- Page 1 S C H M I D T c o n t r o l i n s t r u m e n t s Edition FGP 01.E FG Series Model FGP Operating Instructions Valid as of: 01.10.2015 • Please keep the manual for future reference!
- Page 2 Safety Precaution *Please keep this instruction manual at your side after you read. Observe all warnings and cautions; it is extremely important and any safety serious contents are described. Expression and meaning are as follows. Warning When you use FGP wrongly, it may cause serious problem, such as death or severe injury. Caution When you use FGP wrongly, it might cause serious problem depend on the situation.
- Page 3 Safety precaution Caution Do not use and keep the FGP under Do not use AC plug covered with dust. the following circumstances. ・ Location which will be gotten water ・ Dusty, salinity and iron content environments It might the cause of the fire. ・...
-
Page 4: Table Of Contents
INDEX 1.Product features 5.6.Memory 2.Confirmation of standard accessories 5.6.1.Setting memory mode 3.Part names and functions 5.6.2.Storing data 3.1.Main unit 5.6.2.1.Store the data (Continuous memory mode) 3.2.Display 5.6.2.2.Store the data (Single memory mode) 3.2.1.Part names 5.6.2.3.Store the data (Standard memory mode) 3.2.2.Numeric display 5.7.Recalling memory data 3.2.3.Unit display... -
Page 5: Product Features
1.Product Features ● Nickel –hydrogen battery enable us to use long time → 4.1. Charge ● Data can be dawnloaded to PC with USB → 5.9. USB communication ● Memorize up to 1000 data → 5.6. Memory ● Comparator enable us decision to pass or fail. ( I/O output of the result) →... -
Page 6: Part Names And Functions
3． Part names and functions 3.1.Main Unit ① Sensor shaft ② Display ③ PEAK key ⑤ＺＥＲＯ key ④ＵＮＩＴ key PEAK ZERO ⑫ Threaded hole ⑦ＭＥＭ key UNIT ⑥ＰＯＷＥＲ key REVERSE Model number ⑧ AC adapter port ⑨ Data output port ⑪... -
Page 7: Display
3.2.Display 3.2.1.Part names Display of unit Display of comparator judgement Display of MAX/MIN Display of measuring value. Display of peak hold mode 3.2.2.Numeric Display Display the measuring value with sign and 4 digits numbers. Compression force: plus, Tension force: minus. (It's available to switch plus/minus with the setting of function (f01)). -
Page 8: Before Use
4.Before use 4.1.Charge Do not charge with non- Please use AC adapter which supplied with FGP. If you use non-attached AC adapter, electronic circuit might be broken and fire might happen. attached AC adapter. Before the FGP arrive at your hand, nickel hydride battery might discharge electricity. Please plug attached AC adapter and charge before you use. -
Page 9: Tracking
4.4.Tracking A load cell of strain gauge is used for FGP as a load sensing. By using this sensor, the measuring value is slightly changed due to temperature and so on, but tracking is able to cancel this slightly change by the software. When you measure very minute forces, measuring value error might happen due to the tracking. -
Page 10: Sign: F01
4.5.1.Sign: f01 It's available to set the sign (plus or minus) of measuring value for pushing the sensor shaft. Select the sign by use of UNIT key / Press the PEAK key to move ahead. Key operation Display Plus Minus ZERO PEAK UNIT... -
Page 11: Baud Rate Of Rs232C: F04
4.5.4.Baud rate of RS-232C ： f04 It's available to set the baud rate of RS-232C. Press the UNIT key to switch the Baud rate (2400、 4800、 9600、 19200(bps)） / Press PEAK key to move ahead. Key operation Display 9600 4800 2400 19200 ZERO... -
Page 12: Reverse The Display
4.6.Reverse the display In the case you attach FGP with a stand, display of the value and the units can be reversed in order to read the display easily. Turn POWER off. Press the UNIT key and hold, then press POWER key and release (release UNIT key after the value is appeared in the display more than 1 second). -
Page 13: Measuring Mode
5.2.Measuring Mode There are standard measuring mode and peak hold mode in the measuring mode. 5.2.1Standard measuring mode It's available to measure the compression and tension force. Measuring value is appeared at all times. １） Press POWER key and release ( Turn POWER on after release) ２）... -
Page 14: Comparator
5.5.Comparator 5.5.1.Compatrator Compare HI / LO limit which you entered to measuring value, then result is appeared in the display. In addition, output signal of the result is available with data output port. In order to active comparator function, you have to set “Hi-Lo” at “External output (f06)” at function setting. (When you set “ovEr” at the External output (f06), result does not appear and output signal is not performed.) 5.5.2.How to enter Comparator / Memory setting mode Turn POWER off, press PEAK key and hold, then press POWER key and release (release PEAK key after the value is displayed more than 1... -
Page 15: Setting Lo Limit
5.5.4.Setting LO limit （1） Press PEAK key during comparator HI limit setting, then move to LO limit setting. （2） Setting way is the same as the comparator HI limit setting. （3） Press MEM key, then setting value is registered, and move to standard measuring mode. （4）... - Page 16 ［Definisions of the terms］ Measuring value: Displayed value which is per display update time at standard measuring mode. Plus maximum value (+MAX): Maximum value at plus side which is measured within memory measuring interval. Minus maximum value (-MAX): Maximum value at minus side which is measured within memory measuring interval. Plus minimum value (+MIN): Minimum value at plus side which is measured within memory measuring interval.
