UTC Fire and Security interlogix VT7820 Installation & Operation Instructions page 3

VIDEO
STATUS
Camera on
A
Video Present
B
Optical carrier received
C
D Power
NOTE: WITHOUT PROPER FIBER CONNECTION, LED's DO NOT INDICATE
CORRECT OPERATIONAL STATUS OF THE UNIT.
VR7800
VT VR VT VR VT VR
CH 5 CH 6
VT VR VT VR VT VR
CH 1 CH 2
OPTICAL
CARRIER
VT VR
CH 7 CH 8
VT VR
CH 3 CH 4
POWER
Status indicating
LEDs will change
from RED to GREEN
with these conditions.
A
B
C
D
