Adey MagnaClean Professional3 Sense Installation And Servicing page 11

4 10
1
4 13
1
4 16
Tighten by a ¼ turn.
Important - Do NOT
overtighten.
1
4 11
1
4 14
1
4 17
1 - Turn valves on.
2 - Vent.
3 - Wipe filter dry.
2
4 12
Lock red wheel
against canister.
4 15
Hand tighten.
1
1 2 3
4 18
A
Press
and hold
B
button for
6 seconds
using the
C
reset tool
provided.
D
1
E
1
F
