User manual
DM4405D / DM4405RFD

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DM4405D and is the answer not in the manual?

Questions and answers

Related Manuals for Cylinda DM4405D

Summary of Contents for Cylinda DM4405D

  • Page 1 User manual DM4405D / DM4405RFD...
  • Page 2 Thank you for choosing this product. This user manual contains important information on safety and instructions intended to assist you in the operation and maintenance of your appliance. Please take the time to read this user manual before using your appliance and keep this book for future reference.

  • Page 3: Table Of Contents

    CONTENTS 1 SAFETY INSTRUCTIONS ................1 1.1 General Safety Warnings .....................1 1.2 Installation Warnings ....................2 1.3 During Usage.........................3 2 INSTALLATION ....................6 2.1 Machine Positioning .....................6 2.2 Water Connection ......................6 2.3 Water Inlet Hose ......................6 2.4 Drain Hose (Model Depending) ..................7 2.5 Electrical Connection .....................7 2.6 Fitting the Machine Undercounter ................

  • Page 4: Safety Instructions

    1 SAFETY INSTRUCTIONS 1.1 General Safety Warnings • Read these instructions carefully before using your appliance and keep this manual for future reference. Please check the packaging of your machine before installation and the outer surface of the machine once the packaging has been removed. Do not operate the machine if it appears damaged or if the packaging has been opened.

  • Page 5: Installation Warnings

    There may be some residue left in the machine after washing. Keep children away from the machine when it is open. 1.2 Installation Warnings • Choose a suitable and safe place to install your machine. • Only original spare parts should be used with the machine.

  • Page 6: During Usage

    Always use the coated plug supplied with your machine. If the electrical cable is damaged, it should only be replaced by a qualified electrician. • Connect the hose directly to the water inlet tap. The pressure supplied by the tap should be a minimum of 0.03 MPa and a maximum of 1 MPa.
  • Page 7 Do not open the door while the machine is in operation, hot water may spill out. Safety devices ensure the machine stops if the door is opened. The machine door should not be left open. It may cause accidents. Place knives and other sharp objects in the cutlery basket in a blade-down position.
  • Page 8 Pull the plug to disconnect the machine from the mains, never pull on the cord. EN - 5...

  • Page 9: Installation

    2 INSTALLATION water). For all other models: Cold water preferred; hot water max. 2.1 Machine Positioning temperature 60 °C. When positioning the machine, place it in an area where dishes can be easily loaded 2.3 Water Inlet Hose and unloaded. Do not put the machine in an area where the ambient temperature falls below 0°C.

  • Page 10: Drain Hose (Model Depending)

    2.4 Drain Hose (Model Depending) 2.5 Electrical Connection WARNING: Your machine is set to operate at 220-240 V. If the mains voltage supply to your machine is 110 V, connect a transformer of 110/220 V and 3000 W between the electrical connection. Connect the product to a grounded outlet protected by a fuse complying with the values in the...

  • Page 11: Fitting The Machine Undercounter

    2.6. Fitting the Machine Undercounter 700X75 OPS.(+50)H=870-920 mm EN - 8...
  • Page 12 Adjust the machine’s feet. EN - 9...
  • Page 13 Option 1: To put the furtniture kickplate. Option 2: To put the adjustable plint group. Follow the instructions is given with adjustable plint group. EN - 10...

  • Page 14: Technical Specifications

    3 TECHNICAL SPECIFICATIONS 3.2 Technical Specifications 10 place Capacity settings Dimensions Height 820-870 (mm) Width 450 (mm) Depth 570 (mm) Net weight 34 kg Operating 220-240V voltage / 50 Hz frequency Total current 10(A) Total power 1900(W) Maximum: Water supply 1 (Mpa) pressure Minimum:...
  • Page 15 RECYCLING • Some machine components and Declaration of Conformity packaging consist of recyclable materials. This dishwasher complies with the • Plastics are marked with the requirements of: international abbreviations:(>PE<, >PP<, etc. ) CE Marking Directive 93/68/EEC • The cardboard parts consist of recycled paper.

  • Page 16: Before Using The Appliance

    4 BEFORE USING THE 4.3 Fill The Salt (IF AVAILABLE) APPLIANCE To add softener salt, open the salt compartment cap by turning it counter 4.1 Preparing Your Dishwasher For First clockwise. (1) (2) At first use, fill the compartment with 1 kg salt and water (3) until it is almost overflowing.

  • Page 17: Test Strip

    4.4 Test Strip Run water Keep the Shake the Wait Set the hardness level of through the strip in the strip. (1min.) your machine. tap (1min.) water (1sec) second munite munite NOTE: The level is set to 3 as default. If the water is well water or has a hardness level above 90 dF, we recommend that you use filter and refinement devices.

