RLY26
MANAGER'S CHAIR

Assembly Instructions - Important:

Carefully unpack and identify each component before attempting to assemble. Refer to parts list. Please take care when
assembling the unit and always set the parts on a clean, soft surface. If you require any assistance with assembly, parts or
information on other products, please visit our website: www.officestar.net or call or write us.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Caty RLY26 and is the answer not in the manual?

Questions and answers

Related Manuals for OSP Home Furnishings Caty RLY26

Summary of Contents for OSP Home Furnishings Caty RLY26

  • Page 1 January, 2023 RLY26 MANAGER’S CHAIR Assembly Instructions - Important: Carefully unpack and identify each component before attempting to assemble. Refer to parts list. Please take care when assembling the unit and always set the parts on a clean, soft surface. If you require any assistance with assembly, parts or information on other products, please visit our website: www.officestar.net or call or write us.
  • Page 2 1-800-950-7262, Monday through Friday 8:00 a.m. - 3:30 p.m. Pacific Time. To make a warranty claim, contact Parts Department. Provide model number, proof of purchase, description of the problem and obtain return authorization. At its option OSP Home Furnishings will: ®...
  • Page 3 3. Rename all English discriptions to French discriptions. PARTS (A) Backrest (1 PC) (B) Seat (1 PC) (C) Base (1 PC) (D) Seat Plate (1 PC) (E) Pneumatic Clyinder (1 PC) (F) Bellows (1 PC) (G) Caster (5 PCS) HARDWARE LIST DRAWING DESCRIPTION QUANTITY...
  • Page 4 STEP 1 Insert five Casters (G) into Base (C), push hard until you feel or hear the Caster (G) snap into place. Insert Pneumatic Cylinder (E) into Base (C) and slip Bellows (F) over Pneumatic Cylinder (E). STEP 2 Attach Seat Plate (D) to Seat (B) with the arrow towards the front of the chair using four Short BOLTS with washers (1).
  • Page 5 STEP 3 Attach BackRest (A) to rear of Seat Plate (D) using four long bolts with washers (2). fully tighten bolts (2) using allen wrench (3). STEP 4 Place the assembled seat on top of Pneumatic Cylinder (E) and apply downward pressure.
