- Page 1 Edition TS 05.5.E TS Series Model TS1 Instruction Manual Valid as of: 01.01.2013 • Please keep the manual for future reference! TSF1...
-
Page 2: Table Of Contents
2.1.7 Available TSF models..................9 2.1.8 Available TSB1 models ..................9 2.1.9 Available TSB2 models .................. 10 2.2 Specifications of the TS series ................10 2.3 Assignment of the connector ................11 2.3.1 Connecting the tension meter................. 11 2.4 Optional accessories .................... 12 2.5 Delivery includes .................... -
Page 3: Warranty And Liability
Warranty: - SCHMIDT tension meters are warranted for 12 months. Parts subject to wear, electronic components and measuring springs are not covered by the warranty. No warranty or liability will be accepted for bodily injury or property damage resulting from one or several of the following causes: - Misuse or abuse of the device. -
Page 4: Informal Safety Measures
The device is intended exclusively to be used as a tension meter. Any other use or any use exceeding this intention will be regarded as misuse. Under no circumstances shall Hans Schmidt & Co GmbH be held liable for damage resulting from misuse. -
Page 5: Available Models
Available models General information These instruction manual refer to the TS1 model of the TS series; they are also appli- cable to the following models: TSP, TSH, TSW, TSL,TSF, TSF1, TSW, TSB1, TSB2 The individual models of the TS series are also available with the following modifications... -
Page 6: Available Tsp Models
* Outside dimensions of front plate. ** Suitable for 95% of applications. PA = Polyamide Monofilament Should the process material differ significant from the SCHMIDT calibration material in size, rigidity or shape, we recommend special calibration using customer supplied material. -
Page 7: Available Tsh Models
* Outside dimensions of front plate. ** Suitable for 95% of applications. PA = Polyamide Monofilament Should the process material differ significant from the SCHMIDT calibration material in size, rigidity or shape, we recommend special calibration using customer supplied material. -
Page 8: Available Tsl Models
* Outside dimensions of front plate. ** Suitable for 95% of applications. PA = Polyamide Monofilament Should the process material differ significant from the SCHMIDT calibration material in size, rigidity or shape, we recommend special calibration using customer supplied material. -
Page 9: Available Tsf Models
* Depending on model, either outside dimension of front plate or outer distance between outside guide rollers. ** Suitable for 95% of applications. PA = Polyamide Monofilament Should the process material differ significant from the SCHMIDT calibration material in size, rigidity or shape, we recommend special calibration using customer supplied material. -
Page 10: Available Tsb2 Models
Roller Material [m/min ... max.] Standard 1000 Hard-coated aluminium 13 mm Ø Specifications of the TS series Calibration: According to SCHMIDT factory procedure Accuracy: For 10 % to 100 % of range: ± 1 % full scale Other calibration material: ± 3 % full scale or better... -
Page 11: Assignment Of The Connector
Hans Schmidt & Co GmbH. Certification to the CE specification does not extend to, and shall be invalid for any other combina- tion. Under no circumstances shall Hans Schmidt & Co GmbH be held liable for any damage resulting from the use of non-SCHMIDT sensors or cables. -
Page 12: Optional Accessories
TS sensor, SCD-1 display unit and an 5 m long connecting cable (special cable). In no event shall Hans Schmidt & Co GmbH take over any warranty coverage for, or shall be held liable for, any damage resulting from self-made cables. -
Page 13: Initial Setup
If the material path is other than vertical or if the process material deviates signifi- cantly from the SCHMIDT calibration material, you need to carry out static zero and gain adjustment as described in chapters 3.2.1 and 3.2.2. -
Page 14: Gain Adjustment
3.2.1 Zero adjustment (cont.) - Screw the countersunk bolts (M2.5) labeled zero and gain all the way out on the rear side of the sensor. - Allow approx. 10 minutes for thermal stabilization of the sensor. - Thread the process material through the measuring and guide rollers, following the material path symbol on the front of the sensor. -
Page 15: Service And Maintenance
The question of finding the right frequency of calibration accuracy verification depends on several different factors: Operating time and load of the SCHMIDT tension meter Tolerance band defined by the customer Changes to the tolerance band compared to previous calibrations Therefore, the interval between verifications of calibration must be determined by the user‘s Quality Assurance Department, based on the user‘s experience. -
Page 16: Correspondence
Please indicate in your order whether you require an Inspection Certificate 3.1 according to DIN EN 10204. Service address: Hans Schmidt & Co GmbH Schichtstr. 16 84478 Waldkraiburg Germany...
