VIDEO
STATUS
A Camera on
Power
B
NOTE: WITHOUT PROPER FIBER CONNECTION, LED's DO NOT INDICATE
CORRECT OPERATIONAL STATUS OF THE UNIT.
VT7800
CH 5 CH 6
CH 1 CH 2
CH 7 CH 8
CH 3 CH 4
POWER
Status indicating LEDs will
change from RED to
GREEN with these conditions.
A
B
