Summary of Contents for Hans Grohe Allegro N 71843 1 Series
- Page 1 EN Installation / User Instructions / Warranty FR Instructions de montage / Mode d'emploi / Garantie ES Instrucciones de montaje / Manejo / Garantía Allegro N 71843xx1 71844xx1 Focus N 71800xx1 71801xx1...
-
Page 2: Installation Considerations
English Français Technical Information Données techniques Water pressure Pression d’eau Recommended 15 - 75 PSI (0.1 - 0.5 MPa) recommandée 15 - 75 PSI (0.1 - 0.5 MPa) Maximum 145 PSI (1 MPa) maximum 145 PSI (1 MPa) Hot water temp. Température d'eau chaude Recommended 120°-140°... -
Page 3: Consideraciones Para La Instalación
Español Datos tecnicos Tools Required / Outiles Utiles / Herramientas Útiles Presión en servicio recomendada 15 - 75 PSI (0.1 - 0.5 MPa) max. 145 PSI (1 MPa) Temperatura del agua caliente recomendada 120°-140° F (48° - 60° C)* 9 mm max. - Page 4 Focus N Focus N 71800xx1 71801xx1 8⅞" (224 mm) 8⅞" (224 mm) Ø1⅛" (28 mm) Ø1⅛" 8⅛" (207 mm) 3⅞" (97 mm) (28 mm) 2⅝" 3⅞" (97 mm) (68 mm) 4⅞" (125 mm) 2⅝" 4⅞" (125 mm) 8⅛" (207 mm) 3⅜"...
- Page 5 Allegro N Allegro N 71843xx1 71844xx1 8⅞" (224 mm) 8⅞" (224 mm) Ø1⅛" (28 mm) Ø1⅛" (28 mm) 8⅛" (207 mm) 4" (101 mm) 2¾" 4" (101 mm) (69 mm) 5⅛" (131 mm) 8⅛" (207 mm) 5⅛" (131 mm) 2¾" (69 mm) 3½"...
-
Page 6: Installation / Installation / Instalación
Installation / Installation / Instalación English Français Español Remove the protective cover Retirez le capuchon de Retire la tapa protectora. from the faucet body. protection. Alinee el orificio en la parte tra- Align the hole in the rear of the Alignez le trou à... - Page 7 2.2 ft-lb 3 Nm English Français Español Place the faucet and sealing ring Placez l'anneau d'étanchéite Coloque el oro de sellado y on the mounting surface. et le robinet sur la surface de el grifo sobre la superficie de montage. montaje.
- Page 8 English Français Español Connect the hot and cold supply Connectez les tuyaux d'arrivée Conecte las mangueras de sum- hoses to the stops. d'eau chaude et d'eau froide inistro de agua caliente y fría a aux tuyau d'alimentation. las alimentaciones de la red. Use two wrenches.
- Page 9 CLICK English Français Español Connect the handspray hose to Raccordez le tuyau de la dou- Conecte la manguera de roci- the connection hose: chette au tuyau d'arrivée de la ador de mano a la manguera douchette: de suministro: • Open the quick connect by pushing it upwards.
- Page 10 English Français Español Test the handspray hose. If it Tirez sur la douchette. Elle devrait Tire del rociador de mano. Debe does not retract smoothly, reposi- coulisser facilement et se rétract- moverse con facilidad y retraerse tion the weight. er sans à-coups. Modifiez la po- suavemente.
- Page 11 English Français Español Flush the faucet for at least two Rincez le robinet pour un mini- Enjuague el grifo durante un minutes. mum de deux minutes. mínimo de dos minutos. Reinstall the hose filter. Installez le filtre. Instale el filtro.
- Page 12 0.74 ft-lb 1 Nm English Français Español Lightly lubricate the hose o-ring. Lubrifiez le joint torique du Lubrique ligeramente la junta tuyau. tórica de la manguera. Install the handspray. Installez le douchette. Instale la ducha. Tighten the hose nut. Serrez l’écrou. Apriete la tuerca de la manguera.
- Page 13 Set hot water limiter / Positionner le limiteur de température / Ajustar tope 140°F 50°F 44 PSI 60° C 10°C 0.3 MPa 4 mm 97°F (36°C) 100°F (38°C) 109°F (43°C) 122°F (50°C) 140°F (60°C) 131°F (55°C) 17 x 4 mm 3.7 ft-lb 5 Nm 4 mm...
- Page 14 Replacement Parts / Pièces détachées / Repuestos Focus N 71800xx1 71801xx1 98127000 (11x2) 98193000 (32x2) 97735000 93344xx0 98211000 (21x2.5) 98156000 96338000 (36x2) 98365000 97406xx0 92730000 93346000 (M40x1.5) SW 30 mm 93218000 95140000 (M4x20) 93343XX1 SW 4 mm 95008000 93342XX0 98433000 (30x1.5) 98396000 (38x2)
- Page 15 Allegro N 71843xx1 71844xx1 98127000 (11x2) 98193000 (32x2) 97735000 93496XX0 98156000 (36x2) 96338000 98365000 97406xx0 92730000 93346000 (M40x1.5) SW 30 mm 93218000 95140000 (M4x20) 93343XX1 SW 4 mm 95008000 93342XX0 98433000 (30x1.5) 98396000 (38x2) 95910000 98162000 (44x2.5) (46x2) 97523000 96316001 97548000 93253000 95507000...
- Page 16 User Instructions / Instructions de service / Manejo ouvert fermé abierto cerrar cold froid chaud caliente frío ouvert abierto...
- Page 17 Cleaning / Nettoyage / Limpieza Check valve maintenance / Entretien de les clapets anti-retour/ Mantenimiento de las válvulas antirretornos...
- Page 18 Cleaning Recommendation for Hansgrohe Products Modern bathroom faucets, kitchen faucets and shower products are made from different materials to comply with the needs of the market with regard to design and functionality. To avoid damage to the product, it is necessary to take proper care of it.
- Page 19 Important • Les residus de produits pour le corps comme les savons liquides, shampooings, gels de douche, teintures pour cheveux, parfums, apres-rasage et vernis a ongles peuvent causer des deteriorations. Rincez le produit avec de l’eau propre après chaque utilisation. •...
- Page 23 Hansgrohe, Inc. Limited Warranty Offering our customers the highest quality at all times is a funda- • abuse, neglect or improper or incorrectly performed mental part of the Hansgrohe, Inc. company philosophy. We offer installation, maintenance or repair, including the use consumers a limited warranty on our hansgrohe and AXOR of abrasive or caustic cleaning agents or “no-rinse”...
- Page 24 TEAR, OUTDOOR USE, MISUSE (INCLUDING USE OF THE This warranty gives you specific legal rights, and you may also PRODUCT FOR AN UNINTENDED APPLICATION), FREEZING have other rights which vary from state to state. WATER, EXCESSIVE WATER PRESSURE, PIPE CORROSION IN PRODUCT I NSTRUC TIONS A ND QUE STIONS THE HOME IN WHICH THE PRODUCT IS INSTALLED, ABUSE, NEGLECT OR IMPROPER OR INCORRECTLY PERFORMED...
