Related Manuals for HIKVISION TurboHD DS-2CC5209T-AITZE
Summary of Contents for HIKVISION TurboHD DS-2CC5209T-AITZE
- Page 1 All manuals and user guides at all-guides.com DS-2CCx2D9T-xxxx HD 1080p Ultra Low-Light PoC Camera User Manual...
- Page 2 all-g uides .com...
- Page 3 Any and all information, including, among others, wordings, pictures, graphs are the properties of Hangzhou Hikvision Digital Technology Co., Ltd. or its subsidiaries (hereinafter referred to be “Hikvision”). This user manual (hereinafter referred to be “the Manual”) cannot be reproduced, changed, translated, or distributed, partially or wholly, by any means, without the prior written permission of Hikvision.
- Page 4 SURVEILLANCE LAWS VARY BY JURISDICTION. PLEASE CHECK ALL RELEVANT LAWS IN YOUR JURISDICTION BEFORE USING THIS PRODUCT IN ORDER TO ENSURE THAT YOUR USE CONFORMS TO THE APPLICABLE LAW. HIKVISION SHALL NOT BE LIABLE IN THE EVENT THAT THIS PRODUCT IS USED FOR ILLEGITIMATE PURPOSES.
- Page 5 All manuals and user guides at all-guides.com conditions: • This device may not cause harmful interference. • This device must accept any interference received, including interference that may cause undesired operation. EU Conformity Statement This product and, if applicable, the supplied accessories too are marked with “CE”...
- Page 6 “Last Updated” above. What Information We Collect In order to provide HIKVISION services to you, we will ask you to provide personal information that is necessary to provide those services to you. If you do not provide your personal information, we may not be able to provide you with our products or services.
- Page 7 • personalize your experience with our HIKVISION Services and Products; • increase the safety of our HIKVISION Services and Products – for example, for user authentication, security protection, fraud detection, filing, and backups; • perform analytics and conduct customer research;...
- Page 8 all-g uides .com...
- Page 9 Terms of Service. • If HIKVISION and/or all or part of our assets are ever sold or transferred, your personal information may be among the items sold or transferred. Under such circumstance, we will notify you by the e-mail address specified in your account or by means of notice on us.hikvision.com and associated Websites of (i) the identity and contact information of...
- Page 10 100% secure. Therefore, HIKVISION cannot guarantee that your personal information is under absolute security with the existing security technology. If you have any questions about the security of our HIKVISION Services, you can contact us at the contact information below in Contact Us.
- Page 11 Privacy Policy. Links to Other Websites We may permit others to link to the HIKVISION services or to post a link to their Website. We do not endorse these Websites and are not responsible for other Websites or their privacy practices.
- Page 12 Our HIKVISION Services are designed and intended for adults. By using the HIKVISION Services, you represent that you are at least 18 years old, or above the equivalent minimum age in the relevant jurisdiction and understand that you must be at...
- Page 13 All manuals and user guides at all-guides.com • Canadian Technical Support: techsupport.ca@hikvision.com • Need Help with This Product/Product Detail feature: inside.usa@hikvision.com • A&E partner inquiries (user registration, new project support, etc.): aepartners.usa@hikvision.com • HDP partner inquiries (user registration, new partner registration, etc.): partners.usa@hikvision.com...
- Page 14 all-g uides .com...
-
Page 15: Specifications
All manuals and user guides at all-guides.com Mandatory Electrical Requirements Hikvision requires the following conditions and equipment for all of its electronic equipment: • Grounding Ensure good conductivity for all ground paths; examine ground path contact surfaces for defects, dirt, corrosion, or non- conductive coatings that may impede conductivity. - Page 16 All manuals and user guides at all-guides.com - Maintenance > Replace after a serious electrical event (e.g., lighting blew out a transformer down the street) > Replace yearly in storm-prone areas > Replace every two years as routine maintenance Symbol Conventions The symbols that may be found in this document are defined as follows.
- Page 17 All manuals and user guides at all-guides.com technical specifications for detailed information. • Do not connect several devices to one power adapter as adapter overload may cause overheating or a fire hazard. • Make sure that the plug is firmly connected into the power socket. •...
- Page 18 All manuals and user guides at all-guides.com Cautions Make sure the power supply voltage is correct before using the camera. Do not drop the camera or subject it to physical shock. Do not touch sensor modules with fingers. If cleaning is necessary, use a clean cloth with a bit of ethanol, and wipe it gently.
