  • Page 1 P10S-V/4L...
  • Page 2 Product warranty or service will not be extended if: (1) the product is repaired, modified or altered, unless such repair, modification of alteration is authorized in writing by ASUS; or (2) the serial number of the product is defaced or missing.

  • Page 3: Table Of Contents

    ......................vii Safety information ....................viii Electrical safety ..................... viii Operation safety .................... viii Australia statement notice ................ix P10S-V/4L Specifications Summary ................. xi Chapter 1: Product Introduction Welcome! ....................1-3 Package contents ..................1-3 Serial number label ..................1-4 Special features..................1-4 1.4.1...
  • Page 4 3.2.2 Using the dual function power switch .......... 3-4 Chapter 4: BIOS Setup Managing and updating your BIOS ............4-3 4.1.1 ASUS CrashFree BIOS 3 utility........... 4-3 4.1.2 ASUS EzFlash Utility..............4-4 4.1.3 BUPDATER utility ............... 4-5 BIOS setup program .................. 4-7 4.2.1...
  • Page 5 Contents Main menu ....................4-10 4.3.1 System Date [Day xx/xx/xxxx] ........... 4-10 4.3.2 System Time [xx:xx:xx] ............. 4-10 Advanced menu ..................4-11 4.4.1 Trusted Computing..............4-12 4.4.2 Chipset Configuration..............4-12 4.4.3 Platform Configuration .............. 4-20 4.4.4 CPU Configuration ..............4-28 4.4.5 SATA Configuration ..............
  • Page 6 Contact information menu ............6-9 ® 6.3.5 Installing the Intel Chipset device Software driver ....6-10 ® Installing the Intel I210 Gigabit Adapters driver ........6-12 Installing the VGA driver ................. 6-15 Appendix P10S-V/4L block diagram ..................A-2 ASUS contact information ..................A-3...

  • Page 7: Notices

    Radio Interference Regulations of the Canadian Department of Communications. This class B digital apparatus complies with Canadian ICES-003. REACH Complying with the REACH (Registration, Evaluation, Authorization, and Restriction of Chemicals) regulatory framework, we publish the chemical substances in our products at ASUS REACH website at http://csr.asus.com/english/REACH.htm.

  • Page 8: Safety Information

    Safety information Electrical safety • To prevent electrical shock hazard, disconnect the power cable from the electrical outlet before relocating the system. • When adding or removing devices to or from the system, ensure that the power cables for the devices are unplugged before the signal cables are connected. If possible, disconnect all power cables from the existing system before you add a device.

  • Page 9: Australia Statement Notice

    You are also entitled to have the goods repaired or replaced if the goods fail to be of acceptable quality and the failure does not amount to a major failure. If you require assistance please call ASUS Customer Service 1300 2787 88 or visit us at http://support.asus.com...

  • Page 10: Conventions Used In This Guide

    Conventions used in this guide To ensure that you perform certain tasks properly, take note of the following symbols used throughout this manual. DANGER/WARNING: Information to prevent injury to yourself when trying to complete a task. CAUTION: Information to prevent damage to the components when trying to complete a task IMPORTANT: Instructions that you MUST follow to complete a task.

  • Page 11: P10S-V/4L Specifications Summary

    Optional Kits: - ASUS PIKE II 3008 Series SAS 12G RAID card SAS Controller - ASUS PIKE II 3108 Series SAS 12G HW RAID card * Refer to www.asus.com for the complete list of supported CPUs. (continued on the next page)
  • Page 12 ® 4 x Intel I210 Networking Graphic Aspeed AST1400 64MB TPM Header 24-pin ATX power connector + PSU Connector 8-pin ATX 12V power connector SATA DOM Power 4-pin power connector Connector 1 x USB 3.0 pin header (up to 2 devices) USB Connector/ 1 x USB 2.0 pin header (up to 2 devices) Header...

  • Page 13: Chapter 1: Product Introduction

    Chapter 1: Product Introduction Chapter 1: Product Introduction...
  • Page 14 Chapter summary This chapter describes the motherboard features and the new technologies it supports. This chapter contains the following sections: Welcome! ....................1-3 Package contents ..................1-3 Serial number label ..................1-4 Special features..................1-4...

  • Page 15: Welcome

    P10S-V/4L motherboard! The motherboard delivers a host of new features and latest technologies, making it another standout in the long line of ASUS quality motherboards! Before you start installing the motherboard and hardware devices on it, check the items in your package with the list below.

  • Page 16: Serial Number Label

    Serial number label Before requesting support from the ASUS Technical Support team, you must take note of the motherboard's serial number containing 12 characters xxS2xxxxxxxx shown as the figure below. With the correct serial number of the product, ASUS Technical Support team members can then offer a quicker and satisfying solution to your problems.
  • Page 17 The CPU temperature is monitored to prevent overheating and damage. The system fan rotations per minute (RPM) is monitored for timely failure detection. The chip monitors the voltage levels to ensure stable supply of current for critical components. ASUS P10S-V/4L...

  • Page 18: Innovative Asus Features

    1.4.2 Innovative ASUS features ASUS Fan Speed technology The ASUS Fan Speed technology smartly adjusts the fan speeds according to the system loading to ensure quiet, cool, and efficient operation. ASUS MIO Audio card The ASUS MIO audio card is a discrete 8-channel high definition audio (High Definition Audio previously codenamed Azalia) CODEC that enables the clearest high quality audio output.

  • Page 19: Chapter 2: Hardware Information

    Chapter 2: Hardware Information...
  • Page 20 Chapter summary This chapter lists the hardware setup procedures that you have to perform when installing system components. It includes description of the jumpers and connectors on the motherboard. This chapter contains the following sections: Before you proceed ................... 2-3 Motherboard overview ................

  • Page 21: Before You Proceed

    • Unplug the power cord from the wall socket before touching any component. • Use a grounded wrist strap or touch a safely grounded object or a metal object, such as the power supply case, before handling components to avoid damaging them due to static electricity. • Hold components by the edges to avoid touching the ICs on them. • Whenever you uninstall any component, place it on a grounded antistatic pad or in the bag that came with the component. • Before you install or remove any component, ensure that the power supply is switched off or the power cord is detached from the power supply. Failure to do so may cause severe damage to the motherboard, peripherals, and/or components. ASUS P10S-V/4L...

  • Page 22: Motherboard Overview

    Motherboard overview Before you install the motherboard, study the configuration of your chassis to ensure that the motherboard fits into it. To optimize the motherboard features, we highly recommend that you install it in an ATX 1.1 compliant chassis. Ensure to unplug the chassis power cord before installing or removing the motherboard. Failure to do so can cause you physical injury and damage motherboard components! 2.2.1 Placement direction When installing the motherboard, ensure that you place it into the chassis in the correct orientation. The edge with external ports goes to the rear part of the chassis as indicated in the image below.