-
Page 17: Setting Memory Mode
5.6.1.Setting memory mode Turn the POWER off. Press PEAK key and hold, then press POWER key. Comparator HI limit setting turns on, then press PEAK key twice. Memory setting mode turns on. There are following setting items for comparator ・ memory setting mode. Item Display Content... -
Page 18: Storing Data
5.6.2.Storing data Store the data at setting memory mode (single memory, continuous memory, standard memory). 5.6.2.1.Store the data (Continuous memory mode) （1） During the standard measuring mode, please press MEM key. Then “M” blink, start the record. Press MEM key, measurement is finished, and then display of the unit is changed from M into the unit. -
Page 19: Recalling Memory Data
5.7.Recalling memory data 5.7.1.Continuous memory mode 5.7.1.1.Measuring memory data （1） Turn the POWER off. Press MEM key and hold, then press and release POWER key (release MEM key after the value appear in the display more than 1 second), then move to display measuring memory data. （2）... -
Page 20: 2.Statistics Memory Data
5.7.1.2.Statistics memory data （1） Press UNIT key during the measuring memory data, statistical data appear. （2） Every time press UNIT key, switch the display item, plus maximum value → minus maximum valu → plus minimum value → minun minimum value → plus peak value → minus peak value → average value → standard deviation. （3）... -
Page 21: Single Memory Mode
5.7.2.Single memory mode 5.7.2.1.Measuring memory data （1） Turn POWER off. Press MEM key and hold, then press and release POWER key (release MEM key after the value appear in the display more than 1 second), then measuring memory data is dislayed. （2）... -
Page 22: 2.Statistics Memory Data
5.7.2.2.Statistics memory data （1） When measuring memory data is displayed、 the display shifts to statistical memory data by pressing UNIT key. （2） Each time you press UNIT key, the display switches in order of plus maximum value → minus maximum value →... -
Page 23: Standard Memory Mode
5.7.3.Standard memory mode 5.7.3.1.Measuring memory data （1） Turn POWER off. Press MEM key and hold, then press and release POWER key (release MEM key after the value appear in the display more than 1 second), then measuring memory data is dislayed. （2）... -
Page 24: 2.Statistics Memory Data
5.7.3.2.Statistics memory data （1） When measuring memory data is displayed, display shifts to stastistics memory data by pressing UNIT key. （2） Each time you press UNIT key, display switches in order of plus maximum value → minus maximum value → plus minimum value → minus minimum value → plus peak value → minus peak value. （3）... -
Page 25: Erasing All Memory Data
5.8.2.Erasing all memory data (1)When last memory data is displayed, all data will be erased if you press ZERO key for a long time. (2)Display switches to standard measuring mode after showing “nonE” for one second at measuring display. (3)All memory data of current memory mode is erased. Key operation Display Memory number... -
Page 26: External Connection Connector
6.External Connection Connection 6.1.Pin assignment Pin Number Signal Name ＨＲ１２－１０ＲＣ－１０ＳＤＬ made in Hirose is ① Analog ＋ used for connector. We recommend you to use ＨＲ１２－１０Ｐ１０ＰＣＡＥ３００ （10 wires seald ② Analog ＧＮＤ cable） when making cable on your own. ＲｘＤ （ＲＳ－２３２Ｃ Received data） ③... -
Page 27: Rs232C Communication Command
6.2.2.RS232C communication command ■ Typical communication command "cr"means carriage return. Transmitting command from Returning command from Content Explanation host computer to FGP ＡＡｃｒ Tare ＡＡｃｒ ＡＢｃｒ Cancel of data transmission ＡＢｃｒ ＡＣｃｒ Switch to plus peak hold mode ＡＣｃｒ ＡＤｃｒ Switch to standard measuring mode ＡＤｃｒ... -
Page 28: Connection Between Fgp And Pc
6.2.3.Connection between FGP and PC Host computer （Connector for data output port） （Ｄ－ＳＵＢ ９ｐｉｎ） ＤＣＤ ＲｘＤ ＴｘＤ ＲｘＤ Please be sure to connect 5pin into 4 pin of digital GND when making ＤＴＲ Digital ＧＮＤ cable for RS-232C on your own. It cannot be transmitted without this D e t e c t i o n o f ＧＮＤ... -
Page 29: Frequently-Asked Questions
7.Frequently –asked questions 7.1.Questions for trouble Questions Cause Presumable reason Procedure When turning on power, “OVR” is There is possibility which Due to dropment or Please send it for repair. displayed even if not applying load internal loadsell is broken. overloading and cannot be cleared by pushing ZERO key. -
Page 30: Support
8.Support 8.1.Repair and Calibration We have calibration service for value. We recommend calibrating regularly for keeping up the accuracy of force gauge. Please ask our dealers for the price and lead time of the calibaration. 8.2.Warranty Nidec-Shimpo Corp. warrants, to the original purchaser of new products only, that this product shall be free from defects in workmanship and materials under normal use and proper maintenance for one year from the date of original purchase. -
Page 31: Dimensions
Dimensions Force measuring attachments (standard accessories) The following drawing is for the attachment of FGP-2 ～ 50 (M6). Please contact our dealers about the adapter for FGP-0.2, 0.5 (M4) and FGP-100 (M6). Flat head φ 12 Chisel ： 70° Cone head ： 70° (43) Extension rod Ｌ＝... - Page 32 Yarn Package Durometer and Shore Durometer Sample Cutter Balance Moisture Meter Leak Tester More than 75 years - Worldwide - Hans Schmidt & Co GmbH Mailing address: P. O. B. 11 54 Phone: e-mail: 84464 Waldkraiburg Germany int. + 49 / (0)8638 / 9410-0 info@hans-schmidt.com...
