Summary of Contents for Cylinda DM4350FiD

  • Page 1 User manual DM4350FiD...
  • Page 2 Thank you for choosing this product. This user manual contains important information on safety and instructions intended to assist you in the operation and maintenance of your appliance. Please take the time to read this user manual before using your appliance and keep this book for future reference.

  • Page 3: Table Of Contents

    CONTENTS 1 SAFETY INSTRUCTIONS ................1 1.1 General Safety Warnings ....................1 1.2 Installation Warnings .....................2 1.3 During Usage........................3 2 INSTALLATION ....................6 2.1 Machine Positioning ......................6 2.2 Water Connection ......................6 2.3 Water Inlet Hose ......................6 2.4 Drain Hose (Model Depending) ..................7 2.5 Electrical Connection ......................7 3 TECHNICAL SPECIFICATIONS ..............

  • Page 4: Safety Instructions

    1 SAFETY INSTRUCTIONS 1.1 General Safety Warnings • Read these instructions carefully before using your appliance and keep this manual for future reference. Please check the packaging of your machine before installation and the outer surface of the machine once the packaging has been removed. Do not operate the machine if it appears damaged or if the packaging has been opened.

  • Page 5: Installation Warnings

    There may be some residue left in the machine after washing. Keep children away from the machine when it is open. 1.2 Installation Warnings • Choose a suitable and safe place to install your machine. • Only original spare parts should be used with the machine.

  • Page 6: During Usage

    Always use the coated plug supplied with your machine. If the electrical cable is damaged, it should only be replaced by a qualified electrician. • Connect the hose directly to the water inlet tap. The pressure supplied by the tap should be a minimum of 0.03 MPa and a maximum of 1 MPa.
  • Page 7 Do not open the door while the machine is in operation, hot water may spill out. Safety devices ensure the machine stops if the door is opened. The machine door should not be left open. It may cause accidents. Place knives and other sharp objects in the cutlery basket in a blade-down position.
  • Page 8 Pull the plug to disconnect the machine from the mains, never pull on the cord. EN - 5...

  • Page 9: Installation

    2 INSTALLATION water). For all other models: Cold water preferred; hot water max. 2.1 Machine Positioning temperature 60 °C. When positioning the machine, place it in an area where dishes can be easily loaded 2.3 Water Inlet Hose and unloaded. Do not put the machine in an area where the ambient temperature falls below 0°C.

  • Page 10: Drain Hose (Model Depending)

    2.4 Drain Hose (Model Depending) 2.5 Electrical Connection WARNING: Your machine is set to operate at 220-240 V. If the mains voltage supply to your machine is 110 V, connect a transformer of 110/220 V and 3000 W between the electrical connection. Connect the product to a grounded outlet protected by a fuse complying with the values in the...

  • Page 11: Technical Specifications

    3 TECHNICAL SPECIFICATIONS 3.2 Technical Specifications 15 place Capacity settings Dimensions Height 820-870 (mm) 598 (mm) Width 570 (mm) Depth Net weight 39 kg Operating 220-240V voltage / 50 Hz frequency Total current 10(A) Total power 1900(W) Maximum: Water supply 1 (Mpa) 3.1 General Sppearance pressure...
  • Page 12 RECYCLING • Some machine components and packaging consist of recyclable materials. • Plastics are marked with the international abbreviations:(>PE<, >PP<, etc. ) • The cardboard parts consist of recycled paper. They can be put into waste paper containers for recycling. •...

  • Page 13: Before Using The Appliance

    4 BEFORE USING THE 4.3 Fill The Salt (IF AVAILABLE) APPLIANCE To add softener salt, open the salt compartment cap by turning it counter 4.1 Preparing Your Dishwasher For First clockwise. (1) (2) At first use, fill the compartment with 1 kg salt and water (3) until it is almost overflowing.

  • Page 14: Test Strip

    4.4 Test Strip Run water through Keep the strip in Set the hardness level of Shake the strip. Wait (1min.) the tap (1min.) the water (1sec) your machine. second minute NOTE: The factory hardness level setting is “3”. If the water is well water or has a hardness level above 90 dF, we recommend that you use filter and refinement devices.

  • Page 15: Filling The Detergent

    programmes. cool, dry places out of reach of children. If you encounter problems when using Add the proper detergent for the selected combined detergents, please contact the program to ensure the best performance. detergent manufacturer. The amount of detergent needed depends on the cycle, load size, and soil level of When you stop using combined detergents, dishes.
  • Page 16 Level Brightener Dose Indicator Rinse-aid not r1 is shown on the dispensed display 1 dose is r2 is shown on the dispensed display 2 doses are r3 is shown on the dispensed display. 3 doses are r4 is shown on the dispensed display.