  • Page 23: Motherboard Layout

    2.2.3 Motherboard layout ASUS P10S-V/4L...

  • Page 24: Layout Contents

    2.2.4 Layout contents Slots/Sockets Page CPU sockets DDR4 sockets 2-14 PCI Express x16 / PCI Express x8 / PCI slot 2-18 Onboard LEDs Page Standby Power LED (SBPWR1) 2-20 Power LED (PLED1) 2-20 Location LED (LOCLED1) 2-21 CATT ERR LED (CATTERR1) 2-21 Jumpers Page Clear RTC RAM (CLRTC1) 2-22 VGA controller setting (3-pin VGA_SW1) 2-23 LAN controller setting (3-pin LAN_SW1, LAN_SW2, LAN_SW3, 2-23 LAN_SW4) ME firmware force recovery setting (3-pin ME_RCVR1) 2-24 Rear panel connectors Page PS/2 keyboard/mouse port 2-25 USB 3.0 ports 1 and 2 2-25 Serial port (COM1) 2-25 Video Graphics Adapter port...
  • Page 25 2-29 USB 3.0 connector (20-1 pin USB3_34, A-Type USB3_5) 2-30 CPU, front, and rear fan connectors (4-pin FRNT_FAN1, REAR_FAN1, CPU_FAN1, FRNT_FAN2, 2-30 FRNT_FAN3. FRNT_FAN4) Serial General Purpose Input/Output connector (6-1 pin SGPIO1) 2-31 Trusted Platform Module connector (14-1 pin TPM) 2-31 VGA connector (16-1 pin VGA_HDR1)) 2-32 SATA DOM power connector (4-pin PWR3) 2-32 10. ATX power connectors (24-pin EATXPWR1, 8-pin EATX12V1) 2-33 11. System panel connector (20-1 pin PANEL1) 2-34 12. Auxiliary panel connector (20-2 pin AUX_PANEL1) 2-35 13. Chassis intrusion connector (2-pin INTRUSION1) 2-36 14. LAN34_LED connector (5-1 pin LAN34_LED1) 2-36 15. LPT connector (26-1 pin LPT1) 2-37 16. S ystem Management Bus (SMBUS) connector 2-37 (5-1 pin SMBUS1) ASUS P10S-V/4L...

  • Page 26: Central Processing Unit (Cpu)

    Central Processing Unit (CPU) ® ® The motherboard comes with a surface mount LGA1151 socket designed for the Intel Xeon ® E3-1200 v5 and Intel Core™ i3 processor. • Upon purchase of the motherboard, ensure that the PnP cap is on the socket and the socket contacts are not bent. Contact your retailer immediately if the PnP cap is missing, or if you see any damage to the PnP cap/socket contacts/motherboard components. ASUS will shoulder the cost of repair only if the damage is shipment/ transit-related. • The product warranty does not cover damage to the socket contacts resulting from incorrect CPU installation/removal, or misplacement/loss/incorrect removal of the PnP cap. 2.3.1 Installing the CPU To install the CPU: Locate the CPU socket on the motherboard. Before installing the CPU, ensure that the socket box is facing toward you and the load lever is on your right. Chapter 2: Hardware Information...
  • Page 27 Retention tab Lift the load lever until the load plate is completely lifted. Load plate Position the CPU above the socket, ensuring that the gold triangle mark is on the bottom-left corner of the socket, then fit the CPU notches to the socket's CPU notches alignment keys. The CPU fits in only one orientation. DO NOT force the CPU into the Gold socket to prevent bending the pins on triangle Alignment the socket and damaging the CPU. mark Alignment ASUS P10S-V/4L...
  • Page 28 Close the load plate (A), ensuring that the front edge of the load plate Load lever slides under the retention lock (B) then push down the load lever (C). Retention lock Insert the load lever under the retention tab to remove the PnP cap from the CPU socket. Load lever Retention tab Apply some Thermal Interface Material to the exposed area of the CPU that the heatsink will be in contact with, ensuring that it is evenly spread in a thin layer. Some heatsinks come with pre- applied Thermal Interface Material. If so, skip this step. The Thermal Interface Material is toxic and inedible. DO NOT eat it. If it gets into your eyes or touches your skin, wash it off immediately and seek professional medical help.

  • Page 29: Installing The Cpu Heatsink

    If you purchased a separate CPU heatsink and fan assembly, ensure that the Thermal Interface Material is properly applied to the CPU heatsink or CPU before you install the heatsink and fan assembly. Ensure that you have installed the motherboard to the chassis before you install the CPU fan and heatsink assembly. To install the CPU heatsink and fan: Place the heatsink on top of the installed CPU, making sure that the four fasteners match the holes on the motherboard. Push down two fasteners at a time in a diagonal sequence to secure the heatsink and fan assembly in place. Orient the heatsink and fan assembly such that the CPU fan cable is closest to the CPU fan connector. 2-11 ASUS P10S-V/4L...

  • Page 30: Uninstalling The Cpu Heatsink And Fan

    Connect the CPU fan cable to the connector on the motherboard labeled CPU_FAN1. DO NOT forget to connect the CPU fan connector! Hardware monitoring errors can occur if you fail to plug this connector. 2.3.3 Uninstalling the CPU heatsink and fan To uninstall the CPU heatsink and fan: 1. Disconnect the CPU fan cable from the connector on the motherboard. Rotate each fastener counterclockwise. Pull up two fasteners at a time in a diagonal sequence to disengage the heatsink and fan assembly from the motherboard. Carefully remove the heatsink and fan assembly from the motherboard.

  • Page 31: Installing The Cpu Heatsink In Rack

    The Intel LGA1151 processor requires a specially designed heatsink to ensure optimum ® thermal condition and performance. • Ensure that you use qualified heatsink assembly only. • Ensure that you have applied the thermal interface material to the top of the CPU before installing the heatsink and fan. Peel off the sticker on the heatsink metal plate and affix the plate to the back of the motherboard, matching the standoffs to the heatsink screw holes. Use a Phillips screwdriver to tighten the four heatsink screws using the recommended sequence below. 1. Ensure that the heatsink is not skewed or tilted, otherwise the CPU will overheat. 2. Do not overtighten the screws. Doing so can damage the CPU. 2-13 ASUS P10S-V/4L...

  • Page 32: System Memory

    System memory 2.4.1 Overview The motherboard comes with four Double Data Rate 4 (DDR4) Dual Inline Memory Modules (DIMM) sockets. A DDR4 module is notched differently from a DDR, DDR2, or DDR3 module. DO NOT install a DDR, DDR2, or DDR3 memory module to the DDR4 slot. The figure illustrates the location of the DDR4 DIMM sockets: 2.4.2 Memory configurations You may install unbuffered DDR4 DIMMs into the DIMM sockets using the memory configurations in this section. UDIMM DIMM Slot Per DIMM Populated DIMM Type Speed Rank per DIMM Channel per Channel Unbuffered DDR4 2133 Single Rank, Dual Rank Unbuffered DDR4 2133 Single Rank, Dual Rank • Always install DIMMs with the same CAS latency. For optimum compatibility, it is recommended that you obtain memory modules from the same vendor. •...

  • Page 33: Installing A Dimm On A Single Clip Dimm Socket

    Hold the DIMM by both of its ends then insert the DIMM vertically into the socket. Apply force to both ends of the DIMM simultaneously until the retaining clip snaps back into place and the DIMM cannot be pushed in any further to ensure proper sitting of the DIMM. Locked Retaining Clip Always insert the DIMM into the socket vertically to prevent DIMM notch damage. • To install two or more DIMMs, refer to the user guide bundled in the motherboard package. • Refer to the user guide for qualified vendor lists of the memory modules. Removing a DIMM from a single clip DIMM socket Press the retaining clip outward to unlock the DIMM. Remove the DIMM from the socket. Support the DIMM lightly with your fingers when pressing the retaining clips. The DIMM might get damaged when it flips out with extra force. 2-15 ASUS P10S-V/4L...

  • Page 34: Expansion Slots

    Expansion slots In the future, you may need to install expansion cards. The following subsections describe the slots and the expansion cards that they support. Ensure to unplug the power cord before adding or removing expansion cards. Failure to do so may cause you physical injury and damage motherboard components. 2.5.1 Installing an expansion card To install an expansion card: Before installing the expansion card, read the documentation that came with it and make the necessary hardware settings for the card.

