- Page 1 Installation, use and maintenance instructions Forced draught gas burners Progressive two-stage or modulating operation CODE MODEL TYPE 3897330 - 3897332 RS 45/E BLU 827 T3 3897331 - 3897333 RS 45/E BLU 827 T3 2916377 (5) - 02/2012...
- Page 2 Controlling organisation: TÜV Industrie Service GmbH TÜV SÜD Gruppe Ridlerstrase, 65 80339 München DEUTSCHLAND Manufacturer's Declaration RIELLO S.p.A. declares that the following products comply with the NOx emission limits specified by German standard “1. BImSchV reliese 26.01.2010”. Product Type Model Power...
-
Page 3: Table Of Contents
Contents Section Page Information and general instructions Information about the instruction manual Guarantee and responsibility Safety and prevention Introduction Personnel training Technical description of the burner Burner designation Models available Burner categories - Countries of destination Technical data Packaging Overall dimensions Firing rates Burner components Burner equipment... -
Page 4: Information And General Instructions
Information and general instructions Information about the instruction manual Introduction DANGER: LIVE COMPONENTS The instruction manual supplied with the burner: This symbol indicates operations which, if not is an integral and essential part of the product and must not carried out correctly, lead to electric shocks be separated from it;... -
Page 5: Safety And Prevention
Safety and prevention Introduction burners have been designed and built in compliance In particular: with current regulations and directives, applying the known tech- it can be applied to boilers operating with water, steam, dia- nical rules of safety and envisaging all the potential danger situ- thermic oil, and to other users expressly named by the man- ations. -
Page 6: Technical Description Of The Burner
3/400/50 230/50/60 BASIC DESIGNATION EXTENDED DESIGNATION Models available Designation Voltage Code RS 45/E BLU 230V - 50Hz 3897330 - 3897332 RS 45/E BLU 230V - 50Hz 3897331 - 3897333 Burner categories - Countries of destination Country of destination Gas category... -
Page 7: Technical Data
Technical description of the burner Technical data Model RS 45/E BLU Type 827 T3 Output maximum 190 - 550 Mcal/h 164 - 474 minimum Mcal/h Fuel Natural gas: G20 (methane gas) - G21 - G22 - G23 - G25 Gas pressure at max. output... -
Page 8: Firing Rates
Technical description of the burner Firing rates RS 45/E BLU D2194 Fig. 3 The maximum output is chosen within area A. Warning The firing rate was obtained considering a room temperature of The minimum output must not be lower than the minimum limit 20°C and an atmospheric pressure of 1013 mbar (approx. -
Page 9: Burner Components
Technical description of the burner Burner components seen from A Fig. 5 D8043 1 Combustion head 10 Operator panel with LCD display 20 Gas pressure test point and head fix- 2 Ignition electrode 11 Control box for checking flame and air/ ing screw 3 Screw for combustion head adjustment fuel ratio... -
Page 10: Control Box For The Air/Fuel Ratio
Technical description of the burner 3.10 Control box for the air/fuel ratio D8266 Fig. 6 Introduction Technical data The control box for the air/fuel ratio (hereafter referred to simply Electrical supply AC 230V - 15% / as the control box), that equips the burners of the RS range, car- +10% ries out a series of integrated functions in order to optimise Frequency... -
Page 11: Servomotors
Technical description of the burner 3.11 Servomotors Introduction The servomotors that equip the burners of the RS range work directly on the air damper and the gas butterfly valve, without mechanical lever- ages but via the interposition of a coupling. They are commanded by the control box, which constantly checks their position by means of a return signal from the optic sensor inside the ser- vomotor. -
Page 12: Installation
the model (see A in Fig. 8) and type of burner (B); GAZ-AEPIO the year of manufacture, in cryptographic form (C); RIELLO S.p.A. the serial number (D); I-37045 Legnago (VR) the data for electrical supply and the protection level (E);... -
Page 13: Securing The Burner To The Boiler
Securing the burner to the boiler Introduction The RS 45/E BLU burner is suitable for working on both flame inversion boilers* (in this case the long head model is recom- mended) and boilers with a combustion chamber with bottom run- off (three flue gas circulations), from which the best results of low emissions are obtained. - Page 14 Installation Securing the burner to the boiler Before fixing the burner to the boiler, check from the opening of the blast tube that the probe and the electrode are correctly positioned, as in Fig. 13. If, in the previous check, the position of the probe or electrode was not correct, remove the screw 1)(Fig. 14), extract the inner part 2)(Fig.
