P11C-C/4L specifications summary
Model Name
SATA Controller
Storage
SAS Controller
TPM Header
PSU Connector
Management
Connector
USB Connector /
Header
Fan Header
Onboard I/O
SMBus
Connectors
Chassis Intruder
Front LAN LED
Serial Port Header 2
Device Power
Connector
VGA Header
M.2 Connector
Micro SD card
External USB Port
Rear I/O
VGA Port
Connectors
RJ-45
Software
Management
Out of Band
Solution
Remote
Management
CPU Temperature
Monitoring
FAN RPM
Environment
* Specifications are subject to change without notice.
** Refer to www.asus.com for the complete list of supported PIKE cards.
®
Intel C242:
- 6 x SATA 6Gb/s ports (4 by miniSAS HD) with 2 x M.2 (NGFF
22110/2280/2260/2242, PCI-E NGFF1 x2 link, NGFF2 x1
link or SATA signal, gray SATA port will disable when M.2
is SATA signal)
®
- Intel RSTe (Windows & Linux)
(Supports software RAID 0, 1, 10 & 5)
Optional kits:
ASUS PIKE II 3008-8i 8-port SAS 12G RAID card
ASUS PIKE II 3108-8i 8-port SAS 12G HW RAID card
1
24-pin ATX power connector + 8-pin ATX 12V power connector
Onboard header for optional management card
1 x USB 3.1 Gen 1 pin header (up to 2 devices)
1 x USB 2.0 pin header (up to 2 devices)
1 x USB 2.0 connector (Type A USB socket)
6 x 4 pin
1
1
4
4-pin power connector
1
2 (NGFF Type 22110)
1
2 x USB 3.1 Gen 2 ports
2 x USB 3.1 Gen 1 ports
1
4 x GbE LAN
1 x Management LAN
ASUS Control Center
Optional ASMB9-iKVM for KVM-over-Internet
Operating temperature: 10°C ~ 35°C
Non operating temperature: -40°C ~ 70°C
Non operating humidity: 20% ~ 90% (Non condensing)
