Fitting the Lens
4
Using the triangular mark as a
guide, push the lens connector
into the LENS connector on
the camera head, until it clicks
into place. Fasten the cable
with the clamps.
Fitting optional filters
Loosen the lens hood fixing screw to remove the lens
hood, then attach the filter.
Filter (optional)
30
Chapter 2 Fitting and Connections
Remove lens hood
LENS connector
Lens hood fixing screw
Triangular
mark