  • Page 35: Interrupt Assignments

    2.5.3 Interrupt assignments Standard Interrupt assignments Priority Standard function System Timer Keyboard Controller Programmable Interrupt Communications Port (COM1) Print Port (LPT1) System CMOS/Real Time Clock ACPI Mode when used IRQ Holder for PCI Steering IRQ Holder for PCI Steering PS/2 Compatible Mouse Port Numeric Data Processor * These IRQs are usually available for ISA or PCI devices. 2-17 ASUS P10S-V/4L...

  • Page 36: Pci Express X16 Slot (X16 Link)

    2.5.4 PCI Express x16 slot (x16 link) The onboard PCIE 6 provides one x16 Gen3 link to CPU. This slot supports VGA cards and various server class high performance add-on cards. 2.5.5 PCI Express x8 slot (x4 link) The onboard PCIE 5 provide one x4 Gen3 link to the PCH. These slots support various server class high performance add-on cards. 2.5.6 PCI slot The onboard PCI 1, PCI 2, PCI 3 and PCI 4 supports cards such as LAN, USB, and other cards that complies with PCI specifications. No.(Slot location) Short Description 1 (slot 7) MIO1 1 x MIO slot 2 (slot 6) PCIE6 1 x PCI-E x16 (x16 Gen3 link)

  • Page 37: Installing The Audio Card

    2.5.7 Installing the Audio card Locate the MIO card slot on the motherboard and align the golden fingers of the audio card with the MIO card slot. Insert the audio card into the MIO slot on the motherboard. Ensure that it is completely seated on the card slot. Secure the audio card to the chassis with a screw. 2-19 ASUS P10S-V/4L...

  • Page 38: Onboard Leds

    Onboard LEDs Standby Power LED (SBPWR1) The motherboard comes with a standby power LED. The green LED lights up to indicate that the system is ON, in sleep mode, or in soft-off mode. This is a reminder that you should shut down the system and unplug the power cable before removing or plugging in any motherboard component. The illustration below shows the location of the onboard LED. Power LED (PLED1) This LED lights up when the Power-on button is pressed and the system is on. 2-20 Chapter 2: Hardware Information...
  • Page 39 Location LED (LOCLED1) The Location LED is an onboard LED that lights up when the Location Button on the front panel is pressed. This LED helps you visually locate the server among other servers especially when you are located at the back of the server rack. CATT ERR LED (CATTERR1) The CATT ERR LED indicates that the system has experienced a fatal or catastrophic error and cannot continue to operate. 2-21 ASUS P10S-V/4L...

  • Page 40: Jumpers

    Jumpers Clear RTC RAM (3-pin CLRTC1) This jumper allows you to clear the Real Time Clock (RTC) RAM in CMOS. You can clear the CMOS memory of date, time, and system setup parameters by erasing the CMOS RTC RAM data. The onboard button cell battery powers the RAM data in CMOS, which include system setup information such as system passwords. To erase the RTC RAM: Turn OFF the computer and unplug the power cord. Move the jumper cap from pins 1–2 (default) to pins 2–3. Keep the cap on pins 2–3 for about 5–10 seconds, then move the cap back to pins 1–2. Plug the power cord and turn ON the computer. Hold down the <Del> key during the boot process and enter BIOS setup to re- enter data. Except when clearing the RTC RAM, never remove the cap on CLRTC jumper default position. Removing the cap will cause system boot failure! If the steps above do not help, remove the onboard battery and move the jumper again to clear the CMOS RTC RAM data. After the CMOS clearance, reinstall the battery. 2-22 Chapter 2: Hardware Information...
  • Page 41 VGA controller setting (3-pin VGA_SW1) This jumper allows you to enable or disable the onboard VGA controller. Set to pins 1–2 to activate the VGA feature. LAN controller setting (3-pin LAN_SW1, LAN_SW2, LAN_SW3, LAN_SW4) ® These jumpers allows you to enable or disable the onboard Intel I210 Gigabit LAN controllers. Set to pins 1-2 to activate the Gigabit LAN feature. 2-23 ASUS P10S-V/4L...
  • Page 42 ME firmware force recovery setting (3-pin ME_RCVR1) This jumper allows you to force Intel Management Engine (ME) boot from recovery mode when ME become corrupted. 2-24 Chapter 2: Hardware Information...

  • Page 43: Connectors

    LAN port LED indications ACT/LINK SPEED Activity/Link LED Speed LED Status Description Status Description LAN 2 LAN 4 No link 10 Mbps connection LAN 3 LAN 1 GREEN Linked ORANGE 100 Mbps connection BLINKING Data activity GREEN 1 Gbps connection SPEED ACT/LINK 2-25 ASUS P10S-V/4L...

  • Page 44: Q-Code Table

    2.8.2 Q-Code table Action PHASE POST CODE TYPE DESCRIPTIONz Progress First post code(POWER_ON_POST_CODE) Progress Load BSP microcode(MICROCODE_POST_CODE) Progress Perform early platform initialization Security Phase Progress Set cache as ram for PEI phase(CACHE_ENABLED_POST_CODE) Progress Establish Stack Progress CPU Early init.(CPU_EARLY_INIT_POST_CODE) Progress PEI Core Entry Progress PEI cache as ram CPU initial Progress NB initialize before installed memory Progress SB initialize before installed memory MRC Progress MRC_INITIALIZATION_START MRC Progress MRC_CMD_PLOT_2D MRC Progress MRC_FAST_BOOT_PERMITTED MRC Progress MRC_RESTORE_NON_TRAINING MRC Progress MRC_PRINT_INPUT_PARAMS...
  • Page 45 Selection) phase Progress Reset system Progress USB hotplug Progress NVRAM clean up Progress NVRAM configuration reset Progress IDE, AHCI Init. Progress IDE, AHCI Init. Progress IDE, AHCI Init. Progress IDE, AHCI Init. FF~00 Progress Wait BMC ready(duration: 120 seconds). Progress BIOS Setup Utility password verify Progress BIOS Setup Utility start Progress BIOS Setup Utility input wait Progress Ready to boot event Progress Legacy boot event Progress APIC mode Operating system phase Progress PIC mode 2-27 ASUS P10S-V/4L...