- Page 19 All manuals and user guides at all-guides.com Table of Contents UM DS-2CCx2D9T-xxxx 022520NA (UD02874B-A)
- Page 20 all-g uides .com...
- Page 21 All manuals and user guides at all-guides.com UM DS-2CCx2D9T-xxxx 022520NA (UD02874B-A)
- Page 22 All manuals and user guides at all-guides.com Introduction 1.1. Product Features The camera is applicable for both indoor and outdoor conditions, and the application scenarios include road, warehouse, underground parking lot, bar, etc.. The main features are as follows: • High performance CMOS sensor •...
- Page 23 All manuals and user guides at all-guides.com 1.2. Overview of Type I Camera Figure 1, Type I Camera 1.3. Overview of Type II Camera Figure 2, Type II Camera UM DS-2CCx2D9T-xxxx 022520NA (UD02874B-A)
- Page 24 All manuals and user guides at all-guides.com 1.4. Overview of Type III Camera Figure 3, Type III Camera 1.5. Overview of Type IV Camera Figure 4, Type IV Camera 1.6. Overview of Type V Camera Figure 5, Type V Camera UM DS-2CCx2D9T-xxxx 022520NA (UD02874B-A)
-
Page 25: Installation
All manuals and user guides at all-guides.com Installation 2.1. Before You Start Make sure that the device in the package is in good condition and all the assembly parts are included. Make sure that all the related equipment is powered off during the installation. - Page 26 all-g uides .com...
- Page 27 All manuals and user guides at all-guides.com Figure 6, Type I Camera Drill Template Figure 7, Type II Camera Drill Template 3. Loosen the screws on the dome camera bubble to remove the bubble and black liner. 4. Attach the of type I camera back box/type II camera base plate to the ceiling and secure with supplied screws.
- Page 28 All manuals and user guides at all-guides.com Figure 8, Attach the Back Box/Base Plate The supplied screw package contains both self-tapping screws and expansion bolts. If the wall is concrete, expansion bolts are required to fix the camera. If the wall is wood, self-tapping screws are required.
- Page 29 All manuals and user guides at all-guides.com Figure 9, Affix the Camera to the Ceiling 7. Connect the corresponding cables such as power cable and video cable. 8. Power on the camera to check if the image on the monitor is at an optimum angle.
- Page 30 All manuals and user guides at all-guides.com bubble of the dome camera to finish the installation. 2.2.2. Wall Mounting You need to purchase a wall mounting bracket separately if you use wall mounting. 1. Drill four screw holes in the wall according to the bracket holes. 2.
- Page 31 All manuals and user guides at all-guides.com Figure 12, Attach Base Plate to Bracket 6. Route the cables through the bracket. 2.1.1 Ceiling Mounting steps 6 to 9 of to complete the Repeat installation. 2.2.3. In-Ceiling Mounting You need to purchase an in-ceiling mounting bracket separately if you use in-ceiling mounting.
- Page 32 all-g uides .com...
- Page 33 All manuals and user guides at all-guides.com Figure 13, In-Ceiling Mounting Bracket 5. Route the cables through the cable hole. 6. Attach the type I camera back box/type II camera base plate to the in-ceiling mounting bracket with the supplied screws. The supplied screw package contains both self-tapping screws and expansion bolts.
- Page 34 All manuals and user guides at all-guides.com 2.2.4. In-Ceiling Mounting with Junction Box You need to purchase an in-ceiling mounting bracket separately if you use in-ceiling mounting with the junction box. Figure 15, Install the Bracket 2.1.3 In-Ceiling Mounting 1. Repeat steps 2 to 4 of the section to secure the in-ceiling mounting bracket (supplied) to the junction box.
- Page 35 All manuals and user guides at all-guides.com Figure 16, Affix Camera to Junction Box 2.1.1 Ceiling Mounting 4. Repeat steps 6 to 9 of the section to complete the installation. 2.2.5. Mounting with Inclined Base of Type I Camera You need to purchase an inclined base separately if mounting with an inclined base.