-
Page 15: Combustion Head Adjustment
R1 = notch 5,3; central air: R1 = notch 2.7; gas: R3 = notch 0.7. Fig. 15 D8046 RS 45/E BLU Maximum burner output Fig. 16 D2209 Note The adjustments indicated can be modified during the initial start-up. - Page 16 Installation Once the combustion head adjustment is completed: When fitting the burner on the two guides, it is reassemble the burner on the guides 3) at about 100 mm advisable to gently draw out the high voltage from the pipe coupling 4) - burner in the position shown in cable and flame detection probe cable until they Fig.
-
Page 17: Assembly Of The Gas Train
Installation Assembly of the gas train The gas train is type-approved according to standard EN 676 and is sup- plied separately from the burner, with the code indicated in Appendix B. The gas train can enter the burner from the right or left side, depending on which is the most convenient, see Fig. -
Page 18: Electrical Wiring
The use of the cable grommets and the pre-blanked holes can be done in different manners; by way of example we indicate the fol- lowing mode: RS 45/E BLU 1 - Pg 11 Single phase power supply 2 - Pg 11... -
Page 19: Start-Up, Calibration And Operation Of The Burner
Start-up, calibration and operation of the burner Notes on safety for the first start-up The first start-up of the burner must be carried out Check the correct working of the adjustment, com- by qualified personnel, as indicated in this manual mand and safety devices. -
Page 20: Burner Start-Up
Start-up, calibration and operation of the burner Burner start-up Feed electricity to the burner via the disconnecting switch on the boiler panel. Close the thermostats/pressure switches and turn the switch of Fig. 25 to position “1”. Make sure that the lamps or testers connected to the solenoids, or indicator lights on the solenoids themselves, show that no voltage is present. - Page 21 Start-up, calibration and operation of the burner Minimum gas pressure switch Adjust the minimum gas pressure switch after having per- formed all other burner adjustments with the pressure switch set to the start of the scale (Fig. 27). With the burner operating at maximum output, increase adjust- ment pressure by slowly turning the relative knob clockwise until the burner locks out.
-
Page 22: Operator Panel With Lcd Display
Start-up, calibration and operation of the burner Operator panel with LCD display Description of the symbols Lock-out lamp Lockout Flame presence Valve powered Ignition transformer powered Fan motor powered Pre-heater active only for burners of fuel oil Fig. 29 Request for heat D8268 Parameters mode active Key to units of measurement... -
Page 23: Visualisation And Programming Modes
Start-up, calibration and operation of the burner Visualisation and programming modes The operator panel, and especially the display visualisation, has 4 working modes: Normal mode Info mode (InFo) Service mode (Ser) Parameters mode (PArA) The information for accessing and operating at the various levels is given below. Normal mode Visualises the operation conditions and allows you to modify the operation point of the burner manually. - Page 24 Start-up, calibration and operation of the burner m³ m³/h The display visualises alternately an error code and a diagnostic, which does not take the system into safety mode. m³ m³/h Reset procedure The burner is in lockout when the red indicator light on the operator panel is switched on m³...
- Page 25 Start-up, calibration and operation of the burner From Normal mode, using the keys of the operator panel, it is possible to activate one of the three visualisation/programming modes: Info mode (InFo) Visualisation modes Service mode (Ser) Service mode (Ser) Programming modes Info mode Service mode Visualises the general system information.