  • Page 46: Internal Connectors

    2.8.3 Internal connectors Serial ATA 6.0 Gbps connectors (7-pin SATA 6Gbps_1-8 connector [Light Blue]) ® Supported by the Intel C236 chipset, these connectors are for the Serial ATA signal cables for Serial ATA hard disk drives that allows up to 6Gb/s of data transfer rate. If you installed Serial ATA hard disk drives, you can create a RAID 0, RAID 1, RAID 10, or RAID 5 configuration. The actual data transfer rate depends on the speed of Serial ATA hard disks installed. 2-28 Chapter 2: Hardware Information...
  • Page 47 Hard disk activity LED connector (4-pin HDLED1) This LED connector is for the storage add-on card cable connected to the SATA or SAS add-on card. The read or write activities of any device connected to the SATA or SAS add-on card causes the front panel LED to light up. USB 2.0 connector (10-1 pin USB78) These connectors are for USB 2.0 ports. Connect the USB module cables to these connectors. These USB connectors comply with USB 2.0 specification that supports up to 480 Mbps connection speed. 2-29 ASUS P10S-V/4L...
  • Page 48 USB-chargeable devices, optimized power efficiency, and backward compatibility with USB 2.0. CPU, front, and rear fan connectors (4-pin FRNT_FAN1, REAR_FAN1, CPU_FAN1, FRNT_FAN2, FRNT_FAN3, FRNT_ FAN4) The fan connectors support cooling fans. Connect the fan cables to the fan connectors on the motherboard, ensuring that the black wire of each cable matches the ground pin of the connector. • DO NOT forget to connect the fan cables to the fan connectors. Insufficient air flow inside the system may damage the motherboard components. • These are not jumpers! DO NOT place jumper caps on the fan connectors! • All fans feature the ASUS Smart Fan technology. 2-30 Chapter 2: Hardware Information...
  • Page 49 Serial General Purpose Input/Output connector (6-1 pin SGPIO1) The SGPIO 1 connector is used for the Intel Rapid Storage Technology Enterprise SGPIO interface that controls the LED pattern generation, device information, and general purpose data. Trusted Platform Module connector (14-1 pin TPM) This connector supports a Trusted Platform Module (TPM) system, which can securely store keys, digital certificates, passwords, and data. A TPM system also helps enhance network security, protects digital identities, and ensures platform integrity. 2-31 ASUS P10S-V/4L...
  • Page 50 VGA connector (16-1 pin VGA_HDR1) This connector supports the VGA High Dynamic-Range interface. SATA DOM power connector (4-pin PWR3) This 4-pin connector is for 5V power of a certain SATA DOM (Disk on Module) device when using an appropriate cable. • The SATA DOM power connector is for output power only. It has a maximum output current of 1A. • Ensure that the power of the SATA DOM device that you will use is less than 1A. 2-32 Chapter 2: Hardware Information...
  • Page 51 ATX power connectors (24-pin EATXPWR1, 8-pin EATX12V1) These connectors are for the ATX power supply plugs. The power supply plugs are designed to fit these connectors in only one orientation. Find the proper orientation and push down firmly until the connectors completely fit. • DO NOT forget to connect the 24-pin and the 8-pin power plugs; otherwise, the system will not boot up. • Use of a power supply unit (PSU) with a higher power output is recommended when configuring a system with more power-consuming devices. The system may become unstable or may not boot up if the power is inadequate. • This motherboard supports ATX2.0 PSU or later version. • Ensure that your PSU can provide at least the minimum power required by your system. 2-33 ASUS P10S-V/4L...

  • Page 52: System Panel Connector

    System panel connector (20-1 pin PANEL1) This connector supports several chassis-mounted functions. System power LED (3-pin PLED) This 3-pin connector is for the system power LED. Connect the chassis power LED cable to this connector. The system power LED lights up when you turn on the system power, and blinks when the system is in sleep mode. Message LED (2-pin MLED) This 2-pin connector is for the message LED cable that connects to the front message LED. The message LED is controlled by Hardware monitor to indicate an abnormal event occurrence. System warning speaker (4-pin SPEAKER) This 4-pin connector is for the chassis-mounted system warning speaker. The speaker allows you to hear system beeps and warnings.
  • Page 53 LED and switch, chassis intrusion, and LAN LEDs. Front panel SMB (6-1 pin FPSMB) These LEDs connect the front panel SMBus cable. LAN activity LED (2-pin LAN1LINK and 2-pin LAN2LINK) These LEDs are for Gigabit LAN activity LEDs on the front panel. Locator LED (2-pin AUX_LOCLED1 and 2-pin AUX_LOCLED2) These LEDs are for the Locator LED1 and LED2 on the front panel. Connect the Locator LED cables to these 2-pin connector. The LEDs will light up when the Locator button is pressed. Locator Button/Switch (2-pin AUX_BMCLOCBNT) These LEDs are for the locator button on the front panel. This button queries the state of the system locator. 2-35 ASUS P10S-V/4L...
  • Page 54 Chassis intrusion connector (2-pin INTRUSION1) This connector is for a chassis-mounted intrusion detection sensor or switch. Connect one end of the chassis intrusion sensor or switch cable to this connector. The chassis intrusion sensor or switch sends a high-level signal to this connector when a chassis component is removed or replaced. The signal is then generated as a chassis intrusion event.
  • Page 55 LPT connector (26-1 pin LPT1) The LPT (Line Printing Terminal) connector supports devices such as a printer. LPT standardizes as IEEE 1284, which is the parallel port interface on IBM PC-compatible computers. System Management Bus (SMBUS) connector (5-1 pin SMBUS1) This connector controls the system and power management-related tasks. This connector processes the messages to and from devices rather than tripping the individual control lines. 2-37 ASUS P10S-V/4L...
  • Page 56 2-38 Chapter 2: Hardware Information...

  • Page 57: Chapter 3: Powering Up

    Chapter 3: Powering Up Chapter 3: Powering Up...
  • Page 58 Chapter summary This chapter describes the power up sequence, and ways of shutting down the system. This chapter contains the following sections: Starting up for the first time ..............3-3 Powering off the computer ................ 3-4...

  • Page 59: Starting Up For The First Time

    No DIMM Detected. 1 short, 8 short No VGA Detected. 2 long Chassis Intrusion. 2 long BIOS-image Crash Detected. At power on, hold down the <Del> key to enter the BIOS Setup. Follow the instructions in Chapter 4. ASUS P10S-V/4L...

  • Page 60: Powering Off The Computer

    Powering off the computer 3.2.1 Using the OS shut down function ® Using Windows Server 2008 R2: Click the Start button, move the cursor to the triangle on the right of Log off, then click Shut Down. From the Shutdown Event Tracker, select the option that best describes why you want to shut down the computer.

  • Page 61: Chapter 4: Bios Setup

    Chapter 4: BIOS Setup...
  • Page 62 Chapter summary This chapter tells how to change the system settings through the BIOS Setup menus. Detailed descriptions of the BIOS parameters are also provided. This chapter contains the following sections: Managing and updating your BIOS ............4-3 BIOS setup program .................. 4-7 Main menu ....................

  • Page 63: Managing And Updating Your Bios

    BIOS in the future. Copy the original motherboard BIOS using the BUPDATER utility. 4.1.1 ASUS CrashFree BIOS 3 utility The ASUS CrashFree BIOS 3 is an auto recovery tool that allows you to restore the BIOS file when it fails or gets corrupted during the updating process. You can update a corrupted BIOS file using a USB flash drive that contains the updated BIOS file.

  • Page 64: Asus Ezflash Utility

    To update the BIOS using EzFlash Utility: Insert the USB flash disk that contains the latest BIOS file to the USB port. Enter the BIOS setup program. Go to the Tool menu to select ASUS EzFlash Utility and press <Enter> to enable it. ASUS Tek. EzFlash Utility...

  • Page 65: Bupdater Utility

    The BUPDATER utility allows you to update the BIOS file in DOS environment using a bootable USB flash disk drive with the updated BIOS file. Updating the BIOS file To update the BIOS file using the BUPDATER utility: Visit the ASUS website at www.asus.com and download the latest BIOS file for the motherboard. Save the BIOS file to a bootable USB flash disk drive. Download the BUPDATER utility (BUPDATER.exe) from the ASUS support website at support.asus.com to the bootable USB flash disk drive you created earlier. Boot the system in DOS mode, then at the prompt, type: BUPDATER /i[filename].CAP where [filename] is the latest or the original BIOS file on the bootable USB flash disk drive, then press <Enter>. A:\>BUPDATER /i[file name]CAP...
  • Page 66 The utility verifies the file, then starts updating the BIOS file. ASUS Tek. EzFlash Utility Current Platform New Platform Platform : P10S-V/4L Platform : P10S-V/4L Version : 0200 Version : 0206 Build date: 07/20/2015 Build date: 08/01/2015 Start Programming Flash. DO NOT SHUTDOWN THE SYSTEM!!! Write DO NOT shut down or reset the system while updating the BIOS to prevent system boot failure! The utility returns to the DOS prompt after the BIOS update process is completed.