- Page 36 All manuals and user guides at all-guides.com Figure 17, Affix Inclined Base 3. Route the cables through the inclined base hole. 4. Attach the type I camera back box/type II camera base plate to the inclined base with the supplied screws. Figure 18, Affix Camera to Base 2.1.1 Ceiling Mounting 5.
- Page 37 All manuals and user guides at all-guides.com example in this section. Use the ceiling mounting steps as a reference for wall mounting. 1. Attach the drill template to the ceiling. 2. Drill the screw holes and cable hole (optional) on the ceiling according to the supplied drill template.
- Page 38 all-g uides .com...
- Page 39 All manuals and user guides at all-guides.com Figure 20, Affix Camera to Ceiling 5. Connect the corresponding cables such as power cable and video cable. The supplied screw package contains both self-tapping screws and expansion bolts. If the wall is concrete, expansion bolts are required to affix the camera.
- Page 40 All manuals and user guides at all-guides.com Figure 21, Internal Interface and Button 8. Power on the camera to check if the image on the monitor is at an optimum angle. If not, adjust the surveillance angle. 1) Loosen the no.1 adjusting screw to adjust the pan position [0°...
- Page 41 All manuals and user guides at all-guides.com Figure 22, 3-Axis Adjustment 2.3.2. Mounting with Junction Box You need to purchase a junction box separately if mounting with a junction box. 1. Attach the drill template to the wall/ceiling. 2. Drill screw holes and cable hole in the wall/ceiling according to the drill template holes.
- Page 42 All manuals and user guides at all-guides.com Type IIICamera Type IVCamera Figure 23, Install Junction Box 5. Route the cables through the cable hole. 6. Secure the camera with M4 × 10 screws on the junction box. Figure 24, Wall/Ceiling Mounting with Junction Box 7.
- Page 43 All manuals and user guides at all-guides.com 2.4. Type V Camera Installation 2.4.1. Ceiling Mounting 1. Disassemble the turret camera by rotating the camera to align the notch to one of the marks, as shown below. Figure 25, Disassemble the Camera 2.
- Page 44 all-g uides .com...
- Page 45 All manuals and user guides at all-guides.com Figure 26, Drill Template 4. Attach the mounting base to the ceiling and secure with supplied screws. Figure 27, Attach Mounting Base to Ceiling The supplied screw package contains both self-tapping screws and expansion bolts. If the wall is concrete, expansion bolts are required to affix the camera.
- Page 46 All manuals and user guides at all-guides.com Figure 28, Secure Camera with Mounting Base 7. Power on the camera to check that the image on the monitor is at an optimum angle. If not, adjust the camera according to the figure below to get an optimum angle.
- Page 47 All manuals and user guides at all-guides.com 2.4.2. Ceiling Mounting with Junction Box You need to purchase a junction box separately if you use ceiling mounting with a junction box. 1. Disassemble the junction box from the junction box cover. 2.
- Page 48 All manuals and user guides at all-guides.com camera to the junction box. 2.4.3. Wall Mounting You need to purchase a wall mounting bracket separately if you use wall mounting. 1. Drill four screw holes in the wall according to the bracket holes. 2.
- Page 49 All manuals and user guides at all-guides.com Figure 33, Attach Mounting Base to Bracket 2.3.1 Ceiling Mounting steps 5 to 7 of the section to Repeat complete the installation. 2.4.4. Mounting with Inclined Base You need to purchase an inclined base separately if you mount with an inclined base.
- Page 50 all-g uides .com...
- Page 51 All manuals and user guides at all-guides.com Figure 34, Drill Template 3. Disassemble the inclined base with the screwdriver. 4. Install the turret camera’s mounting base to the inclined base cover with three PM4 screws. Figure 35, Install Turret Camera Mounting Base 5.
- Page 52 All manuals and user guides at all-guides.com Figure 36, Affix Inclined Base Body 6. Attach the inclined base cover to its body with supplied screws. 2.3.1 Ceiling Mounting 7. Repeat steps 5 to 7 of the section to complete the installation. Figure 37, Affix Camera to Inclined Base UM DS-2CCx2D9T-xxxx 022520NA (UD02874B-A)
-
Page 53: Menu Operation
All manuals and user guides at all-guides.com Menu Operation Two methods are available to call the menu. This section takes method b) as an example to start the menu operation. A. Call the menu and adjust the camera parameters with a coaxial camera controller (purchase separately). - Page 54 All manuals and user guides at all-guides.com Figure 39, Menu Tree UM DS-2CCx2D9T-xxxx 022520NA (UD02874B-A)
-
Page 55: Smart Focus
All manuals and user guides at all-guides.com Camera type IV and type V do not support SMART FOCUS. 3.1. VIDEO OUT • PAL: (Phase Alternating Lines) is a color encoding system for analog television used in broadcast television systems in most countries. - Page 56 all-g uides .com...
