  • Page 1 User manual DM4210E / DM4210RFE...
  • Page 2 Thank you for choosing this product. This User Manual contains important information on safety and instructions intended to assist you in the operation and maintenance of your appliance. Please take the time to read this User Manual before using your appliance and keep this book for future reference.

  • Page 3: Table Of Contents

    CONTENTS 1.SAFETY INSTRUCTIONS ....................1 1.1. General Safety Warnings ....................1 1.2. Installation Warnings .....................2 1.3. During Use........................3 2.INSTALLATION ......................... 6 2.1. Machine Positioning .....................6 2.2. Water Connection ......................6 2.3. Water Inlet Hose ......................6 2.4. Drain Hose........................7 2.5. Electrical Connection ....................7 2.6.

  • Page 4: Safety Instructions

    1. SAFETY INSTRUCTIONS 1.1. General Safety Warnings • Read these instructions carefully before using your appliance and keep this manual for future reference. Please check the packaging of your machine before installation and the outer surface of the machine once the packaging has been removed. Do not operate the machine if it appears damaged or if the packaging has been opened.

  • Page 5: Installation Warnings

    1.2. Installation Warnings • Choose a suitable and safe place to install your machine. • Only original spare parts should be used with the machine. Unplug the machine before installation. Your machine must only be installed by an authorised service agent. Installation by anyone other than an authorised agent may cause your warranty to be void.

  • Page 6: During Use

    pressure exceeds 1 MPa, a pressure relief valve must be fitted between the connection. 1.3. During Usage • This machine is for domestic use only; do not use it for other purposes. Commercial use will void the guarantee. Do not stand, sit or place loads on the open door the dishwasher.
  • Page 7 the door for one minute after it has opened. For effective drying, keep the door open for 30 minutes after a programme has ended. Do not stand in front of the door after the auto-open signal sounds. In the case of a malfunction, repair should only be performed by an authorised service company, otherwise the warranty will be void.
  • Page 8 RECYCLING • Some machine components and packaging consist of recyclable materials. • Plastics are marked with the international abbreviations:(>PE<, >PP<, etc. ) • The cardboard parts consist of recycled paper. They can be put into waste paper containers for recycling. •...

  • Page 9: Installation

    2. INSTALLATION 2.3. Water inlet hose 2.1. Machine positioning When positioning the machine, place it in an area where dishes can be easily loaded and unloaded. Do not put the machine in an area where the ambient temperature falls below 0°C. Read all warnings located on the packaging before removing the packaging and positioning the machine.

  • Page 10: Drain Hose

    2.4. Drain hose The plug on this appliance may incorporate 10A fuse. Connect the water drain hose directly to water drain hole or to the sink outlet spigot. This connection should be minimum 50 cm and maximum 110 cm from floor that dishwasher is placed.

  • Page 11: Fitting The Machine Undercounter

    2.6 Fitting the Machine Undercounter 700X75 OPS.(+50)H=870-920 mm EN - 8...
  • Page 12 EN - 9...
  • Page 13 The following options are available. Follow the supplied instructions. The following options are available. ops.(+50) H= 870-920 mm Option 1: Attach the furniture kickplate. Option 2: Attach the adjustable plinth group. Follow the instructions supplied with the adjustable plint group. EN - 10...

  • Page 14: Technical Specifications

    3. TECHNICAL SPECIFICATIONS 3.2. Technical Specifications 12 place Capacity settings Dimensions (mm) 820-870(mm) Height 870-920(mm) Width 570(mm) Depth 598(mm) 3.1. general appearance 1. Upper basket with racks Net weight 39,100 kg 2. Upper spray arm 3. Lower basket Operating 220-240V 50 4.

  • Page 15: Before Using The Appliance

    4. BEFORE USING THE APPLIANCE 4.1. Preparing your dishwasher for first use • Make sure the electricity and supply water specifications match the values indicated in the installation instructions for the machine. • Remove all packaging material inside the machine. •...

  • Page 16: Test Strip

    4.4 Test Strip Run water Keep the Shake the Wait Set the hardness level of through the strip in the strip. (1min.) your machine. tap (1min.) water (1sec) second munite munite NOTE: The level is set to 1 as default. If the water is well water or has a hardness level above 90 dF, we recommend that you use filter and refinement devices.

  • Page 17: Filling The Detergent

    Add the proper detergent for the selected 4.11 Rinse-aid usage program to ensure the best performance. The rinse aid helps to dry the dishes without The amount of detergent needed depends streaks and stains. Rinse-aid is required for on the cycle, load size, and soil level of stain-free utensils and clear glasses.
  • Page 18 Level Brightener Dose Indicator Rinse-aid not r1 is shown on the dispensed display. 1 dose is r2 is shown on the dispensed display. 2 doses are r3 is shown on the dispensed display. 3 doses are r4 is shown on the dispensed display.