  • Page 67: Bios Setup Program

    If the system becomes unstable after changing any BIOS settings, load the default settings to ensure system compatibility and stability. Press <F5> and select Yes to load the BIOS default settings. • The BIOS setup screens shown in this section are for reference purposes only, and may not exactly match what you see on your screen. • Visit the ASUS website (www.asus.com) to download the latest BIOS file for this motherboard. ASUS P10S-V/4L...

  • Page 68: Bios Menu Screen

    4.2.1 BIOS menu screen General help Configuration fields Menu items Menu bar Navigation keys 4.2.2 Menu bar The menu bar on top of the screen has the following main items: Main For changing the basic system configuration Advanced For changing the advanced system settings For changing the security settings Security Boot For changing the system boot configuration...

  • Page 69: Menu Items

    At the top right corner of the menu screen is a brief description of the selected item. 4.2.7 Configuration fields These fields show the values for the menu items. If an item is user-configurable, you can change the value of the field opposite the item. You cannot select an item that is not user- configurable. A configurable field is enclosed in brackets, and is highlighted when selected. To change the value of a field, select it and press <Enter> to display a list of options. 4.2.8 Pop-up window Select a menu item and press <Enter> to display a pop-up window with the configuration options for that item. 4.2.9 Scroll bar A scroll bar appears on the right side of a menu screen when there are items that do not fit on the screen. Press the Up/Down arrow keys or <Page Up> /<Page Down> keys to display the other items on the screen. ASUS P10S-V/4L...

  • Page 70: Main Menu

    Main menu When you enter the BIOS Setup program, the Main menu screen appears. The Main menu provides you an overview of the basic system information, and allows you to set the system date and time. 4.3.1 System Date [Day xx/xx/xxxx] Allows you to set the system date. 4.3.2 System Time [xx:xx:xx] Allows you to set the system time. 4-10 Chapter 4: BIOS Setup...

  • Page 71: Advanced Menu

    Advanced menu The Advanced menu items allow you to change the settings for the CPU and other system devices. Take caution when changing the settings of the Advanced menu items. Incorrect field values can cause the system to malfunction. ASUS P10S-V/4L 4-11...

  • Page 72: Trusted Computing

    4.4.1 Trusted Computing Configuration Security Device Support [Enabled] Allows you to enable or disable the BIOS support for security device. Configuration options: [Disabled] [Enabled] Device Select [Auto] Allows you to restrict support to selected device. Auto will support both devices. Configuration options: [TPM 1.2] [TPM 2.0] [Auto] 4.4.2 Chipset Configuration System Agent (SA) Configuration Allows you to set System Agent (SA) parameters.
  • Page 73 DMI Vcm Control [Enabled] Allows you to enable or disable DMI Vcm. Configuration options: [Enabled] [Disabled] DMI Link ASPM Control [L1] This item is for the control of the Active State Power Management on SA side of the DMI link. Configuration options: [Disabled] [L1] ASUS P10S-V/4L 4-13...
  • Page 74 PEG Port Configuration PEG 0:1:0 Enable Root Port [Auto] Allows you to enable or disable the root port. Configuration options: [Disabled] [Enabled] [Auto] Max Link speed [Auto] Allows you to configure PEG 0:1:0 Max Speed. Configuration options: [Auto] [Gen1] [Gen2] [Gen3] ASPM [Auto] Allows you to configure the PCIE ASPM. Configuration options: [Disabled] [Auto] [ASPM L0s] [ASPM L1] [ASPM L0sL1] Max Link Width [Auto] Allows you to force PEG link to retrain selected value. Configuration options: [Auto] [Force X1] [Force X2] [Force X4] [Force X8] Power Down Unused Lanes [Auto] Allows you to power down unused lanes.

  • Page 75: Memory Configuration

    Allows you to select when to program the PCIe ASPM. [Disabled] PCIe ASPM will be programmed before OpROM. [Enabled] PCIe ASPM will be programmed after OpROM. PCIe Spread Spectrum Clocking Control [Enabled] Allows you to enable or disable the Spread Spectrum Clocking for compliance testing. Configuration options: [Disabled] [Enabled] Memory Configuration Maximum Memory Frequency [Auto] Allows you to set the maximum memory frequency. Configuration options: [Auto] [1067] [1200] [1333] [1400] [1600] [1800] [1867] [2000] [2133] [2200] [2400] [2600] ASUS P10S-V/4L 4-15...

  • Page 76: Pci Express Configuration

    Max TOLUD [Dynamic] Allows you to set the maximum value of TOLUD. Dynamic assignment would adjust TOLUD automatically based on largest MMIO length of installed graphic controller. Configuration options: [Dynamic] [1 GB] [1.25 GB] [1.5 GB] [1.75 GB] [2 GB] [2.25 GB] [2.5 GB] [2.75 GB] [3 GB] [3.25 GB] [3.5 GB] Memory Scrambler [Enabled] Set this item to enable or disable memory scrambler support. Configuration options: [Enabled] [Disabled] Memory Remap [Enabled] Allows you to enable or disable memory remap above 4GB.
  • Page 77 Allows you to enable or disable the corresponding USB port from reporting a Device Connection to the controller Configuration options: [Disabled] [Select Per-Pin] CLKRUN# Logic [Enabled] Allows you to enable or disable the CLKRUN# logic to stop the PCI clocks. Configuration options: [Disabled] [Enabled] Serial IRQ Mode [Continuous] Allows you to configure Serial IRQ mode. Configuration options: [Quiet] [Continuous] High Precision Timer [Enabled] Allows you to enable or disable the High Precision Event Timer. Configuration options: [Disabled] [Enabled] ASUS P10S-V/4L 4-17...
  • Page 78 Intel Server Platform Services Intel TXT Information 4-18 Chapter 4: BIOS Setup...
  • Page 79 This allows you to prioritize between the onboard and offboard video device to be found. Configuration options: [Onboard Device] [Offboard Device] PCIe slot opROM option PCIE5/ PCIE6 Option ROM [Enabled] Allows you to enable or disable the PCIE5 / PCIE6 Option ROM. Configuration options: [Disabled] [Enabled] ASUS P10S-V/4L 4-19...

  • Page 80: Platform Configuration

    4.4.3 Platform Configuration USB Configuration Legacy USB Support [Enabled] [Disabled] The USB devices can be used only for the BIOS setup program. It cannot be recognized in boot devices list. [Enabled] Enables the support for USB devices on legacy operating systems (OS). [Auto] Allows the system to detect the presence of USB devices at startup. If detected, the USB controller legacy mode is enabled. If no USB device is detected, the legacy USB support is disabled. XHCI Hand-off [Disabled] This item is set to [Disabled] by default for the EHCI (enhanced host controller interface) support by XHCI drivers in operating systems.
  • Page 81 USB transfer time-out [20 sec] Allows you to select the USB transfer time-out value. Configuration options: [1 sec] [5 sec] [10 sec] [20 sec] Device reset time-out [20 sec] Allows you to select the USB device reset time-out value. Configuration options: [10 sec] [20 sec] [30 sec] [40 sec] Device power-up delay [Auto] This allows you to set the maximum time the device will take before it properly reports itself to the Host Controller. Configuration options: [Auto] [Manual] Mass Storage Devices Allows you to select the mass storage device emulation type for devices connected. Configuration options: [Auto] [Floppy] [Forced FDD] [Hard Disk] [CD-ROM] ASUS P10S-V/4L 4-21...