  • Page 18: Detergent Usage

    4.8 Detergent Usage the detergent but also rinse-aid, salt replacement substances and additional Only use detergents specifically designed components depending on the combination. for domestic dishwashers. Keep your We recommend you do not use combined detergents in cool, dry places out of reach detergents in short programmes.
  • Page 19 • Switch off the machine to save the setting. • The factory setting is “4”. If the dishes are not drying properly or are spotted, increase the level. If blue stains form on your dishes, decrease the level. Level Brightener Dose Indicator Rinse-aid not r1 is shown on the...

  • Page 20: Loading Your Dishwasher

    5 LOADING YOUR DISHWASHER Two Folding Racks The folding racks allow large items, such For best results, follow these loading as pots and pans, to be placed more easily. guidelines. Each part can be folded separately. They Loading the household dishwasher up to the can either be raised upwards or folded capacity indicated by the manufacturer will down.
  • Page 21 Height Adjustment Dish rack The upper basket includes a mechanism The upper basket racks can either be which enables the height of the basket open, a, or closed, b. Place cups and large to be adjusted up (1) or down (2) without utensils (horizontally) on the racks to be having to remove the basket.

  • Page 22: Alternative Basket Loads

    5.2 Alternative Basket Loads Important Note For Test Lower Basket Laboratories For detailed information required for tests according to EN normatives and a softcopy of the manual, please send the model name and serial number to the following address: dishwasher@standardtest.info Top Basket Incorrect Loads Incorrect loading can cause poor washing...
  • Page 23 EN - 20...
  • Page 24 • The program duration may change according to the amount of dishes, the water temperature, the ambient temperature and selected additional functions. • Values given for programmes other than the eco programme are indicative only. • Eco programme is suitable to clean normally soiled tableware, that for this use, it is the most efficient programme in terms of its combined energy and water consumption, and that it is used to assess compliance with the EU ecodesign legislation.

  • Page 25: Programme Table

    7 THE CONTROL PANEL 3. Delay Button You can delay the start time of the programme for 1-2...24 hours by pressing the delay button (3) before the programme starts. The delay indicator (3.1) will be on. If you want to change the delay time,first press the Start/Pause button and then the delay button to select a new delay time.

  • Page 26: Changing A Programme

    Tablet Indicator selected for 15 to 100 minutes. Select the Tablet Detergent function when * Wash using a combined detergent that contains * Rinse salt, rinse aid or other extras. The Tablet * Dry Detergent Indicator will remain on for as long as it is selected.

  • Page 27: Cancelling A Programme

    NOTE: At the end of washing program- me, you can leave the door of your machine ajar to hasten the drying. Start newly selected programme by NOTE: If the door of machine is opened pressing the Start/Pause button. or power is cut off during washing the programme will continue when the door is The new programme will resume closed or the power is restored.
  • Page 28 Natural Ion Tech (Model Depending) This function provides extra hygiene to the machine thanks to Ion Technology. It opera- tes as an independent program. This func- tion is activated by pressing Options button (6) for 3 seconds in ready state. At the end of 3 seconds, “Ion”...

  • Page 29: Cleaning And Maintenance

    8 CLEANING AND To remove and clean the filter combination, turn it counter clockwise and remove it by MAINTENANCE lifting it upwards (1).Pull the coarse filter out Cleaning your dishwasher is important to of the micro filter (2).Then pull and remove maintain the machine’s service life the metal filter (3).Rinse the filter with lots of Make sure that the water softening setting...

  • Page 30: Drain Pump

    8.3 Drain Pump Large food residues or foreign objects which were not captured by the filters may block the waste water pump. The rinsing water will then be above the filter. Warning Risk of cuts! When cleaning the waste water pump, ensure that you do not injure yourself on p ieces of broken glass or pointed implements.

  • Page 31: Troubleshooting

    9 TROUBLESHOOTING FAULT POSSIBLE CAUSE TROUBLESHOOTING Your Dishwasher is not plugged in. Plug your Dishwasher in. Switch your Dishwasher on by pressing the Your Dishwasher is not switched on. On/Off button. Fuse blown. Check your indoor fuses. The programme does not start.
  • Page 32 FAULT POSSIBLE CAUSE TROUBLESHOOTING Use the correct amount of detergent, as Not enough detergent used. instructed in the programme table. Rinse aid dosage and/or water Increase rinse aid and/or water softener softener setting set too low. level. Whitish stains remains on dishes.
  • Page 33 AUTOMATIC FAULT WARNINGS AND WHAT TO DO TROUBLE POSSIBLE FAULT WHAT TO DO CODE Make sure the water inlet tap is open and water is flowing. Separate the inlet hose from the tap and clean the filter of Water inlet system failure the hose.
  • Page 34 Service Nationwide service in Sweden Visit www.cylinda.se Call 0771-25 25 00 Declare Model code Serial number Purchase date Problem description Name and address Phone number Contact us www.cylinda.se 52431890 R45...