- Page 26 Start-up, calibration and operation of the burner Parameters mode Visualises and allows you to modify/program the complete list of To access this level, refer to “Access procedure with password”. parameters, see Cap. 5.18. Once the access procedure has been carried out, the display will The factory-set parameters are not visible.
- Page 27 Start-up, calibration and operation of the burner Parameter modification procedure Procedure for inserting and adjusting points on the modulation curve Nine adjustment/calibration points (P1 ÷ P9) can be inserted in After accessing the level the control box for each servomotor, varying their position by de- and group of parameters, grees and, consequently, the quantity of air and fuel introduced.
-
Page 28: Operation Sequence Of The Burner
Start-up, calibration and operation of the burner Operation sequence of the burner Signal ON Operation Signal OFF Start-up Switching off Checking of Any signal is allowed seal TSA1 Number of the phase Thermostat/pressure switch safety TS Thermostat/pressure switch indicator TL Ionisation probe ION Air pressure switch PA Minimum gas pressure switch... -
Page 29: Start-Up Procedure
Start-up, calibration and operation of the burner Start-up procedure Check that the display of the Operator Panel shows request for heat and “OFF Upr”: this means it is necessary to set the modulation curve of the burner. m³ m³/h Access the Parameters level referring to “Access procedure with password”. The display visualises the parameters group 400;... - Page 30 “546” and “545” according to “Parameter modification procedure”. Press simultaneously the keys “+” and “-” (esc) twice: the display will visualise the current load position. Factory settings Burner Point of the curve RS 45/E BLU 21° 30° 90° 90°...
-
Page 31: Calc Function
Start-up, calibration and operation of the burner CALC function D7908 D7909 original curve CALC+ CALC- Recalculation Point of the curve Fig. 31 Point of the curve Fig. 32 The diagram of Fig.31 shows how the fuel modulation curve is The diagram of Fig. 32 shows the fuel modulation curve modified if the values of point “P5”... -
Page 32: Steady State Operation
Start-up, calibration and operation of the burner 5.11 Steady state operation 5.15 Measuring the ionisation current The burner is fitted with an ionisation system to check that a Burner without modulating operation kit flame is present. Once the start-up cycle is completed, the servomotor command The minimum current for control box operation is 4 µA. -
Page 33: List Of Parameters
5.18 List of parameters Parameter Values interval Unit of Number of Degree of Predefined measure- Modification Access mode elements precision setting Description Min. Max. ment par. General parameters Control box identification date Reading only Info mode Control box identification number Reading only 65535 Info mode... - Page 34 Parameter Values interval Unit of Number of Modifica- Degree of pre- Predefined measure- Access mode elements tion cision setting Description Min. Max. ment par. Selection of the burner operation during the interruption of the switch-over with the system of remote management. 0 = burner switched off With modulating operation the settings of the values are the following: 0...19.9 = burner switched off...
- Page 35 Parameter Values interval Unit of Number of Modifica- Degree of pre- Predefined measure- Access mode Description Min. Max. elements tion cision setting ment par. Gas: selection of flame sensor 0 = QRB.../ QRC Modification Parameters mode 1 = ION / QRA Gas: Selection of the pre-purging function Modification Parameters mode...
- Page 36 Parameter Values interval Unit of Number of Modifica- Degree of pre- Predefined measure- Access mode Description Min. Max. elements tion cision setting ment par. Position of the air servomotor in absence of flame (°) Modification 0° 90° 0.1° 0°; 90°; 45° Parameters mode Index 0 = standby position Index 1 = pre-purging position...
