Asus P11C-C/4L User Manual page 21

Layout contents
Internal connectors / Sockets / Jumpers / LEDs
1. CPU, front, and rear fan connectors
(4-pin FRNT_FAN1-4; REAR_FAN1; CPU_FAN1)
2. Baseboard Management Card header (10-1 pin ASMB9)
3. ATX power connectors (24-pin EATXPWR1; 8-pin EATX12V1)
4. Power Supply SMBus connector (5-pin PSUSMB1)
5. Smart Ride Through (SmaRT) setting (3-pin SMART_PSU1)
6. DDR4 DIMM sockets
7. System Management Bus (SMBUS) connector (5-1 pin SMBUS1)
8. CPU socket
9. SATA DOM power connector (4-pin PWR3)
10. Mini-SAS HD connector (ISATA1)
11. Clear RTC RAM (3-pin CLRTC1)
12. Serial ATA 6.0Gb/s connectors (7-pin SATA5-6 [Gray])
13. SATA DOM power setting (3-pin DOM1_PWR1, DOM1_PWR2)
14. USB 3.0 connector (20-1 pin USB3_34)
15. Auxiliary panel connector (20-2 pin AUX_PANEL1, 20-pin AUX_
PANEL2)
16. System panel connector (20-1 pin PANEL1)
17. Serial General Purpose Input/Output connector (6-1 pin SGPIO1)
18. DMLAN setting (3-pin DM_IP_SEL1)
19. Hard disk activity LED connector (4-pin HDLED1)
20. Chassis intrusion connector (2-pin INTRUSION1)
21. USB 2.0 connector (10-1 pin USB1114; 4-pin Type-A USB7)
22. ME firmware force recovery setting (3-pin ME_RCVR1)
23. PCH_MFG1 setting (3-pin PCH_MFG1)
24. Thermal sensor cable connector (3-pin TR1)
25. Trusted Platform Module connector (14-1 pin TPM1)
26. Serial port connectors (10-1 pin COM1-2)
27. LAN controller setting (3-pin LAN_SW1-4)
28. M.2 (NGFF) connector (NGFF1-2)
29. Micro SD card slot (MSD1)
30. VGA controller setting (3-pin VGA_SW1)
31. VGA connector (16 pin VGA_HDR1)
P11C-C/4L
Page
2-31
2-17
2-34
2-32
2-22
2-8
2-37
2-6
2-33
2-28
2-19
2-28
2-22
2-30
2-36
2-35
2-30
2-23
2-29
2-38
2-29
2-21
2-21
2-38
2-32
2-31
2-20
2-37
2-39
2-20
2-33
2-5