  • Page 82: Onboard Lan Configuration

    Onboard LAN Configuration Intel LAN1 Enable [Enabled] Allows you to enable or disable the Intel LAN. Configuration options: [Disabled] [Enabled] Intel LAN ROM Type [PXE] Allows you to select the Intel LAN ROM type. Configuration options: [Disabled] [PXE] [iSCSI] Intel LAN2 / LAN3 / LAN4 Enable [Enabled] Allows you to enable or disable the Intel LAN.
  • Page 83 The following item appears only when you set Console Redirection to [Enabled]. Console Redirection Settings This item becomes configurable only when you enable the Console Redirection item. The settings specify how the host computer and the remote computer (which the user is using) will exchange data. Both computers should have the same or compatible settings. ASUS P10S-V/4L 4-23...
  • Page 84 Terminal Type [VT-UTF8] Allows you to set the terminal type. [VT100] ASCII char set. [VT100+] Extends VT100 to support color, function keys, et. [VT-UTF8] Uses UTF8 encoding to map Unicode chars onto 1 or more bytes [ANSI] Extended ASCII char set Bits per second [57600] Selects serial port transmission speed. The speed must be matched on the other side. Long or noisy lines may require lower speeds. Configuration options: [9600] [19200] [38400] [57600] [115200] Data Bits [8] Configuration options: [7] [8]...
  • Page 85 Configuration options: [COM1] Serial Port for Out-of-Band Management/ Windows Emergency Management Services (EMS) Console Redirection [Disabled] Allows you to enable or disable the console redirection feature. Configuration options: [Disabled] [Enabled] The following item appears only when you set Console Redirection to [Enabled]. ASUS P10S-V/4L 4-25...

  • Page 86: Acpi Settings

    Console Redirection Settings Terminal Type [VT-UTF8] Allows you to set the terminal type for out-of-band management. Configuration options: [VT100] [VT100+] [VT-UTF8] [ANSI] Bits per second [115200] Allows you to set the serial port transmission speed. Configuration options: [9600] [19200] [57600] [115200] Flow Control [None] Allows you to set the flow control to prevent data loss from buffer overflow. Configuration options: [None] [Hardware RTS/CTS] [Software Xon/Xoff] ACPI Settings Enable Hibernation [Enabled] Allows you to enable or disable the ability of the system to hibernate (OS/S4 Sleep State).

  • Page 87: Smart Settings

    This item functions only if there is a serial port (COM1) connector on the motherboard Power On By RTC [Disabled] [Disabled] Disables RTC to generate a wake event. [Enabled] W hen set to [Enabled], the items RTC Alarm Date (Days) and Hour/Minute/ Second will become user-configurable with set values. SMART Settings SMART Self Test [Enabled] Allows you to run SMART Self Test on all HDDs during POST. Configuration options: [Disabled] [Enabled] ASUS P10S-V/4L 4-27...

  • Page 88: Cpu Configuration

    WHEA Configurations WHEA Support [Enabled] This item allows you to enable or disable the WHEA support. Configuration options: [Disabled] [Enabled] 4.4.4 CPU Configuration The items in this menu show the CPU-related information that the BIOS automatically detects. Some items may not appear if your CPU does not support the related functions. Navigate to the second page of the screen to see the rest of items in this menu by pressing the Up or Down arrow keys.
  • Page 89 CPU AES [Enabled] Allows you to enable or disable the CPU Advance Encryption Standard instructions. Configuration options: [Disabled] [Enabled] Boot performance mode [Turbo Performance] Allows you to select the CPU performance state during system boot before the operating system takes control. The CPU runs at a selected performance ratio based on CPU configuration. Configuration options: [Max Battery] [Max Non-Turbo Performance] [Turbo Performance] ASUS P10S-V/4L 4-29...
  • Page 90 HardWare P states (HWP) [Disabled] Allows you to enable or disable HWP support. Configuration options: [Disabled] [Enabled] Intel(R) SpeedStep(tm) [Enabled] Allows your system to adjust the CPU’s voltage and cores frequency, resulting in decreased power consumption and heat production. [Disabled] The CPU runs at its default speed. [Enabled] The system controls the CPU speed. The following item appears only when you set Intel(R) SpeedStep(tm) to [Enabled]. Turbo Mode [Enabled] This item allows you to automatically set the CPU cores to run faster than the base operating frequency when it is below the operating power, current and temperature specification limit.
  • Page 91 Configuration options: [Disabled] [Enabled] Package C state undemotion [Disabled] Allows you to enable or disable the Package C state undemotion. Configuration options: [Disabled] [Enabled] CState Pre-Wake [Enabled] Allows you to enable or disable the CState Pre-Wake. Selecting [Disabled] will set bit 30 of POWER_CTL MSR(0x1FC) to 1 to disable the CState Pre-Wake. Configuration options: [Disabled] [Enabled] Package C State limit [AUTO] Allows you set the Package C State limit. Configuration options: [C0/C1] [C2] [C3] C6] [C7] [C7s] [C8] [AUTO] CFG lock [Enabled] Allows you to configure MSR 0xE2[15], CFG lock bit. Configuration options: [Disabled] [Enabled] Intel TXT(LT) Support [Disabled] Allows you to enable or disable the Intel(R) TXT(LT) support. Configuration options: [Disabled] [Enabled] ASUS P10S-V/4L 4-31...

  • Page 92: Sata Configuration

    4.4.5 SATA Configuration SATA Controller(s) [Enabled] Allows you to enable or disable the SATA Device. Configuration options: [Enabled] [Disabled] SATA Mode Selection [AHCI] This item allows you to set the SATA configuration. [AHCI] S et to [AHCI] when you want the SATA hard disk drives to use the AHCI (Advanced Host Controller Interface). The AHCI allows the onboard storage driver to enable advanced Serial ATA features that increases storage performance on random workloads by allowing the drive to internally optimize the order of commands.
  • Page 93 HDD Unlock [Enabled] Selecting [Enabled] will indicate that the HDD password unlock in the OS is enabled. Configuration options: [Disabled] [Enabled] LED Locate [Enabled] Selecting [Enabled] will indicate that the LED/SGPIO hardware is attached and ping to locate feature is enabled on the OS. Configuration options: [Disabled] [Enabled] IRRT Only on eSATA [Enabled] [Disabled] Any RAID volume can span internal and eSATA drives. [Enabled] Only IRRT volumes can span internal and eSATA drives. ASUS P10S-V/4L 4-33...

  • Page 94: Network Stack Configuration

    Smart Response Technology [Enabled] Allows you to enable or disable the Smart Response Technology. Configuration options: [Disabled] [Enabled] OROM UI Normal Delay [4 sec] Allows you to select the delay time of the OROM UI Splash Screen in a normal status. Configuration options: [2 sec] [4 sec] [6 sec] [8 sec] RST Force Form [Disabled] Allows you to enable or disable Form for Intel Rapid Storage Technology.

  • Page 95: Csm Configuration

    The values range from 0 to 5. Media detect count [1] Set the number of times presence of media will be checked. Use the <+> or <-> to adjust the value. The values range from 1 to 50. 4.4.7 CSM Configuration CSM Support [Enabled] This option allows you to enable or disable CSM Support. Configuration options: [Disabled] [Enabled] ASUS P10S-V/4L 4-35...