-
Page 37: Faults - Possible Causes - Solutions
Faults - Possible causes - Solutions If faults arise in ignition or operations, the burner performs a "safety stop", which is signalled by the red burner lockout LED. The display visualises alternately the lockout code and the relative diagnostic. To reset the start-up conditions, refer to “Reset procedure”. When the burner starts up again, the red LED goes out. List of error codes Error Diagnostic... - Page 38 Faults - Possible causes - Solutions Error Diagnostic Meaning of the system REC27.100A2 Recommended measures code code Reference error of a servomotor The reference of the fuel servomotor was not successful. Bit 0 It was not possible to reach the reference point. Reference error of the fuel servomotor Valence 1 1.
- Page 39 Faults - Possible causes - Solutions Error Diagnostic Meaning of the system REC27.100A2 Recommended measures code code Relay supervision error 2 – Safety valve 3 Ignition transformer The relay does not start up Carry out a reset; if the error arises repeatedly, replace the unit 4 Fuel valve 1 5 Fuel valve 2 6 Fuel valve 3...
- Page 40 Faults - Possible causes - Solutions Error Diagnostic Meaning of the system REC27.100A2 Recommended measures code code Internal error – backup / restoration Restoration – OK, but backup < compared with set data of Restoration successful, but the backup data installed are fewer than those currently present in current system the system.
-
Page 41: Maintenance
Maintenance Notes on safety for the maintenance The periodic maintenance is essential for the good operation, Before carrying out any maintenance, cleaning or checking oper- safety, yield and duration of the burner. ations: It allows you to reduce consumption and polluting emissions and disconnect the electricity supply from the burner by to keep the product in a reliable state over time. -
Page 42: Opening The Burner
Maintenance Opening the burner Closing the burner Disconnect the electrical supply from the burner. Remove the split pin 9) and push the burner until it is approx. Loosen the screws 1) and remove the cover 2). 100 mm from the pipe coupling. ... -
Page 43: A Appendix - Electrical Panel Layout
Appendix - Electrical panel layout Index of layouts Indication of references Functional layout REC27... Functional layout REC27... Functional layout REC27... Electrical wiring that the installer is responsible for Electrical wiring Kit RWF40... external Indication of references /1.A1 Sheet no. Co-ordinates... - Page 44 Appendix - Electrical panel layout Wiring layout key - Control box for the air/fuel ratio - Air pressure switch - Operator panel - Burner earth - Filter to protect against radio disturbance - Maximum gas pressure switch - Burners components PGMin - Minimum gas pressure switch - Boiler components...
- Page 45 Appendix - Electrical panel layout...
- Page 46 Appendix - Electrical panel layout...
- Page 47 Appendix - Electrical panel layout...
- Page 48 Appendix - Electrical panel layout...
- Page 49 Appendix - Electrical panel layout...
-
Page 50: Appendix - Accessories (On Request)
Appendix - Accessories (on request) Output power regulator kit for modulating operation With the modulating operation, the burner continually adapts the power to the request for heat, ensuring great stability for the parameter controlled: temperature or pressure. Two components should be ordered: •... - Page 51 Long Head Kit Head length obtained Burner Kit Code Standard head length with the kit RS 45/E BLU 20006586 229 mm 354 mm Post-purging function Note A specific kit does not exist, because the post-purging function is obtained by modifying parameter 234 (see Chap. 5.18).
-
Page 52: C Appendix - Gas Supply Pressure
- read the corresponding output on the left. Fig. 36 Example - RS 45/E BLU: • Maximum output operation • Natural gas G 20 PCI 9.45 kWh/Sm • Ring nut 2)(Fig.15) adjusted as in the diagram of Fig. 16 •... -
Page 53: D Appendix - Firing Rate On Basis Of Air Density
Appendix - Firing rate on basis of air density The firing rate of the burner shown in the manual is valid for a 4 -Trace a vertical line from point A, Fig. 37, and find the maxi- room temperature of 20°C and an altitude of 0m above sea level mum pressure H2 of the firing rate. - Page 56 RIELLO S.p.A. I-37045 Legnago (VR) Tel.: +39.0442.630111 http:// www.riello.it http:// www.rielloburners.com Subject to modifications...
