Hans Grohe Allegro N 71844 1 Series Installation/User Instructions/Warranty
Hide thumbs
Also See for Allegro N 71844 1 Series:
- Installation/user instructions/warranty (24 pages) ,
- Installation/user instructions/warranty (24 pages)
Subscribe to Our Youtube Channel
Related Manuals for Hans Grohe Allegro N 71844 1 Series
Summary of Contents for Hans Grohe Allegro N 71844 1 Series
- Page 1 EN Installation / User Instructions / Warranty FR Instructions de montage / Mode d'emploi / Garantie ES Instrucciones de montaje / Manejo / Garantía Allegro N 71843xx1 71844xx1 Focus N 71800xx1 71801xx1...
-
Page 2: Installation Considerations
English Français Technical Information Données techniques Water pressure Pression d’eau Recommended 15 - 75 PSI (0.1 - 0.5 MPa) recommandée 15 - 75 PSI (0.1 - 0.5 MPa) Maximum 145 PSI (1 MPa) maximum 145 PSI (1 MPa) Hot water temp. Température d'eau chaude Recommended 120°-140°... - Page 3 Español Datos tecnicos Tools Required / Outiles Utiles / Herramientas Útiles Presión en servicio recomendada 15 - 75 PSI (0.1 - 0.5 MPa) max. 145 PSI (1 MPa) Temperatura del agua caliente recomendada 120°-140° F (48° - 60° C)* 9 mm max.
- Page 4 Focus N Focus N 71800xx1 71801xx1 8⅞" (224 mm) 8¹⁄₁₆" (204 mm) Ø1⅛" 3⅞" (97 mm) (28 mm) Ø1⅛" 2⅝" (28 mm) (68 mm) 4⅞" (125 mm) 8⅛" (207 mm) 7½" (192 mm) 3⅜" (85 mm) 3⅞" (97 mm) 2⅝" 4⅞"...
- Page 5 Allegro N Allegro N 71843xx1 71844xx1 8¹⁄₁₆" (204 mm) 8⅞" (224 mm) Ø1⅛" (28 mm) 4" (101 mm) Ø1⅛" (28 mm) 2¾" (69 mm) 8⅛" (207 mm) 5⅛" (131 mm) 8⅛" (207 mm) 3½" 4" (101 mm) (89 mm) 5⅛" (131 mm) 2¾"...
-
Page 6: Installation / Installation / Instalación
Installation / Installation / Instalación English Français Español Remove the protective cover Retirez le capuchon de Retire la tapa protectora. from the faucet body. protection. Alinee el orificio en la parte tra- Align the hole in the rear of the Alignez le trou à... - Page 7 2.2 ft-lb 3 Nm English Français Español Place the faucet and sealing ring Placez l'anneau d'étanchéite Coloque el oro de sellado y on the mounting surface. et le robinet sur la surface de el grifo sobre la superficie de montage. montaje.
- Page 8 CLICK English Français Español Connect the hot and cold supply Connectez les tuyaux d'arrivée Conecte las mangueras de sum- hoses to the stops. d'eau chaude et d'eau froide inistro de agua caliente y fría a aux tuyau d'alimentation. las alimentaciones de la red. Use two wrenches.
- Page 9 English Français Español Install the hose weight. Installez le contrepoids sur le Instale el contrapeso. tuyau. Test the handspray hose. If it Tire del rociador de mano. Debe does not retract smoothly, reposi- Tirez sur la douchette. Elle devrait moverse con facilidad y retraerse tion the weight.
- Page 10 1 Nm English Français Español Flush the faucet for at least two Rincez le robinet pour un mini- Enjuague el grifo durante un minutes. mum de deux minutes. mínimo de dos minutos. Reinstall the hose filter. Installez le filtre. Instale el filtro. Lightly lubricate the hose o-ring.
- Page 11 Set the high temperature limit stop / Réglage de la butée limite d’eau chaude / Ajuste el tope de límite de alta temperatura 140°F 50°F 44 PSI 60° C 10°C 0.3 MPa 97°F (36°C) 100°F (38°C) 109°F (43°C) 122°F (50°C) 140°F (60°C) 131°F (55°C)
- Page 12 Replacement Parts / Pièces détachées / Repuestos Focus N 71800xx1 71801xx1 98127000 (11x2) 98193000 (32x2) 97735000 93344xx0 98211000 (21x2.5) 98156000 96338000 (36x2) 98365000 97406xx0 92730000 93346000 (M40x1.5) SW 30 mm 93218000 95140000 (M4x20) 93343XX1 SW 4 mm 95008000 93342XX0 98433000 (30x1.5) 98396000 (38x2)
- Page 13 Allegro N 71843xx1 71844xx1 98127000 (11x2) 98193000 (32x2) 97735000 93496XX0 98156000 (36x2) 96338000 98365000 97406xx0 92730000 93346000 (M40x1.5) SW 30 mm 93218000 95140000 (M4x20) 93343XX1 SW 4 mm 95008000 93342XX0 98433000 (30x1.5) 98396000 (38x2) 95910000 98162000 (44x2.5) (46x2) 97523000 96316001 95561000 97548000 (600 mm)
- Page 14 User Instructions / Instructions de service / Manejo ouvert fermé abierto cerrar cold froid chaud caliente frío ouvert abierto...
-
Page 15: Maintenance / Entretien / Mantenimiento
Maintenance / Entretien / Mantenimiento... - Page 16 Cleaning Recommendation for Hansgrohe Products Modern bathroom faucets, kitchen faucets and shower products are made from different materials to comply with the needs of the market with regard to design and functionality. To avoid damage to the product, it is necessary to take proper care of it.
- Page 17 Important • Les residus de produits pour le corps comme les savons liquides, shampooings, gels de douche, teintures pour cheveux, parfums, apres-rasage et vernis a ongles peuvent causer des deteriorations. Rincez le produit avec de l’eau propre après chaque utilisation. •...
-
Page 20: Limited Consumer Warranty
Limited Consumer Warranty This warranty is limited to products manufactured by Hansgrohe, conditions in the home such as excessive water pressure Inc. (“Hansgrohe”) that are purchased by a consumer in the United or corrosion. States or Canada after March 1, 1996, and installed in either the Labor and other expenses for disconnection, deinstallation, United States or in Canada.