  • Page 96: Iscsi Configuration

    GateA20 Active [Upon Request] This allows you to set the GA20 option. [Upon Request] GA20 can be disabled using BIOS services. [Always] D o not allow disabling GA20; this option is useful when any RT code is executed above 1MB Option ROM Messages [Force BIOS] This allows you to set the display mode for option ROM. Configuration options: [Force BIOS] [Keep Current] Boot Option filter [Legacy only] This option allows you to control the Legacy/UEFI ROMs priority.

  • Page 97: Security Menu

    Select the Administrator Password item and press <Enter>. From the Create New Password box, key in a password, then press <Enter>. Confirm the password when prompted. To change an administrator password: Select the Administrator Password item and press <Enter>. From the Enter Current Password box, key in the current password, then press <Enter>. From the Create New Password box, key in a new password, then press <Enter>. Confirm the password when prompted. To clear the administrator password, follow the same steps as in changing an administrator password, but press <Enter> when prompted to create/confirm the password. ASUS P10S-V/4L 4-37...

  • Page 98: User Password

    User Password To set a user password: Select the User Password item and press <Enter>. From the Create New Password box, key in a password, then press <Enter>. Confirm the password when prompted. To change a user password: Select the User Password item and press <Enter>. From the Enter Current Password box, key in the current password, then press <Enter>. From the Create New Password box, key in a new password, then press <Enter>. Confirm the password when prompted. To clear a user password: Select the Clear User Password item and press <Enter>. Select Yes from the Warning message window then press <Enter>.

  • Page 99: Boot Menu

    Platform Key (PK) / Key Exchange Keys / Authorized Signatures / Forbidden Signatures / Authorized TimeStamps Configuration options: [Set New] [Delete] [Append] Boot Menu The Boot menu items allow you to change the system boot options. Bootup NumLock State [On] Allows you to select the power-on state for the NumLock. Configuration options: [Off] [On] ASUS P10S-V/4L 4-39...

  • Page 100: Boot Option Priorities

    These items specify the boot device priority sequence from the available devices. The number of device items that appears on the screen depends on the number of devices installed in the system. • To select the boot device during system startup, press <F8> when ASUS Logo appears. • To access Windows OS in Safe Mode, please press <F8> after POST. Set the booting order of network devices.

  • Page 101: Monitor Menu

    Configuration options: [Generic Mode] [High Speed Mode] [Full Speed Mode] Tool menu The Tool menu items allow you to configure options for special functions. Select an item then press <Enter> to display the submenu. ASUS EZ Flash Allows you to run ASUS EZ Flash BIOS ROM Utility when you press <Enter>. Refer to the ASUS EZ Flash Utility section for details. ASUS P10S-V/4L 4-41...

  • Page 102: Save & Exit Menu

    Save & Exit menu The Exit menu items allow you to save or discard your changes to the BIOS items. Pressing <Esc> does not immediately exit this menu. Select one of the options from this menu or <F10> from the legend bar to exit. Discard Changes and Exit Exit System setup without saving any changes.

  • Page 103: Event Logs Menu

    Change this to enable or disable all features of Smbios Event Logging during boot. Configuration options: [Disabled] [Enabled] Erasing Settings Erase Event Log [No] Choose options for erasing Smbios Event Log. Erasing is done prior to any logging activation during reset. Configuration options: [No] [Yes, Next reset] [Yes, Every reset] ASUS P10S-V/4L 4-43...
  • Page 104 When Log is Full [Do Nothing] Allows you to choose options for reactions to a full Smbios Event Log. Configuration options: [Do Nothing] [Erase Immediately] Smbios Event Log Standard Settings Log System Boot Event [Disabled] Allows you to enable or disable logging of System boot event. Configuration options: [Enabled] [Disabled] MECI [1] Also known as Multiple Event Count Increment, and allows you to set the value for the...

  • Page 105: Chapter 5: Raid Configuration

    Chapter 5: RAID Configuration...

  • Page 106: Chapter Summary

    Chapter summary This chapter provides instructions for setting up, creating, and configuring RAID sets using the available utilities. This chapter contains the following sections: Setting up RAID ..................5-3 Intel Rapid Storage Technology enterprise ® SATA Option ROM Utility................5-5 Intel Rapid Storage Technology enterprise (Windows) ......

  • Page 107: Setting Up Raid

    If you want to boot the system from a hard disk drive included in a created RAID set, copy first the RAID driver from the support DVD to a floppy disk before you install an operating system to the selected hard disk drive. ASUS P10S-V/4L...

  • Page 108: Installing Hard Disk Drives

    5.1.2 Installing hard disk drives The motherboard supports Serial ATA for RAID set configuration. For optimal performance, install identical drives of the same model and capacity when creating a disk array. To install the SATA hard disks for RAID configuration: Install the SATA hard disks into the drive bays following the instructions in the system user guide.

  • Page 109: Intel

    The navigation keys at the bottom of the screen allow you to move through the menus and select the menu options. The RAID BIOS setup screens shown in this section are for reference only and may not exactly match the items on your screen. ASUS P10S-V/4L...

  • Page 110: Creating A Raid Set

    5.2.1 Creating a RAID set To create a RAID set: From the utility main menu, select 1. Create RAID Volume and press <Enter>. Key in a name for the RAID set and press <Enter>. Intel(R) Rapid Storage Technology enterprise - SATA Option ROM - 3.6.0.1023 Copyright(C) 2003-12 Intel Corporation.
  • Page 111 From the following warning message, press <Y> to create the RAID volume and return to the main menu, or press <N> to go back to the CREATE VOLUME menu. WARNING: ALL DATA ON SELECTED DISKS WILL BE LOST. Are you sure you want to create this volume? (Y/N): ASUS P10S-V/4L...

  • Page 112: Deleting A Raid Set

    5.2.2 Deleting a RAID set Take caution when deleting a RAID set. You will lose all data on the hard disk drives when you delete a RAID set. To delete a RAID set: From the utility main menu, select 2. Delete RAID Volume and press <Enter>. From the Delete Volume Menu, press the up/down arrow keys to select the RAID set you want to delete then press <Del>.

  • Page 113: Resetting Disks To Non-Raid

    Member Disk ST3300656SS 37VN00009846RAJ1 279.3GB Member Disk Select the disks that should be reset. ]-Previous/Next [SPACE]-Selects [ENTER]-Selection Complete Press <Y> in the confirmation window to reset the drive(s) or press <N> to return to the utility main menu. ASUS P10S-V/4L...

  • Page 114: Exiting The Intel ® Rapid Storage Technology Enterprise Sata Option Rom Utility

    5.2.4 Exiting the Intel Rapid Storage Technology ® enterprise SATA Option ROM utility To exit the utility: From the utility main menu, select 4. Exit then press <Enter>. Press <Y> to exit or press <N> to return to the utility main menu. CONFIRM EXIT Are you sure you want to exit? (Y/N): 5.2.5...
  • Page 115 Remove the failed SATA hard disk and install a new SATA hard disk of the same specification into the same SATA Port. Select a destination disk with the same size as the original hard disk. Reboot the system then follow the steps in section Rebuilding the RAID with other non-RAID disk. ASUS P10S-V/4L 5-11...

  • Page 116: Setting The Boot Array In The Bios Setup Utility

    5.2.6 Setting the Boot array in the BIOS Setup Utility You can set the boot priority sequence in the BIOS for your RAID arrays when creating multi- RAID using the Intel Rapid Storage Technology enterprise SATA Option ROM utility. ® To set the boot array in the BIOS: Set at least one of the arrays bootable to boot from the hard disk.