- Page 57 All manuals and user guides at all-guides.com • LOW LIGHT: Applicable to environments with low light. Under this circumstance, slow shutter is ON by default to receive more light. 3.3.3. LENS The camera is equipped with a manual lens or a DC (auto iris) lens. Indoor mode and outdoor mode are available for the DC lens.
- Page 58 All manuals and user guides at all-guides.com If you select shutter as AUTO or 1/25, SENS-UP is adjustable (OFF/AUTO), and SENS-UP is disabled if any other shutter speed is selected. • AGC: A form of amplification where the camera will automatically boost the image output signal to optimize the image clarity in poor light conditions.
- Page 59 All manuals and user guides at all-guides.com weather or in high illumination, in which the dynamic range is lower than that in an ordinary environment, and the image always appears hazy. Enabling Defog can enhance subtle details so that the image appears clearer. Set Defog to ON to enable the function.
- Page 60 All manuals and user guides at all-guides.com define the BLC area. - DEFAULT: Restore the BLC settings to the default. Figure 42, BLC • HLC (High Light Compensation): Masks strong light sources that usually flare across a scene. HLC makes it possible to see the image details that would normally be hidden.
- Page 61 All manuals and user guides at all-guides.com Figure 43, HLC • WDR (Wide Dynamic Range): Balances the brightness level of the whole image, and provide the clear image with details. - GAIN: Set the gain of WDR as high, middle, or low. The higher the gain, the clearer the image.
- Page 62 all-g uides .com...
-
Page 63: White Balance
All manuals and user guides at all-guides.com 3.3.6. WHITE BALANCE White balance is the camera’s white rendition function to adjust the color temperature according to the environment. It can remove unrealistic color casts in the image. MANUAL, ATW (Auto-Tracking White Balance), and AWC→SET are selectable. •... - Page 64 All manuals and user guides at all-guides.com • D-EFFECT: OFF, MIRROR, V-FLIP, and ROTATE are selectable for the mirror. • OFF: The mirror function is disabled. • MIRROR: The image flips 180 degrees horizontally. • V-FLIP: The image flips 180 degrees vertically. •...
- Page 65 All manuals and user guides at all-guides.com Figure 46, Motion • PRIVACY: The privacy mask allows you to cover certain areas that you don’t want to be viewed or recorded. Up to eight privacy areas are configurable. Figure 47, Privacy 1.
- Page 66 All manuals and user guides at all-guides.com - When the input voltage is 30 percent higher than the calibrated voltage, OVERVOLTAGE flashes on the screen. Camera type IV and type V do not support VOLTAGE DETECTION. • DEFECT: Defective pixels in digital camera CCD or CMOS image sensors fail to sense light levels correctly.
- Page 67 All manuals and user guides at all-guides.com 3.3.9. ADJUST In the Adjust sub-menu, you can configure settings including sharpness, image quality on monitor, and LSC (lens shading compensation). Move the cursor to ADJUST and click Iris+ to enter the adjust configuration interface. Figure 49, Adjust •...
- Page 68 all-g uides .com...
- Page 69 The current can pick up a high frequency oscillating signal from the surroundings and carry it into the camera, causing interference. To remedy this, Hikvision began including the following items with select cameras since June 2019: • Select Dual-Voltage Cameras: 24 VAC to 12 VDC power converter/filter •...
- Page 70 All manuals and user guides at all-guides.com 4.1. Power Filter Use If your video signal displays power line interference (horizontal lines moving across the screen), install the included power filter to eliminate or minimize the interference. Place the power filter between the camera and the leads/ connectors coming out of the power supply.
- Page 71 Cameras manufactured prior to June 2019 did not ship with a (converter)/filter. Hikvision will ship filter(s) to you free of charge, if needed. Send e-mail to Hikvision Customer Service at cust.usa@hikvision.com, provide the camera model number, serial number, place of purchase, and shipping address.