  • Page 17: Loading Your Dishwasher

    5 LOADING YOUR DISHWASHER Four Folding Racks (15 pc) The folding racks allow easier placement of For best results, follow these loading larger items, such as pots and pans. Each guidelines. section can be folded separately. The racks Loading the household dishwasher up to the can be raised up, or folded down, as shown capacity indicated by the manufacturer will in the images.
  • Page 18 Upper Basket Height Adjustment When Height Adjustable Rack (peg type) Full The upper basket includes a mechanism The height adjustable racks enable glasses that allows the height of the basket to and cups to be placed on or under the be adjusted to the upper (1), lower (2) racks.
  • Page 19 Upper Cutlery Basket WARNING: Knives and other sharp objects must be placed horizontally in the cutlery The upper cutlery basket is designed for basket. you to place forks, spoons and knives, long dippers and small items. Bottle Rack The Upper Cutlery Basket is composed of The bottle rack can be used to wash large three pieces;...
  • Page 20 SOFT TOUCH Top basket Height Adjustable Rack These racks are designed to increase the capacity of the top basket. You can place your glasses and cups on the racks. You can adjust the height of these racks. Thanks to this feature, you can place different sizes of glasses under these racks.

  • Page 21: Alternative Basket Loads

    5.2 Alternative Basket Loads Lower Basket Top Basket Incorrect Loads Incorrect loading can cause poor washing and drying performance. Please follow the manufacturer’s recommendations for a good performans result. EN - 18...

  • Page 22: Programme Table

    EN - 19...
  • Page 23 • The program duration may change according to the amount of dishes, the water temperature, the ambient temperature and selected additional functions. • Values given for programmes other than the eco programme are indicative only • Eco programme is suitable to clean normally soiled tableware, that for this use, it is the most efficient programme in terms of its combined energy and water consumption, and that it is used to assess compliance with the EU ecodesign legislation.

  • Page 24: The Control Panel

    7 THE CONTROL PANEL NOTE: Press and hold the Delay (10) touch button to change the delayed start time faster. The rate of change in time is proportional to the how long the button is pressed and held for. When the Delay Start touch button is pressed for a long period of (11) time, the counter will stop at “h:00”.
  • Page 25 8. Extra Silent Touch Button Changing a Programme Press the Extra Silent touch button to Follow the steps below to change a decrease the water pressure, therefore programme while in operation. providing a more sensitive and silent wash. This option can only be selected at the 1.
  • Page 26 buttons simultaneously for 3 seconds. 2. When sound setting is recognized, buzzer gives a long sound and machine will display last set level, from “S0” to “S3”. 3. To decrease sound level press Extra Dry / Energy Save touch button (5,9). To increase sound level, press Half Load touch button (6).
  • Page 27 NOTE:If machine is turned off, Ionizer Infoled 2.1 (Model Dependent) function is cancelled. LED Indicator State of the Machine NOTE:Natural Ion Tech function does The machine is running a Red, continuous not work with any program. program. Red, flashing A program is cancelled. PureBeam &...

  • Page 28: Cleaning And Maintenance

    8 CLEANING AND MAINTENANCE To remove and clean the filter combination, turn it counter clockwise and remove it by Cleaning your dishwasher is important to lifting it upwards (1).Pull the coarse filter maintain the machine’s service life out of the micro filter (2).Then pull and Make sure that the water softening setting remove the metal filter (3).Rinse the filter (If available) is done correctly and correct...

  • Page 29: Drain Pump

    8.3 Drain Pump Large food residues or foreign objects which were not captured by the filters may block the waste water pump. The rinsing water will then be above the filter. Warning Risk of cuts! When cleaning the waste water pump, ensure that you do not injure yourself on p ieces of broken glass or pointed implements.

  • Page 30: Troubleshooting

    9 TROUBLESHOOTING FAULT POSSIBLE CAUSE TROUBLESHOOTING Your Dishwasher is not plugged in. Plug your Dishwasher in. Switch your Dishwasher on by pressing the Your Dishwasher is not switched on. On/Off button. Fuse blown. Check your indoor fuses. The programme does not start.
  • Page 31 FAULT POSSIBLE CAUSE TROUBLESHOOTING Use the correct amount of detergent, as Not enough detergent used. instructed in the programme table. Rinse aid dosage and/or water Increase rinse aid and/or water softener softener setting set too low. level. Whitish stains remains on dishes.
  • Page 32 AUTOMATIC FAULT WARNINGS AND WHAT TO DO TROUBLE POSSIBLE FAULT WHAT TO DO CODE Make sure the water inlet tap is open and water is flowing. Separate the inlet hose from the tap and clean the filter of Water inlet system failure the hose.
  • Page 33 The installation and repairing procedures should always carried out by the Authorised Service Agent in order to avoid possible risks. The manufacturer shall not be held liable for damages that may arise from procedures carried out by unauthorised persons. Repairs may be carried out by technicians only.
  • Page 34 Service Nationwide service in Sweden Visit www.cylinda.se Call 0771-25 25 00 Declare Model code Serial number Purchase date Problem description Name and address Phone number Contact us www.cylinda.se ---------------------...