  • Page 117: Intel ® Rapid Storage Technology Enterprise (Windows)

    ® Your storage system is configured for data protection, increased performance and optimal data storage capacity. You can create additional volumes to further optimize your storage system. You can click Rescan to re-scan any attached hard disks. ASUS P10S-V/4L 5-13...

  • Page 118: Creating A Raid Set

    5.3.1 Creating a RAID set To create a RAID set: From the utility main menu, select Create Volume then select volume type and click Next. Key in a name for the RAID set, then select the array disks. Select the Volume Size tab then drag the bar to set the volume size. Click Next.
  • Page 119 You still need to partition your new volume using Windows Disk Management before adding any data. The created RAID set is displayed in the Volumes list. If you wish to change the settings, go to Volume Properties. ASUS P10S-V/4L 5-15...

  • Page 120: Changing A Volume Type

    5.3.2 Changing a Volume Type To change the volume type in Volume Properties: Click the SATA array items you want to change in Volumes field. From the Volume Properties field, select Type: RAID 1 Change type. You can also change the Name, Select the new volume type, and Select additional disks to include in the new volume if needed.

  • Page 121: Deleting A Volume

    From the Volumes field in the utility main menu, select the volume that you want to delete. From the Volume Properties field, select Delete volume. Click Yes to delete the volume and return to the utility main menu, or click No to return to the main menu. ASUS P10S-V/4L 5-17...

  • Page 122: Preferences

    5.3.4 Preferences System Preferences Allow you to set to show the notification area icon and show system information, warning, or errors here. E-Mail Preferences Allow you to set to sent e-mail of the following events: • Storage system information • Storage system warnings •...

  • Page 123: Chapter 6: Driver Installation

    Chapter 6: Driver Installation...
  • Page 124 Chapter summary This chapter provides the instructions for installing the necessary drivers for different system components in both Linux and Windows Operating Systems. ® ® This chapter contains the following sections: RAID driver installation ................6-3 Management applications and utilities installation ........ 6-6 Running the Support DVD ................

  • Page 125: Raid Driver Installation

    To install the RAID controller driver when installing Windows Server 2008 OS ® ® Boot the computer using the Windows Server 2008 OS installation disc. Follow the screen instructions to start installing Windows Server 2008. When prompted to choose a type of installation, click Custom (advanced). ASUS P10S-V/4L...
  • Page 126 Click Load Driver. A message appears reminding you to insert the installation media containing the driver of the RAID controller driver (the installation media can be a CD, DVD, or USB flash drive). If you have only one optical drive installed in your system, eject the Windows OS •...
  • Page 127 When the system finishes loading the RAID driver, Replace the motherboard Support DVD with the Windows Server installation disc. • Remove the USB flash drive. • Select the drive to install Windows and click Next. Follow succeeding screen instructions to continue. ASUS P10S-V/4L...

  • Page 128: Management Applications And Utilities Installation

    • The contents of the support DVD are subject to change at any time without notice. Visit the ASUS website (www.asus.com) for the latest updates on software and utilities. • The support DVD is supported on Windows Server 2008 R2 and Windows Server 2012.

  • Page 129: Drivers Menu Tab

    The Drivers Menu shows the available device drivers if the system detects installed devices. Install the necessary drivers to activate the devices. 6.3.2 Utilities menu tab The Utilities menu displays the software applications and utilities that the motherboard supports. ASUS P10S-V/4L...

  • Page 130: Manual Menu

    You need an internet browser installed in your OS to view the User Guide. 6.3.4 Contact information menu The Contact menu displays the ASUS contact information, e-mail addresses, and useful links if you need more information or technical support for your motherboard. Chapter 6: Driver Installation...

  • Page 131: Installing The Intel ® Chipset Device Software Driver

    ASSETUP.EXE from the BIN folder. Double-click the ASSETUP.EXE to run the support DVD. Click Intel Chipset Device Software from the Drivers menu to start the installation. ® The Intel(R) Chipset Device Software window appears. Click Next to start installation. ASUS P10S-V/4L...
  • Page 132 Select Yes to accept the terms of the License Agreement and continue the process. Read the Readme File Information and press Next to continue the installation. Toggle Yes, I want to restart the computer now and click Finish to complete the setup process.

  • Page 133: Installing The Intel ® I210 Gigabit Adapters Driver

    ASSETUP.EXE from the BIN folder. Double-click the ASSETUP.EXE to run the support DVD. Click Intel I210 Gigabit Adapters Drivers in the Drivers menu of the main screen to ® start the installation. Click Install Drivers and Software option to begin installation. ASUS P10S-V/4L 6-11...
  • Page 134 Click Next when the Intel(R) Network Connections–InstallShield Wizard window appears. Tick I accept the terms in the license agreement and click Next to continue. From the Setup Options window, click Next to start the installation. By default, Intel(R) PROSet for Windows Device Manager and Windows PowerShell Module are ticked.
  • Page 135 Click Install to start the installation. When the installation is done, press Finish to complete the installation. ASUS P10S-V/4L 6-13...

  • Page 136: Installing The Vga Driver

    Installing the VGA driver This section provides the instructions on how to install the ASPEED Video Graphics Adapter (VGA) driver. To install the ASPEED VGA driver: Restart the computer. Log in with Administrator privileges. Insert the Motherboard Support DVD to the optical drive. The support DVD automatically displays the Drivers menu if Autorun is enabled in your computer.
  • Page 137 Click Install to proceed with the installation. Click Finish to complete the installation. ASUS P10S-V/4L 6-15...
  • Page 138 6-16 Chapter 6: Driver Installation...

  • Page 139: Appendix

    Appendix...

  • Page 140: P10S-V/4L Block Diagram

    P10S-V/4L block diagram Appendix...

  • Page 141: Asus Contact Information

    ASUS contact information ASUSTeK COMPUTER INC. Address 15 Li-Te Road, Peitou, Taipei, Taiwan 11259 Telephone +886-2-2894-3447 +886-2-2890-7798 E-mail info@asus.com.tw Web site http://www.asus.com Technical Support Telephone +86-21-38429911 +86-21-58668722 ext: 9101 Online Support http://support.asus.com/techserv/techserv.aspx ASUSTeK COMPUTER INC. (Taiwan) Address 15 Li-Te Road, Peitou, Taipei, Taiwan 11259...
  • Page 142 800 Corporate Way, Fremont, CA 94539, USA +1-510-608-4555 Web site http://usa.asus.com Technical Support Support fax +1-812-284-0883 General support +1-812-282-2787 Online support http://support.asus.com/techserv/techserv.aspx ASUS COMPUTER GmbH (Germany and Austria) Address Harkort Str. 21-23, D-40880 Ratingen, Germany +49-2102-959911 Web site http://www.asus.de Online contact http://www.asus.de/sales Technical Support Telephone +49-1805-010923...
  • Page 143 Web site http://www.asus.com Technical Support Telephone +31-(0)591-5-70292 +31-(0)591-666853 E-mail advance.rma.eu@asus.com Online Support http://support.asus.com/techserv/techserv.aspx ASUS Polska Sp. z o.o. (Poland) Ul. Postępu 6, 02-676 Warszawa, Poland Address Web site http://pl.asus.com Technical Support Telephone +48-225718033 Online Support http://support.asus.com/techserv/techserv.aspx ASK-Service (Russia and CIS) Address г.Москва, ул.
  • Page 144 Appendix...

Table of Contents