  • Page 19: Loading Your Dishwasher

    5. LOADING YOUR DISHWASHER For best results, follow these loading guidelines. Loading the household dishwasher up to the capacity indicated by the manufacturer will contribute to energy and water savings. Manual pre-rinsing of tableware items leads to increased water and energy consumption and is not recommended You can place cups, glasses, stemware, small plates, bowls, etc.
  • Page 20 Slide Basket Four Folding Racks The movable cutlery basket can slide The folding racks are designed so that between the front and rear wires of the large items, such as pots and pans, can bottom basket. be easily placed in the dishwasher. Each section can be folded separately.
  • Page 21 Upper Basket Height Adjustable Rack (peg type) Height Adjustment Turn the Rail Stop Clips, at the ends of the The height adjustable racks enable glasses rails, to the sides to open them (as shown and cups to be placed on or under the in the image below), then pull out and racks.

  • Page 22: Alternative Basket Loads

    5.2. Alternative basket loads UnsUit able ite Ms for DishW ashing Lower basket • Cigarette ashes, candle leftovers, polish, paint, chemical substances, iron- alloy materials. • Forks, spoons and knives with wooden, bone, ivory or nacrecoated handles; glued items, items soiled with abrasive, acidic or base chemicals.

  • Page 23: Programme Table

    6. PROGRAMME TABLE EN - 20...
  • Page 24 • The program duration may change according to the amount of dishes, the water temperature, the ambient temperature and selected additional functions. • Values given for programmes other than the eco programme are indicative only • If your model has turbidity sensor, it has Auto program instead of Intensive program. •...

  • Page 25: The Control Panel

    7. THE CONTROL PANEL and activating the delay time, the delayed time is cancelled. 4. Remaining Time Indicator Programme flow can be monitored via the Wash, Rinse, Dry, End indicators (10) and Remaining Time Indicator. 5. Tablet Button Press the Tablet button to activate the Tablet option when using combined 6.1 3.1 5.1 detergent that contains salt and rinse aid.

  • Page 26: Changing A Programme

    7.2. Cancelling a programme NOTE: Child lock is activated/deacti- vated by pressing the Tablet button (5) for If you would like to cancel a programme about 3 seconds. When it is activated, all when it is running. leds blink and “CL” is shown on the Remaining Time Indicator (4) once.
  • Page 27 Buzzer Sound Control (Model Depending) To change the buzzer sound level, follow the below steps: 1. Open the door and press Half Load (6) and Tablet (5) buttons at the same time for 3 seconds. 2. When sound setting is recognized, buzzer gives a long sound and machine will display last set level, from “S0”...

  • Page 28: Cleaning And Maintenance

    8. CLEANING AND To remove and clean the filter combination, turn it counter clockwise and remove it by MAINTENANCE lifting it upwards (1).Pull the coarse filter out of the micro filter (2).Then pull and remove Cleaning your dishwasher is important to the metal filter (3).Rinse the filter with lots of maintain the machine’s service life water until it is free of residue.

  • Page 29: Drain Pump

    8.3 Drain Pump Large food residues or foreign objects which were not captured by the filters may block the waste water pump. The rinsing water will then be above the filter. Warning Risk of cuts! When cleaning the waste water pump, ensure that you do not injure yourself on pieces of broken glass or pointed implements.

  • Page 30: Troubleshooting

    9. TROUBLESHOOTING FAULT POSSIBLE CAUSE TROUBLESHOOTING Your Dishwasher is not plugged in. Plug your Dishwasher in. Switch your Dishwasher on by pressing the Your Dishwasher is not switched on. On/Off button. Fuse blown. Check your indoor fuses. The programme does not start.
  • Page 31 FAULT POSSIBLE CAUSE TROUBLESHOOTING Use the correct amount of detergent, as Not enough detergent used. instructed in the programme table. Rinse aid dosage and/or water Increase rinse aid and/or water softener softener setting set too low. level. Whitish stains remains on dishes.
  • Page 32 AUTOMATIC FAULT WARNINGS AND WHAT TO DO TROUBLE POSSIBLE FAULT WHAT TO DO CODE Make sure the water inlet tap is open and water is flowing. Separate the inlet hose from the tap and clean the filter of Water inlet system failure the hose.
  • Page 33 Service Nationwide service in Sweden Visit www.cylinda.se Call 0771-25 25 00 Declare Model code Serial number Purchase date Problem description Name and address Phone number Contact us www.cylinda.se ---------------------...
