Reolink TrackMix LTE Plus Quick Start Manual page 10

5
5
4
5. Loosen the four screws on two sides of the solar panel's bracket to rotate the
panel for maximum sunlight exposure. Then fasten the screws tightly.
6. Connect the cable from the panel to the shorter cable on the bracket. Ensure that
the arrows on the two cables are aligned.
Important notice:
• Make sure the solar panel is not blocked. The energy harvesting efficiency drops
drastically even when a small portion of the solar panel is blocked.
• Please don't install the solar panel completely horizontally. Otherwise your solar
panel might accumulate dust and other debris easily. It's advised to install the solar
panel angularly to receive the most direct sunlight.
• Wipe the solar panel regularly to remove dust or debris.
17 English
6
6
Install the Camera
1. It is recommended to attach the camera to the mounting bracket for better
waterproof performance.
(1) Use a screwdriver and two screws to secure the lower part of the camera bracket.
(2) Fix the upper part with the screwdriver and two screws.
(3) Connect the camera's charging cable to the longer cable on the bracket.
2
1
2
2
English 18
