" Diameter: 9-1/2"
(200 mm) (241 mm)
4-4/32" (104 mm) 4-3/4" (121 mm)
3.5 lb. (1.6 kg) 5.8 lb. (2.6 kg)
Revel's exclusive "in-wall mover"
allows true comparisons of in-wall
and in-ceiling loudspeakers with their
competitors. Double-blind tests prove
the sonic superiority of every Revel
in-wall and in-ceiling model before they
are released for production. Music lovers
can choose Revel in-wall and in-ceiling
loudspeakers with confidence in the
knowledge that they will provide an
unsurpassed musical experience.
3 O a k P a r k , B e d f o r d , M A 0 1 7 3 0 - 1 4 1 3 U S A
T e l : 7 8 1 - 2 8 0 - 0 3 0 0 | F a x : 7 8 1 - 2 8 0 - 0 4 9 0
w w w . h a r m a n s p e c i a l t y g r o u p . c o m
In-Wall In-Ceiling Loudspeakers
&
IW65
IC65
IC80
